- Page 1 S IMP H O M E L I F E B Y D E S I G N WARM SHAKER / NORFOLK / LEXINGTON MEDIUM STORAGE & MEDIA CABINET MODEL # AXWSH005 1/19...
- Page 2 FOR REPLACEMENT PARTS OR HELP WITH ASSEMBLY PLEASE CONTACT US AT: simpli-home.com/customer-support PLEASE ENSURE TO HAVE THE MODEL # FROM THE PACKAGING OR INSTRUCTION BOOKLET TO RETURN THE PRODUCT: PLEASE CONTACT THE RETAILER WHERE THE ITEM WAS PURCHASED FROM 2/19...
- Page 3 L I F E B Y D E S I G N ENTER TO WIN Upload an image of our furniture in your home with a short review to our facebook page for a chance to Win up to $3000 of Simpli Home furniture!!! www.facebook.com/simplihomefurnishings 3/19...
-
Page 4: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # AXWSH005-GR PARTS DESCRIPTION SIDE CENTRE SUPPORT QTY 1 QTY 1 PAIR QTY 1 DOOR BOTTOM SHELF TOP SHELF QTY 1 PAIR QTY 1 QTY 1 DIVIDER CABINET SHELF BACK PANEL QTY 1 QTY 2 QTY 2 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. -
Page 6: Hardware Description
PRE-ASSEMBLY INFORMATION MODEL # AXWSH005-GR HARDWARE DESCRIPTION ALLEN KEY SCREW CAM LOCK PIN ALLEN KEY M6 X 30 mm CAM LOCK QTY 1 QTY 8 QTY 12 SETS PHILLIPS SCREW PHILLIPS SCREW M4 X 15 mm M3 X 15 mm MAGNET AND PLATE QTY 2 SETS QTY 24... - Page 7 COMPONENTS – KEY DIAGRAM MODEL # AXWSH005-GR 7/19...
- Page 8 ASSEMBLY MODEL # AXWSH005-GR STEP 1 1. Attach Bottom Shelf E to Centre Support C with Allen Key Screws 1 through pre-drilled holes. 2. Attach Cam Lock Pins 2 to Top Shelf F using guide holes. 3. Align Cam Lock Pins 2 and insert into pre-drilled holes on Centre Support C . 4.
- Page 9 ASSEMBLY MODEL # AXWSH005-GR STEP 2 1. Attach Cam Lock Pins 2 into guide holes on Side B ( 3 Cam Lock Pins for the bottom and 2 for the top ). 2. Align Cam Lock Pins 2 with pre-drilled holes of Bottom Shelf E and Top Shelf F . 3.
- Page 10 ASSEMBLY MODEL # AXWSH005-GR STEP 3 1. To attach opposite Side B to Bottom Shelf E and Top Shelf F repeat steps 1 - 4 in step 2. 10/19...
- Page 11 ASSEMBLY MODEL # AXWSH005-GR STEP 4 1. Insert 2 Wood dowels 11 into corner of each Side B . 2. Insert 6 Wood dowels 11 into Divider G . 3. Use rubber mallet to tap Dowels 11 into bottom of holes securely. ½ length of Dowels should be exposed.
- Page 12 ASSEMBLY MODEL # AXWSH005-GR STEP 5 1. Attach Adjustable Hinges 12 to Doors D using Phillips Screws 4 into guide holes on Doors D . 2. Attach Adjustable Hinges on Doors D to Sides B using Phillips Screws 4 into guide holes on Sides B .
-
Page 13: Important Note
ASSEMBLY MODEL # AXWSH005-GR IMPORTANT NOTE: Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so that all the spaces between the door and the unit sides are equal. To adjust, follow instructions: 1. Side adjustment 4 mm To move the door towards the side panel, loosen screw I and tighten screw II . - Page 14 ASSEMBLY MODEL # AXWSH005-GR STEP 6 1. Attach Magnet Plates 6 to inside corners of Doors D using Phillips Screws 5 into guide holes on Doors D . 2. Attach Magnet 6 to inside corner of Bottom Shelf E using Phillips Screws 5 into guide holes on Bottom Shelf E .
- Page 15 ASSEMBLY MODEL # AXWSH005-GR STEP 7 1. Attach Back Panels I to back of cabinet using Phillips Screws Round Head 9 into pre-drilled guide holes. 2. Use Phillips screwdriver to tighten screws. STEP 8 1. Use 4 Shelf Supports 7 for each Cabinet Shelf H in desired location. 2.
- Page 16 FURNITURE ANTI-TIPPING RESTRAINT ASSEMBLY NOTE: Injuries and damage can occur from furniture tip-over. It is important to use the safety bracket included. If the tipping restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture.
- Page 17 FURNITURE ANTI-TIPPING RESTRAINT ASSEMBLY Furniture Anti-Tipping Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 18: Warranty
L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. - Page 19 S IMP H O M E L I F E B Y D E S I G N Question, problems, missing parts? Before returning your product please email Customer Support at simpli-home.com/customer-support or call Customer Support at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
