- Page 1 User Manual V1.0 External LCD Display For Omnik NS Series Inverters User Manual -Safety Regulation...
-
Page 2: Table Of Contents
Table of Contents General Introduction ....................... 2 1) Applied models ......................2 2) Methods........................2 External LCD Display...................... 2 1) Setting ........................3 a) Control Panel ....................3 b) Menu Structure ....................4 c) Operation .................... -
Page 3: General Introduction
1. General Introduction 1) Applied models The models apply for the methods described in the following manual: Omniksol-2k/2.5k/3k-TL3-S-NS Omniksol-3k/3.68k/4k/4.6k/5k/6k-TL3-NS Omniksol-5k/6k-TH/8k/10k/13k/16k-TL3-NS Omniksol-20k/25k/30k-TL3-NS and other upcoming models with “NS” 2) Methods There are three methods in configuring your NS model inverters: ... -
Page 4: Setting
1) Setting Control Panel Fig. 1 Front View Fig. 2 Top View Object Name Description COM1 Connect to WIFI or GPRS module for remote update Connect to the inverter for local operation and modify inverter COM2 parameters... -
Page 5: B) Menu Structure
b) Menu Structure System Status Page2 Safety Total Energy Current Power PV Input Mode Today Energy Page3 PV1 Volt&Current PV2 Volt&Current Info Model Page4 Grid Volt&Current &Freq Err No. Page1 Main Interface Error Err Time Page5 Grid Volt&Current &PF Err Detail Time Page6 Date&Time... -
Page 6: C) Operation
Operation The default interface will be shown once the “Com2” is connected to the inverter. The screen shows the interface as “Fig. 3” indicating the system is started up. This interface will also be shown when the display is not operated for a while. Terminology the default interface: ... - Page 7 End-users can set Date Time, Language by themselves. There is an installer password required to operate on other advance settings, e.g. safety, password, protection etc. Note: Please contact with your installer or Omnik service team for the installer password. The default factory default password is 500005. Protection XXXXXX Fig.
-
Page 8: App Local Function
3. App Local Function The App local function can be used only when the inverter is installed with a WIFI or GPRS stick. 1) Download and Install Search for “Solarman Pro” in AppStore /Google Play or scan the QR code to download the Solarman Pro APP. - Page 9 Press on the icon to access App. Press on "All" Press on "Local Mode" to enter the scanning interface, scan the QR code on the WIFI stick Press on “Next” and prompt “Are you sure you have connected to the *** WIFI?”...
-
Page 10: B) Change Safety Regulation
b) Change safety regulation... -
Page 11: Remote Control
4. Remote control If the inverter is installed with a WIFI or GPRS stick, the configuration, firmware updating etc. can be done via remote control. Please contact Omnik service team via service@omnik-solar.com, or browse on omnik-solar.com/contact-us page to contact nearest service center along with the SN number of WIFI and the inverter.
