  • Page 1 DVD VIDEO PLAYER PLAYER PLAYER DVP532K DVP534K DVP532K DVP534K 8239 300 30471 01-34 DVP532_4K_69 19/03/2004, 2:59 PM...

  • Page 2: General Information

    Due to the numerous versions of new CD-Audio copy protection or enhanced CD-Audio protection recently available on certain discs, Philips is unable to guarantee that this DVD Player is fully compatible with such new discs. Should you have difficulty playing any such CD-Audio discs, kindly refer them to your CD- Audio disc retailer.
  • Page 3 This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.

  • Page 4: Table Of Contents

    Contents Introduction Supplied accessories ... 5 Care and safety information ... 5 Connections Connecting TV ... 6-7 Using Component Video jacks (Y Pb Pr) .. Using Composite Video jack (CVBS) ... Using S-Video jack ... Using an accessory RF modulator ... Connecting the power cord ...

  • Page 5: Introduction

    PREVIEW MUTE MUTE VOCAL VOCAL MODE MODE PHILIPS 10 cm (4 inches) DVD Home Cinema System Care of the cabinet – Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives.

  • Page 6: Connections

    Connections Connecting TV COMPONENT VIDEO IN S-VIDEO V (Pr/Cr) U (Pb/Cb) VIDEO IN COMPONENT VIDEO IN S-VIDEO V (Pr/Cr) AUDIO U (Pb/Cb) VIDEO IN VIDEO OUT MAINS S-VIDEO OUT COAXIAL COMPONENT DIGITAL OUT AUDIO OUT VIDEO OUT IMPORTANT! – You only need to make one video connection from the following options, depending on the capabilities of your TV system.

  • Page 7: Using S-video Jack

    RF In,) you will need an RF modulator in order to view the DVD playback on the TV. See your electronics retailer or contact Philips for details on RF modulator availability and operations. Using an accessory RF modulator Use the composite video cable (yellow) to connect the DVD Player’s CVBS (VIDEO...

  • Page 8: Connecting The Power Cord

    Connections Connecting the power cord COMPONENT VIDEO IN S-VIDEO AUDIO V (Pr/Cr) ~ AC MAINS U (Pb/Cb) VIDEO IN VIDEO OUT MAINS S-VIDEO OUT COMPONENT VIDEO OUT After everything is connected properly, plug in the AC power cord to the power outlet. Never make or change any connections with the power switched on.

  • Page 9: Optional: Connecting To An Audio System

    Optional: Connecting to an Audio System STEREO VIDEO OUT S-VIDEO OUT COAXIAL COMPONENT DIGITAL OUT AUDIO OUT VIDEO OUT Stereo system has Dolby Pro Logic or Right / Left Audio In jack Select one of the video connections (VIDEO IN, S-VIDEO IN or Component Video (Y Pb Pr) jack depending on the options available on your TV.

  • Page 10: Functional Overview

    Functional Overview Front Panels DVP532K STANDBY-ON B – To switch the DVD Player to Standby mode or ON Disc tray OPEN/CLOSE / – Open/Close the disc tray – For connecting microphone – Microphone volume control DVP534K STANDBY-ON B – To switch the DVD Player to Standby mode or ON Disc tray OPEN/CLOSE /...

  • Page 11: Rear Panel

    Rear Panel Mains (AC Power Cord) – Connect to a standard AC outlet S-Video Out – Connect to S-Video input of a TV Video Out (CVBS) – Connect to CVBS Video input of a TV VIDEO OUT MAINS S-VIDEO OUT Caution: Do not touch the inner pins of the jacks on the rear panel.

  • Page 12: Remote Control

    Functional Overview Remote Control RETURN / TITLE – To go back to previous menu / show title menu DISC MENU – Enters or exits the disc contents menu – Switches on or off the playback control mode (for VCD version 2.0 only) 1 2 3 4 –...

  • Page 13: Getting Started

    6-7 “Connecting TV”). Turn on the TV and set to the correct video-in channel. You should see the blue Philips DVD background screen on the Usually these channels are between the lowest and highest channels and may be called FRONT, A/V IN, or VIDEO. See your TV manual for more details.

  • Page 14: Selecting The Colour System That Corresponds To Your Tv

    Getting Started Selecting the colour system that corresponds to your TV This DVD Player is compatible with both NTSC and PAL. In order for a DVD disc to play on this Player, the colour system of the Disc, the TV and the DVD Player should match.

  • Page 15: Step 3: Setting Language Preference

    Step 3: Setting language preference You can select your own preferred language settings.This DVD system will automatically switch to the selected language whenever you load a disc. If the language selected is not available on the disc, the disc’s default language will be used instead.

  • Page 16: Disc Operations

    “Setting up the TV”). Press STANDBY-ON on the DVD Player front panel. You should see the blue Philips DVD background screen on the TV. Press OPEN•CLOSE 0 button to open the disc tray and load in a disc, then press the same button again to close the disc tray.

  • Page 17: Using The Disc Menu

    Using the Disc Menu Depending on the disc, a menu may appear on the TV screen once you load the disc. To select a playback feature or item Use the 1 2 3 4 or numeric keypad (0-9) on the Remote Control, then press PLAY B to start playback.

  • Page 18: Zoom

    Disc Operations Zoom (DVD/SVCD/VCD/JPEG) Zooming allows you to enlarge or reduce the video image during playback. Press ZOOM repeatedly to increase and decrease the playback video image. Press 1 2 3 4 to pan across the TV screen. Repeat (DVD/SVCD/VCD/CD) Press REPEAT continuously to choose a Repeat mode during playback.

  • Page 19: Time Search

    Time Search (DVD/SVCD/VCD) The Time Search function allows you to start playing at any chosen time on the disc. Press DISPLAY. Press 3 4 to highlight time search box. The on-screen display shows the total playing time of the title/chapter. Menu Menu TT Time...

  • Page 20: Preview Function

    Disc Operations Preview Function (DVD/VCD/CD) The preview function allows you to reduce the picture of 6 tracks enough to display in a full screen. Press PREVIEW. The preview menu appears on the TV screen. Select Digest Type: Select Digest Type: Select Digest Type: Select Digest Type: Title Digest...

  • Page 21: Playback Selection

    Playback selection During playback, you can; S / T Press to select another file in the current folder. on the remote to rotate/flip 1 2 3 4 the picture files. Press repeatedly to pause/resume playback. Repeat Press REPEAT continuously to access different ‘Play Mode’.

  • Page 22: Karaoke Operations

    Karaoke Operations Playing Karaoke discs IMPORTANT! You have to turn on your TV and set to the correct Video In channel. (See page 13 “Setting up the TV”). General Operation Connect a microphone (not supplied) to MIC on the side panel of the DVD player. PLAY/PAUSE Press KARAOKE repeatedly.

  • Page 23: System Menu Options

    Basic Operations Press SYSTEM MENU to enter the Setup Menu. Press OK to enter the next level submenu or confirm your selection. Press 1 2 to enter the submenu or return to the previous menu. Press 34 to highlight the desired menu. To exit from the menu Press SYSTEM MENU or select ‘Exit Setup Menu’...

  • Page 24: Audio Setup Page

    System Menu Options Audio Setup Page The options included in Audio Setup page are: ‘Speaker Setup’, ‘Digital Audio Setup’, ‘Dolby Digital Setup’, ‘Equalizer’ and ‘3D’. Press SYSTEM MENU. Press 1 2 to select the ‘Audio Setup’ page. Speaker Setup The options included in Speaker Setup are: ‘Downmix’...

  • Page 25: Dolby Digital Setup

    LPCM Output If you connect the DVD Player to a PCM compatible receiver via the digital terminals, such as coaxial or optical etc, you may need to adjust ‘LPCM Output’. Discs are recorded at a certain sampling rate. The higher the sampling rate, the better the sound quality.

  • Page 26: Equalizer

    System Menu Options Equalizer The option included in Equalizer is: ‘Sound Mode’. Press 34 to highlight ‘Sound Mode’. Enter its submenu by pressing 2. Move the cursor by pressing the 34 keys to highlight the selected item. - - Equalizer Page - - Sound Mode None Rock...

  • Page 27: Video Setup Page

    Video Setup Page The options included in Video Setup page are: ‘TV Type’, ‘TV Display’, ‘Closed Captions’, ‘Angle Mark’, ‘Progressive’, ‘Smart Picture’, and ‘Picture Setting’. Press SYSTEM MENU. Press 1 2 to select the ‘Video Setup’ page. - - Video Setup Page - - TV Type TV Display Closed Captions...

  • Page 28: Closed Captions

    System menu Options Closed Captions Closed captions are data that are hidden in the video signal of some discs. Captions are different from subtitles because captions hearing are impaired by showing the sound effects (e.g., “phone ringing” and “footsteps”), while subtitles do not. Before you select this function, please ensure that the disc contains closed captions information and your TV set also...

  • Page 29: Smart Picture

    Smart Picture In this menu, you can choose a picture setting from a fixed set of predefined picture settings. Press 34 to highlight ‘Smart Picture’. Enter its submenu by pressing 2. Move the cursor by pressing 34 to highlight the selected item. Standard: select the standard picture setting.

  • Page 30: Password

    System Menu Options Parental - cont’d Helpful Hint: – Some DVDs are not encoded with a rating though the movie rating may be printed on the Disc cover. The rating level feature does not work for such Discs. Rating explanations 1 KID SAFE –...

  • Page 31: Specifications

    TV STANDARD (PAL/50Hz) (NTSC/60Hz) Number of lines Playback Multistandard (PAL/NTSC) VIDEO PERFORMANCE DA Converter 12 bit, 54mHz Component video Y: 1 Vpp into 75 ohm output (480i/p) PbPr: 0.7 Vpp into 75 ohm Video Output 1Vpp — 75 ohm S-Video Output Y: 1Vpp —...

  • Page 32: Troubleshooting

    Do not open the system as there is a risk of electric shock. If a fault occurs, first check the points listed below before taking the system for repair. If you are unable to remedy a problem by following these hints, consult your dealer or Philips for help. Problem No power...
  • Page 33 Problem The player does not respond to the Remote Control Buttons do not work Player does not respond to some operating commands during playback. DVD Player cannot read CDs/DVDs Menu items cannot be selected If you are unable to remedy a problem by following these hints, consult your dealer or service center (HOTLINE).

  • Page 34: Glossary

    Glossary Analog: Sound that has not been turned into numbers. Analog sound varies, while digital sound has specific numerical values. These jacks send audio through two channels, the left and right. Aspect ratio: The ratio of vertical and horizontal sizes of a displayed image. The horizontal vs.
