Keiser INFINITY Series Installation Instructions Manual
Triple trainer bolt-down base with bolt-down base 3031x floor mount plate
Hide thumbs
Also See for INFINITY Series:
- Operation & maintenance manual (16 pages) ,
- Installation instructions manual (12 pages) ,
- Operation manual (16 pages)
Advertisement
MODELS 3020XA, XP, XS
with Bolt-down Base
3031X FLOOR MOUNT PLATE
BEFORE YOU BEGIN
• Ensure a site survey for equipment installation has
been performed.
• Observe all governing codes and ordinances.
• Proper installation is the responsibility of the installer.
• Note to Installer: Be sure to leave Installation
Instructions and Operation Manual with the customer.
• Note to Customer: Keep Installation Instructions and
Operation Manual for future reference.
• Skill level: Professional installation is required by
qualified personnel as dictated by authority having
jurisdiction.
Product failure due to improper installation is not covered under
warranty.
READ CAREFULLY. KEEP THESE INSTRUCTIONS.
CUSTOMER SUPPORT
If you have any questions regarding the installation or
operation of the Triple Trainer after reading this manual,
contact Keiser Customer Support:
1 559 256 8000
service@keiser.com
keiser.com/support
Keiser, the Keiser logo, and other trademarks associated with Keiser products referred to in this publication are trademarks of Keiser Corporation.
© Copyright 2018, Keiser Corporation. All rights reserved.
Distribution and copying of this document, use and communication of its contents is not permitted without written authorization from Keiser Corporation. The content
of this document is furnished for informational use only, may be subject to change without notice, and should not be construed as a commitment by Keiser Corporation.
Every effort has been made to ensure that the information in this manual is accurate. Keiser Corporation is not responsible for printing or clerical errors.
305522_A
INSTALLATION INSTRUCTIONS
INFINITY SERIES
TRIPLE TRAINER
BOLT-DOWN BASE
KEISER CORPORATION
2470 S. Cherry Ave.
Fresno, CA 93706
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Keiser INFINITY Series
Summary of Contents for Keiser INFINITY Series
- Page 1 Distribution and copying of this document, use and communication of its contents is not permitted without written authorization from Keiser Corporation. The content of this document is furnished for informational use only, may be subject to change without notice, and should not be construed as a commitment by Keiser Corporation.
- Page 2 INSTALLATION INSTRUCTIONS TRIPLE TRAINER CONTENTS 03 — IMPORTANT SAFETY INFORMATION 04 — EQUIPMENT SPECIFICATIONS 04_TRAINING SPACE 05 — SECURING THE TRIPLE TRAINER 05_INSTALLATION OPTIONS 05_MOUNTING REQUIREMENTS 06 — INSTALLATION 06_GETTING STARTED 07_UNPACKING 07_PARTS LIST 08_STEP-BY-STEP INSTALLATION GUIDE 10_AIR SYSTEM SETUP & FINAL INSTALLATION 11 —...
-
Page 3: Important Safety Information
5. Observe all governing codes and ordinances. could result in serious injury. 6. Safety Glasses required during installation. 17. Keiser Corporation is not responsible for damage or serious 7. Heavy Equipment: The Floor Mount Triple Trainer weighs injury caused by incorrect installation, assembly, or use. -
Page 4: Equipment Specifications
INSTALLATION INSTRUCTIONS TRIPLE TRAINER EQUIPMENT SPECIFICATIONS Height, arms up: 89 inches (2,261 mm) Height, arms down: 59 inches (1,499 mm) Bilateral Cable Length Length: 57 inches (1,448 mm) 72 inches (1,829 mm) Width: 32 inches (813 mm) Arm Span: 95 inches (2,413 mm) Unilateral Cable Length Weight: 345 lbs (156 kg) Training Space... -
Page 5: Installation Options
IMPORTANT: A site survey for equipment installation is required. It is the responsibility of the customer to ensure that a site survey is performed. To obtain a Site Survey Form, contact Keiser Customer Support by telephone at 1 559 256 8000, online 24/7 at keiser.com/support, or by email at service@keiser.com. - Page 6 • If you do not understand these instructions or have doubts about the safety of the installation, assembly, or use of this product, contact Keiser Customer Support (see front cover for contact information). NOTE: Product failure due to improper installation...
-
Page 7: Parts List
The Floor Mount Plate Kit is contained in a packet with the Functional Trainers. Check for any damage or missing parts. If parts are damaged or missing, contact your local dealer, distributor, or Keiser Customer Support (see front cover for contact information). - Page 8 INSTALLATION INSTRUCTIONS TRIPLE TRAINER STEP-BY-STEP INSTALLATION GUIDE CAUTION: WEAR Clean Drill Holes Adhesive SAFETY GLASSES with Wire Tube Brush Application 4 1/4 in. 3/8 in. (108 mm) Floor Mount Plate Hammer Drill Vacuum Dust/Debris Drill: Prepare drill holes for adhesive: Acrylic adhesive application: •...
- Page 9 INSTALLATION INSTRUCTIONS TRIPLE TRAINER STEP-BY-STEP INSTALLATION GUIDE TWO-PERSON PROCEDURE 3/8- 16x3/4 in. Screw Washer with Lift here CRUSH HAZARD KEEP FEET CLEAR Triple Trainer unit installation: • With your helper, carefully place one of the Functional Trainer units onto the Floor Mount Plate, align mount holes as shown. •...
- Page 10 Connector/Tube Insert may be reversed in position for air supply that is routed from the floor. WARNING: Never connect Keiser pneumatic equipment to an air source that is capable of exceeding 120 psi / 8.27 bar. Over pressurizing Keiser pneumatic equipment may cause tubing to burst, breakage of equipment, abnormal operation, or serious injury.
- Page 11 2. Ensure that the Triple Trainer is connected to the Compressor/Air Supply and that the Compressor/Air Supply is powered ON. 3. Read the Operation Manual, enclosed with the product and available at http://manuals.keiser.com. 4. Keep Installation Instructions for future reference.
- Page 12 INSTALLATION INSTRUCTIONS TRIPLE TRAINER CUSTOMER SUPPORT If you have any questions regarding the installation or operation of the Triple Trainer after reading this manual, contact Keiser Customer Support: KEISER CORPORATION 1 559 256 8000 2470 S. Cherry Ave. service@keiser.com Fresno, CA 93706 keiser.com/support...
