Page 1: User Manual
User Manual Manual del usuario Manual do Usuário Read your Quick Start Guide and/or User Manual first for quick tips that make using your Philips product more enjoyable. Register your product and get support at www.philips.com/welcome 1_dvp6620_55_eng7_Final2.indd 1 1_dvp6620_55_eng7_Final2.indd 1... -
Page 2: Aviso Importante
País de Origen: de Serie: LEA CUICADOSAMENTE ESTE INSTRUCTIVO AVISO IMPORTANTE Philips Mexicana, S.A. de C.V. no se hace responsable por daños o desperfectos causados por: – Maltrato, descuido o mal uso, presencia de insectos o roedores (cucarachas, ratones etc.). - Page 3 LASER Type Semiconductor laser InGaAlP (DVD) AIGaAs (CD) Wave length 658 nm (DVD) 790 nm (CD) Output Power 7.0 mW (DVD) 10.0 mW (VCD/CD) Beam divergence 60 degrees ‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE.
-
Page 4: Language Code
Language Code 1_dvp6620_55_eng7_Final2.indd 4 1_dvp6620_55_eng7_Final2.indd 4 2007-08-15 3:58:36 PM 2007-08-15 3:58:36 PM... - Page 5 “Evite o uso prolongado do aparelho com volume superior a 85 decibéis pois isto poderá prejudicar a sua audição.” Nível de Exemplos Decibéis Biblioteca silenciosa, sussurros leves Sala de estar, refrigerador, quarto longe do trânsito Trânsito leve, conversação normal, escritório silencioso Ar condicionado a uma distância de 6 m, máquina de costura Aspirador de pó, secador de cabelo,...
-
Page 6: Table Of Contents
Table of contents General General Information ... 8 Setup precautions ...8 Accessories supplied ...8 Cleaning discs ...8 About recycling ...8 Product Overview Your DVD Player ... 9 Remote Control ...10-12 Using the remote control ...12 Connections Basic Connections ...13-16 Step 1:Connecting to television ...13-14 Option 1: Using Composite Video jacks (CVBS) ...13 Option 2: Using Component Video jacks (Y Pb Pr) ...13 Option 3: Using HDMI or DVI TV jack ...14... - Page 7 Using Display menu options ... 26-27 Switching camera angles ...26 Searching by time ...26 Viewing playing time ...26 Preview function (VCD/SVCD/DVD) ...27 Special Audio CD feature ...27 Playing a DivX disc ... 28 Playing a JPEG image fi le (slide show) ...29 Preview function ...29 Zoom picture ...29 Rotating/fl ipping the picture ...29...
-
Page 8: General Information
General Information WARNING! This unit does not contain any user- serviceable parts. Please leave all maintenance work to qualifi ed personnel. Setup precautions Proper handling To prevent this unit from being scratched, always covers its front surface with a cloth before you place it fl at on any surface. -
Page 9: Your Dvd Player
STANDBY-ON 2 – Turns on this unit or turns off to normal standby mode. PLAY/PAUSE u – Starts/pauses playback. STOP Ç – Exits an operation. – Disc: stops playback. 1_dvp6620_55_eng7_Final2.indd 9 1_dvp6620_55_eng7_Final2.indd 9 Your DVD Player Top panel view IR Sensor –... -
Page 10: Remote Control
Remote Control 1_dvp6620_55_eng7_Final2.indd 10 1_dvp6620_55_eng7_Final2.indd 10 – Turns on this unit or turns off to normal standby mode. DISPLAY – Displays the current status or disc information. – : press up or down for a slow forward or backward search. –... - Page 11 DISC MENU – Enters or exits disc contents menu. – For VCD 2.0 only, switches on or off the playback control mode. – Confi rms an entry or selection. RETURN/TITLE – Returns to the previous menu or shows title menu PREV í...
-
Page 12: Using The Remote Control
Remote Control Using the remote control Open the battery compartment. Insert two batteries type R03 or AAA, following the indications (+-) inside the compartment. Close the cover. Point the remote control directly at the remote sensor (IR) on the front panel. DISC DISPLAY MENU... -
Page 13: Connections
COMPONENT VIDEO IN S-VIDEO V (Pr/Cr) AUDIO U (Pb/Cb) VIDEO IN COMPONENT VIDEO IN -VIDEO V (Pr/Cr) AUDIO U (Pb/Cb) IDEO IN Video (yellow plug) DIGITAL OUT COMPONENT VIDEO OUT Step 1: Connecting to television This connection enables you to view the video playback from this unit. -
Page 14: Option 3: Using Hdmi Or Dvi Tv Jack
Basic Connections HDTV / DVI TV HDMI IN Option 3: Using HDMI or DVI TV jack HDMI (High Defi nition Multimedia Interface) is a digital interface that allows pure digital audio/video transmission without the loss of image quality. Connect a HDMI cable (supplied) from the HDMI OUT jack on this unit to the HDMI IN jack on a HDMI-compatible device (e.g., HDMI TV, HDCP compliant... -
Page 15: Step 2: Placing The Unit
Clean Cloth To lock stand, slide to left Step 2: Placing the unit Before you start... – Make sure that all cables have been connected to this unit. – To prevent this unit from being scratched, always covers its front surface with a cloth before you place it fl at on any surface. -
Page 16: Step 3: Connecting The Power Cord
Basic Connections COMPONENT VIDEO IN S-VIDEO V (Pr/Cr) AUDIO ~ AC MAINS U (Pb/Cb) VIDEO IN Step 3: Connecting the power cord After everything is connected properly, plug the AC power cord into the power outlet. Never make or change any connections with the power turned on. -
Page 17: Optional Connections
(yellow plug) AUDIO STEREO Audio (red/white plugs) COMPONENT VIDEO OUT DIGITAL OUT Connecting to an Analog Stereo System You can connect this unit to a two channel stereo system (e.g. mini system, analog receiver) in order to enjoy stereo sound output. Connect the audio/video cables (supplied) from the VIDEO OUT (CVBS) AUDIO OUT R/L jack on this... -
Page 18: Getting Started
Getting Started Finding the correct viewing channel Press STANDBY-ON 2 to turn on this unit. Turn on the TV and switch it to the correct video-in channel. You should see the blue DVD background screen. You may go to the lowest channel on your TV, then press the Channel Down button on your TVs remote control until you see the Video In channel. -
Page 19: Audio, Subtitle And Menu Language For Dvd Playback
Audio, Subtitle and Menu language for DVD playback You can select your preferred language settings for DVD playback. If the selected language is recorded on the DVD disc, this unit automatically plays the disc in that language. Otherwise, the disc’s default language will be used instead. -
Page 20: Setting Up Progressive Scan Feature
Getting Started Setting up Progressive Scan feature (for Progressive Scan TV only) The progressive scan displays twice the number of frames per second than interlaced scanning (ordinary normal TV system). With nearly double the number of lines, progressive scan offers higher picture resolution and quality. -
Page 21: Disc Operations
Playable discs This unit plays: – Digital Versatile Discs (DVDs) – Video CDs (VCDs) – Super Video CDs (SVCDs) – Finalized DVD Recordable (DVD±R), DVD Rewritable (DVD±RW) – Audio Compact Discs (CDs) – MP3/ WMA discs – The fi le extension has to be ‘.mp3’, ‘.wma’... -
Page 22: Playing A Disc
Disc Operations Notes: – If the inhibit icon the TV when a button is pressed, it means the function is not available on the current disc or at the current time. – Never put any objects other than discs on the disc compartment. Doing so may cause the disc player to malfunction. -
Page 23: Selecting Various Repeat/Shuffl E Functions
Helpful Hints: – This unit has resume playback ability (for certain type of disc). In this case, if you want to playback from the beginning, press PREV í while the message ‘Play from start, press [ PREV ]’ appears on the TV. –... -
Page 24: Repeating A Specifi C Segment (A-B)
Disc Operations Repeating a specifi c segment (A-B) You can repeat the playback of a specifi c segment within a title/chapter/track. To do this, you must mark the start and end of the segment you want. During playback, press REPEAT A-B at the point where you want the repeat playback to begin. -
Page 25: Zooming In/Out
Zooming in/out This option allows you to zoom in or out the picture on the TV and to pan through the picture. During playback, press ZOOM repeatedly to select a different zoom factor. Playback continues. keys to pan through the zoomed image. -
Page 26: Using Display Menu Options
Disc Operations Using Display menu options This unit can display the disc playback information (for example, title or chapter number, elapsed playing time, audio/ subtitle language), a number of operations can be done without interrupting disc playback. During playback, press DISPLAY. The available disc information appears on the TV. -
Page 27: Preview Function (Vcd/Svcd/Dvd)
For VCD/SVCD Display Descriptions Total/Single Disc or Track elapsed Elapsed playing time. Total/Single Disc or Track remaining Remain playing time. Preview function (VCD/SVCD/DVD) This function allows you to preview the contents of a VCD/SVCD disc. Move to { Preview } in the display menu and press The preview menu appears. -
Page 28: Playing A Divx Disc
Disc Operations Playing a DivX disc This unit supports the playback of DivX movies which you can copy from your computer onto a recordable disc. See ‘Setup Menu Options - { General Setup Page - DivX(R) VOD code }’ for details. Insert a DivX disc. -
Page 29: Playing A Jpeg Image Fi Le (Slide Show)
Playing a JPEG image fi le (slide show) Before you start ... Turn on your TV to the correct Video In channel. See ‘Finding the correct viewing channel’ for details. Insert a JPEG photo CD (Kodak Picture CD, JPEG). For a Kodak disc, the slide show begins automatically. -
Page 30: Playing A Mp3/ Wma Disc
Disc Operations Playing a MP3/ WMA disc This unit can playback most of the MP3 and WMA fi les recorded on a recordable disc or commercial CD. Before you start ... Turn on your TV to the correct Video In channel. -
Page 31: Playing Mp3/Wma Music And Jpeg Pictures Simultaneously
Playing MP3/WMA music and JPEG pictures simultaneously You can create a musical slide show if the disc contains both the MP3/WMA music and JPEG picture fi les. Insert a MP3/WMA disc that contains music and picture folders. Select a track in the menu and press PLAY/PAUSE u to start playback. -
Page 32: Setup Menu Options
Setup Menu Options Accessing the setup menu This unit setup is carried out via the TV, enabling you to customize it to suit your particular requirements. Press SETUP on the remote control. The setup menu appears. keys to select one of the setup menu options and press OK. -
Page 33: General Setup Page
(0 ~ 200 ms) for the audio output and press OK to exit. This feature allows you to adjust the volume level. Access the volume setup menu. Use between 0 ~ 20. Philips provides you with the DivX registration code that allows you to rent or purchase videos ® from DivX VOD service at http://vod.divx.com. -
Page 34: Audio Setup Page
Setup Menu Options Audio Setup Page (underlined options are the factory default settings) Analog output Digital Audio Setup 1_dvp6620_55_eng7_Final2.indd 34 1_dvp6620_55_eng7_Final2.indd 34 (continued) This setting is only required if you have connected the audio output of this unit to a stereo device or TV using the analog output jack. - Page 35 Audio Setup Page (underlined options are the factory default settings) HDMI Audio Setup Sound Mode CD Upsampling 1_dvp6620_55_eng7_Final3.indd 35 1_dvp6620_55_eng7_Final3.indd 35 Setup Menu Options This setting is only required if you are using the HDMI OUT jack to connect your TV or other display device. { On } –...
-
Page 36: Audio Setup
Setup Menu Options Audio Setup Page (underlined options are the factory default settings) Night Mode This mode optimizes playback of sound at low volume. High volume outputs will be softened and low volume outputs will be enhanced to an audible level. This feature is only applicable for DVD video discs with Dolby Digital mode. -
Page 37: Video Setup Page
Video Setup Page (underlined options are the factory default settings) TV Type TV Display Progressive Picture Setting Personal Picture Setup Brightness Contrast Sharpness Color 1_dvp6620_55_eng7_Final2.indd 37 1_dvp6620_55_eng7_Final2.indd 37 Setup Menu Options Select the color system that matches the connected TV. It enables playback of a different type of disc (PAL or NTSC disc) on this unit. - Page 38 Setup Menu Options Video Setup Page (underlined options are the factory default settings) HD JPEG HDMI Video Setup 1_dvp6620_55_eng7_Final2.indd 38 1_dvp6620_55_eng7_Final2.indd 38 (continued) HD JPEG allows you to enjoy untouched and uncompressed pictures at it’s original resolution. This feature is only applicable if you have connected this unit to a HDMI-compatible TV/device.
-
Page 39: Video Setup
Video Setup Page (underlined options are the factory default settings) HDMI Video Setup 1_dvp6620_55_eng7_Final2.indd 39 1_dvp6620_55_eng7_Final2.indd 39 Setup Menu Options Continued... { Resolution } – Select a suitable video resolution depending on the capability of the connected TV/device to further enhance the HDMI/DVI video output. -
Page 40: Preference Setup Page
Setup Menu Options Preference Setup Page Audio Subtitle Disc Menu Parental 1_dvp6620_55_eng7_Final2.indd 40 1_dvp6620_55_eng7_Final2.indd 40 (continued) (underlined options are the factory default settings) Select the preferred audio language for DVDs with multiple sound tracks. Select the preferred subtitle language for DVD playback. Select the preferred disc menu language for DVD playback. -
Page 41: Preference Setup
Preference Setup Page Mp3/Jpeg Nav MP3/JPEG Navigator can only be set if the disc is recorded with a menu. It allows you to select different display menus for easy navigation. { Without Menu } { With Menu } Password The password is used for the Disc Lock and Parental. The default password is ‘136900’. -
Page 42: Other Features
Press numeric keypad ‘55’ on the remote control. Write down the fi le name of your current software. Visit the Philips website ‘www.philips. com/support’ to check the availability of the latest software upgrade and download the software to a CD-R. -
Page 43: Troubleshooting
Do not open this unit as there is a risk of electric shock. If a fault occurs, fi rst check the points listed below before taking this unit for repair. If you are unable to remedy a problem by following these hints, consult your dealer or Philips for help. - Page 44 Troubleshooting Problem (Playback) The unit does not start playback. The aspect ratio of the screen cannot be changed even though you have set the TV display. Cannot activate some features such as Angles, Subtitles, or multi-language Audio. Not able to select some items in the setup/system menu.
-
Page 45: Troubleshooting
Problem (Playback) ® No sound during DivX movies playback. ® An DivX movies does not repeat. ® Certain DivX fi les does not play or are skipped. No audio output from HDMI connection. No video output from HDMI connection. 1_dvp6620_55_eng7_Final2.indd 45 1_dvp6620_55_eng7_Final2.indd 45 Troubleshooting Solution... -
Page 46: Glossary
Glossary Analog audio: Sound that has not been turned into numbers. Analog sound is available when you use the AUDIO LEFT/ RIGHT jacks. These red and white jacks send audio through two channels, the left and right. Aspect ratio: Aspect ratio refers to the length to height ratio of TV. - Page 47 MP3: A fi le format with a sound data compression system. ‘MP3’ is the abbreviation of Motion Picture Experts Group 1 (or MPEG-1) Audio Layer3. By using the MP3 format, one CD-R or CD-RW can contain about 10 times more data than a regular CD.
-
Page 48: Specifi Cations
Specifi cations TV STANDARD (PAL/50Hz) (NTSC/60Hz) Number of lines 625 Playback Multistandard (PAL/NTSC) VIDEO PERFORMANCE Video DAC 12 bit, 108 MHz Y Pb Pr 0.7 Vpp ~ 75 ohm Video Output 1 Vpp ~ 75 ohm VIDEO FORMAT Digital MPEG 2 for DVD, SVCD Compression MPEG 1 for VCD ®... - Page 49 1_dvp6620_55_eng7_Final2.indd 49 1_dvp6620_55_eng7_Final2.indd 49 2007-08-15 3:59:02 PM 2007-08-15 3:59:02 PM...
