- Page 1 Operating instructions DFSE 5/6 | AiroClearCabinet V400 Range hood...
- Page 2 Norm for built-in ap- pliances AiroClearCabinet 61066 AE4H5FE SMS 55 V400 AiroClearCabinet 61067 AE4H6FE EURO 60 V400 Type Product family Size system DFSE5 61028 DFSE6 61029 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2019...
-
Page 3: Table Of Contents
Inhaltsverzeichnis Safety precautions 4 Notes 21 Symbols used............ 4 Service & Support 23 General safety precautions........ 4 Quick instructions 24 Before using for the first time...... 5 Correct use ............. 5 Note on use ............ 5 Appliance description 7 Introduction ............. 7 Extraction mode ............. -
Page 4: Safety Precautions
Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that... -
Page 5: Before Using For The First Time
1 Safety precautions ▪ Avoid a cross-current of air, which Before using for the first could blow the cooking vapours over time the cooking area. ▪ The appliance must be installed and ▪ If other appliances – fired by gas or connected to the electricity supply in other fuels –... - Page 6 1 Safety precautions ▪ When carrying out maintenance work on the appliance, including replacing light bulbs, cut off the electricity supply to the appliance: remove the screw fuse from the holder or switch the circuit breaker off, or disconnect from the mains supply.
-
Page 7: Appliance Description
Appliance description Introduction The appliance is designed for use in the home for extracting cooking odours from above a cooking area and can be used in the extraction or recirculation mode. Extraction mode A fan extracts cooking fumes and smells from above the cooking surface. The metal grease filters clean the extracted air, which is then passed through a connecting pipe fit- ted with an integrated non-return valve and through the air duct to the outside. -
Page 8: Construction
2 Appliance description Construction Flat pull-out deflector plate Grip LED illumination Metal grease filters Operating elements Operating elements Switching the extractor fan off/reducing the power level Switching the extractor fan on/increasing the power level Power level display Intensive level display Switch illumination on/off Reset after-running time/saturation indicator Depending on the model and features, the specification of your appliance may dif-... -
Page 9: Operating The Appliance
3 Operating the appliance Operating the appliance Using for the first time Appliance configuration The model can be used to extract or recirculate air. The appliance is set up ex-factory for use in the extraction mode. If the appliance is to be operated as an extraction model, the saturation indicator for the activated charcoal filter must be deactivated. -
Page 10: Intensive Level
3 Operating the appliance Intensive level ▸ Touch the button repeatedly until (intensive level 3) flashes in the display. ▸ The appliance switches back to level 2 after 5 minutes. ▸ Touch the button to stop the intensive level before the 5 minutes has elapsed. After-running time ▸... -
Page 11: Saturation Indicator
4 Care and maintenance Saturation indicator Metal grease filters (power level) and (intensive level) indicators flash alternatively after 40 operat- ing hours. The saturation level has been reached and the metal grease filters must be cleaned. Long-life and standard activated charcoal filters (power level) and (intensive level) indicators flash simultaneously after 160 op- erating hours. -
Page 12: Metal Grease Filters
4 Care and maintenance Metal grease filters The metal grease filters must be cleaned at least once a month with normal use. If prop- erly cared for, the grease filters should provide years of service. Removing Using both hands, carefully remove the metal grease filters, making sure not to drop or damage them. -
Page 13: Long-Life Activated Charcoal Filter
4 Care and maintenance Resetting the saturation indicator With the appliance switched on, hold the button depressed for 3 seconds to reset the saturation indicator. ▸ The (power level) and (intensive level) displays illuminate for 2 seconds if reset correctly. If both the displays are flashing after the reset, the reason for this is: the metal grease or activated charcoal filters are also dirty and must be cleaned or re- placed. - Page 14 4 Care and maintenance If no dishwasher is available: ▸ Clean the activated charcoal filter mat 3 with hot water and detergent and then soak in hot water in the sink for an hour. Rinse well afterwards. ▸ To reactivate the activated charcoal, the activated charcoal filter mat 3 without the frame 4 must be dried in the oven.
-
Page 15: Standard Activated Charcoal Filter
4 Care and maintenance Standard activated charcoal filter The standard activated charcoal filter is to be replaced after an operating time of 3 to 6 months. Standard activated charcoal filters cannot be washed or regenerated. Disconnect the appliance from the mains and unscrew the fuse for the appliance or switch off the circuit breaker. -
Page 16: Trouble-Shooting
5 Trouble-shooting Trouble-shooting What to do if… ... the illumination is not working Possible cause Solution ▪ Fuse or automatic circuit ▸ Replace the fuse. breaker for electrical installa- ▸ Reset the automatic circuit breaker. tions in the home is defect- ive. -
Page 17: Accessories And Spare Parts
6 Accessories and spare parts Accessories and spare parts Please give model number of the appliance and exact designation of the accessory or spare part when ordering parts. Metal grease filters Long-life activated charcoal filter Standard activated charcoal filter Technical data Electrical connection ▸... -
Page 18: Product Fiche
7 Technical data Product fiche In accordance with EU Regulation No. 65/2014 and No. 66/2014. Description Abbreviations Unit Value Brand V-ZUG Ltd Model identifier 61028+61029 / 61066+61067 Annual Energy Consumption kWh/a 43,4 / 98,0 hood Energy Efficiency Index 51,3 / 96,4... -
Page 19: Disposal
8 Disposal Measured value of the electric power 121,0 / 152,0 input at the best efficiency point Nominal power of the lighting system 5,0 / 5,0 Average illumination of the lighting 145,0 / 381,0 middle system on the cooking surface Sound power level 63,0 / 55,0 Disposal... -
Page 20: Index
Index Before using for the first time....... 5 Correct use ............ 5 Accessories ............17 General ............. 4 Appliance configuration........9 Note on use ............. 5 Appliance description ........7 Saturation indicator.......... 11 Appliance disposal .......... 19 Service & Support..........23 Service agreement........... 23 Switching off ............. - Page 21 Notes...
-
Page 23: Service & Support
Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements. -
Page 24: Quick Instructions
Power level display Intensive level display Switch illumination on/off Reset after-running time/saturation indicator 1020579-R03 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
