Page 1 DECswitch 900EF Router Installation and Configuration Part Number: EK-DEFBA-DN-B01 December 1996 This book explains how to install and configure the DECswitch 900EF module. Revision/Update Information: This is a revised document.
Page 2 Digital Equipment Corporation makes no representations that the use of its products in the manner described in this publication will not infringe on existing or future patent rights, nor do the descriptions contained in this publication imply the granting of licenses to make, use, or sell equipment or software in accordance with the description.
Page 3: Table Of Contents
What is the DECswitch 900EF Router?........
Page 4 EasyStart ..............1-7 2 Installing the Module Overview .
Page 5 [3] Set Out-of-Band Interface IP Address ........4-11 [4] Set Default Gateway .
Page 6 Delete ..............6-8 Modify .
Page 7 B Connector and Pin Assignments Overview ..............B-1 Introduction.
Page 8 Table C-2Connectors for the DECswitch 900EF ........
Page 9: Preface
Overview Purpose of This Document This manual describes how to install the DECswitch 900EF Router in either a DEChub 900 MultiSwitch or a DEChub ONE or DEChub ONE-MX docking station. This manual also describes how to configure the DECswitch 900EF Router software to operate in either a DEChub 900 MultiSwitch or as a standalone module in a DEChub ONE or DEChub ONE-MX docking station.
Page 10: Organization
Organization This manual is organized as follows. Chapter Description Provides an overview of the DECswitch 900EF Router and describes its features. Describes the front and back panel features and provides instructions for installing the module in a DEChub 900 MultiSwitch.
Page 11: Conventions
Conventions Conventions Overview This book uses the following conventions. Convention Description Bold Boldface type in example indicates user input. This special type in examples indicates system output or user Special Type output. <Return> Indicates that you should press the Return key.
Page 12: Associated Documents
Associated Documents Associated Documents The following documents provide information relating to the module. To order any of the following documents, refer to the directions at the end of this preface. Title and Order Description Number Bridging Describes bridging methods, operational features of Configuration bridging, configuration methods and basic Guide...
Page 13 Associated Documents Title and Order Description Number DEChub 900 Provides installation, use, security, and troubleshooting MultiSwitch Owner’s information for the DEChub 900 MultiSwitch. Manual EK-DH2MS-OM DEChub ONE Provides installation and operation guidelines for Installation standalone module configuration, including mounting EK-DEHU2-IN options and cabling.
Page 14: Correspondence
To read the Bulletin Board System, set your modem to 8 bits, no parity, 1 stop bit and dial 508-486-5777 (U.S.) The Digital Equipment Corporation Network Products Business Home Page on the World Wide Web is located at the following addresses: North America: http://www.networks.digital.com...
Page 15: How To Order Additional Documentation
P.O. Box CS2008 Puerto Rico) Nashua, New Hampshire 03061 (Place prepaid orders from Puerto Rico with the local Digital subsidiary: 809-754-7575) By Mail DIGITAL EQUIPMENT of CANADA LTD. (Canada) 940 Belfast Road Ottawa, Ontario, Canada K1G 4C2 Attn.: A&SG Business Manager Internationally DIGITAL EQUIPMENT CORPORATION Attn.: A&SG Business Manager...
Page 17: Safety
Safety Overview Any warning or caution that appears in this manual is defined as follows:. WARNING Contains information to prevent personal injury. CAUTION Contains information to prevent damage to equipment. VORSICHT Enthält Informationen, die beachtet werden müssen um den Benutzer vor Schaden zu bewahren. ACHTUNG Enthält Informationen, die beachtet werden müssen um die Gerate vor Schaden zu bewahren...
Page 18 The cautions that must be observed for the hardware described in this manual are listed below in English, German, French, and Spanish. CAUTION This action deletes all configured settings and replaces them with factory default values. All configuration settings will be lost. ACHTUNG Bei diesem Vorgang werden alle Konfigurationseinstellungen gelöscht und die...
Page 19: Product Description
Chapter 1 Product Description Overview Introduction This chapter describes the DECswitch 900EF Router product and its features. In this chapter Topic Page What is the DECswitch 900EF Router? Features Product Description 1-1...
Page 20: What Is The Decswitch 900Ef Router
What is the DECswitch 900EF Router? What is the DECswitch 900EF Router? The DECswitch 900EF Router (also referred to in this manual as the module) provides multiprotocol routing and switching. This module interconnects networks that have both routable and nonroutable protocols. It routes some protocols while switching others.
Page 21: Features
Features Features Your DECswitch 900EF Router module includes the following features. Hot Swap The module’s hot swap capability allows you to install or remove the module from a DEChub 900 without turning off the power. Configuration and Management The following configuration and management options are available: •...
Page 22: Routing Protocols
Features Routing Protocols The following routing protocols are supported: • IP protocols, which are as follows: –– OSPF (Open Shortest Path First) –– RIP (Routing Information Protocol) –– BGP-4 (Border Gateway Protocol) –– EGP (Exterior Gateway Protocol) –– IS-IS (Integrated Intermediate System to Intermediate System) ––...
Page 23: Virtual Lan Support
Features Virtual LAN Support The DECswitch 900EF can bridge a protocol within a virtual LAN while concurrently routing the protocol between virtual LANs. A virtual LAN (VLAN) is a set of switch ports. A port can be a member of only one VLAN.
Page 24: Snmp
Features SNMP The complete MIB-II is provided with the exception of ifInNUcastPkts, ifOutNUcastPkts, and the TCP group. SNMP Gets and Traps are supported for the following RFCs. • Structure and Identification of Management Information for TCP/IP-based Internets (RFC 1155) • SNMP management (RFC 1157) •...
Page 25: Fddi/Ethernet
Features FDDI/Ethernet FDDI and Ethernet support is as follows: • One FDDI dual attachment station (DAS) port and six 802.3/Ethernet LAN ports. • Translation between FDDI and IEEE 802.3/Ethernet frame formats for direct, transparent connections; translation of AppleTalk 1 and AppleTalk 2 AARP packets;...
Page 27: Installing The Module
This chapter describes the front and back panel components of the DECswitch 900EF Router and tells you how to install the DECswitch 900EF Router in a DEChub 900 MultiSwitch. To install a module in a DEChub ONE docking station refer to the DEChub ONE Installation manual.
Page 28: Module Components
Module Components Module Components The following sections describe the front and back panel components for the DECswitch 900EF Router. Table 2-1 describes the front panel components, including LEDs, that are illustrated in Figure 2-1. Table 2-2 describes the back panel components as illustrated in Figure 2-2. For problem-solving information using the LEDs, refer to Appendix A.
Page 29: Front Panel Features
Front Panel Features Front Panel Features Table 2-1describes the front panel features and LEDs that are shown in Figure 2-1. Table 2-1: Front Panel LEDs and Connections Item Icon Name Description Power Indicates the module has power. Module Indicates the module passed self-test. OK LED Off = failed self-test.
Page 30 Front Panel Features Item Icon Name Description OBR (6- Allows you to connect an Optical Bypass Relay pin MJ) (OBR) device (not supplied) to maintain connector connectivity of the FDDI ring in the absence of power or during fault conditions in a station. WARNING To prevent personal injury or equipment damage, do not insert telecommunications cables into the...
Page 31: Figure 2-1Front Panel
Front Panel Features Figure 2-1: Front Panel NPG-9548-95F Installing the Module 2-5...
Page 32: Back Panel Features
Front Panel Features Back Panel Features The features on the back panel (Figure 2-2) of the DECswitch 900EF Rout- er are listed in Table 2-2. Table 2-2: Back Panel Feature Descriptions Item Name Description Locking tab Locks the module into the DEChub 900 and engages the power switch.
Page 33: Figure 2-2Back Panel Layout
Front Panel Features Figure 2-2: Back Panel Layout NPG-9723-95F Installing the Module 2-7...
Page 34: Installing The Module In A Dechub 900
Installing the Module in a DEChub 900 Installing the Module in a DEChub 900 The DECswitch 900EF Router hot-swap feature allows you to install the module into the DEChub 900 without turning off power. Seating the module initiates the module’s powerup sequence if enough power is available.
Page 35: Task 1: Compare The Power Ratings
Task 1: Compare the Power Ratings Task 1: Compare the Power Ratings Compare the module’s power ratings (1) with the values shown in the Hub Manager Status display (2) (see Figure 2-3). If the power values on the module’s manufacturing label do not exceed the values shown in the Hub Manager status display, go to Task 2.
Page 36: Task 2: Seat The Module Into The Dechub 900
Task 2: Seat the Module into the DEChub 900 Task 2: Seat the Module into the DEChub 900 To seat the module, perform the following steps (refer to Figure 2-4). Step Action Place the module’s mounting tab into a mounting slot (1) on the DEChub 900.
Page 37: Task 3: Verify Initial Led Operation
After the module completes self-test, the Module OK LED lights and remains lit. Then the Hub Manager status display shows: Slot <slot-number> DECswitch 900EF up. NOTE Refer to Appendix A, Problem Solving if the LEDs do not operate as described.
Page 38: Task 4: Connect The Cables
Task 4: Connect the Cables Task 4: Connect the Cables Depending on your network configuration requirements, connect the appropriate FDDI cables, AUI cables, and UTP/STP cables. See your network manager if you are not sure which cables to connect. NOTE All cables should be installed, tested, and tagged at the site, prior to this installation.
Page 39: Task 4 (Cont.): Connect The Fddi Cable
Task 4: Connect the Cables Task 4 (Cont.): Connect the FDDI Cable To connect the FDDI cable, complete the following steps (see Figure 2-5). Step Action Remove the protective caps from the module’s FDDI connector and from the FDDI cable plug. Align the keyway on the FDDI cable plug with the key on the module’s FDDI connector.
Page 40: Task 4 (Cont.): Connect The Aui Cable
Task 4: Connect the Cables Task 4 (Cont.): Connect the AUI Cable To connect the AUI cable, complete the following steps (see Figure 2-6). Step Action Remove the loopback plug (if present) from the module’s AUI connector and from the AUI cable plug. Push the module’s AUI connector slide latch up (1) to the unlocked position.
Page 41: Task 4 (Cont.): Connecting The Utp/Stp Cable
Task 4: Connect the Cables Task 4 (Cont.): Connecting the UTP/STP Cable The DECswitch 900EF Router module uses straight-through 10BaseT (8-pin MJ) port connectors. Select the appropriate UTP/STP cable type (crossover or straight-through) to ensure that the module’s transmit/receive signals connect correctly to the transmitter/receiver of the connected device.
Page 42: Figure 2-7Utp/Stp Cable Connection
Task 4: Connect the Cables To connect the UTP/STP cables, complete the following steps (see Figure 2-7). Step Action Align the release tab on the cable plug (1) with the keyway on the module’s 10BaseT port connector. Insert the plug into the connector (2), ensuring that the release tab snaps into the locked position.
Page 43: Installing The Setup Port Cable
Chapter 3 Installing the Setup Port Cable Overview Introduction This chapter describes how to connect the DECswitch 900EF Router module to the setup port on a DEChub 900 MultiSwitch or a DEChub ONE docking station. In this chapter Topic Page...
Page 44: Signaling Standards
Signaling Standards Signaling Standards Signals from the DEChub 900 Hub setup port and from the DEChub ONE docking station setup port conform to the EIA-232D signaling standard at 9600 baud. To the user, the port appears as a data terminal equipment (DTE) device. 3-2 Installing the Setup Port Cable...
Page 45: Setup Port Device Cabling
Setup Port Device Cabling Setup Port Device Cabling The setup port (see Figure 3-1) on the DEChub 900 MultiSwitch or the DEChub ONE docking station can be connected to a setup port device (a terminal or personal computer), using the following cables and adapters: If the setup port Use this cable With this adapter...
Page 46: Connecting The Setup Port
Connecting the Setup Port Connecting the Setup Port To connect the setup port on the DECswitch 900EF module, complete the following steps: Step Action Ensure that the transmit and receive baud rates on the setup port device are set with the following parameters:...
Page 47: Figure 3-1Device, Cable And Connector Identification
Connecting the Setup Port Figure 3-1: Device, Cable and Connector Identification DEChub ONE DEChub 900 Multiswitch DEChub ONE-MX H8571-J BN24H H8575-A NPG-0020-95F After all cables are connected, go to one of the following sections. Go to Configure the Router in a DEChub ONE Chapter 4 Configure the Router in a DEChub 900 Chapter 5...
Page 49: Configuring The Module In A Standalone Unit
Chapter 4 Configuring the Module in a Standalone Unit Overview Introduction This chapter describes how to setup and configure your DECswitch 900EF Router when it is installed as a standalone unit. In this chapter Topic Page Accessing the Setup Port...
Page 50: Accessing The Setup Port
The setup port provides menus that allow you to access the DECswitch 900EF Router. These menus allow you to setup the module for basic connectivity. After the initial setup, you can configure the module software using a command-based interface.
Page 51: Using Menus To Setup The Module
Using Menus to Setup the Module Using Menus to Setup the Module This section describes the options that are available from the DECswitch 900EF/ MP INSTALLATION MENU when the module is installed in the DEChub ONE docking station. When the module powers up, the EasyStart feature begins to run. See the Distributed Routing Software guides for more information.
Page 52 Using Menus to Setup the Module If the module was previously configured, or it is configured for any non-IP protocol and without bridging, the following menu options are available. DECswitch900EF/MP ================================================================== DECswitch900EF/MP INSTALLATION MENU ************************************************************** To fully manage this device telnet to one of the following IP addresses or select item [3] below.
Page 53: Restart With Factory Defaults
EasyStart messages may appear on the console device. See the Distributed Routing Software guides for more information about the EasyStart feature. The DECswitch 900EF/MP INSTALLATION MENU menu appears. Configuring the Module in a Standalone Unit 4-5...
Page 54: Restart With Current Settings
[2] Restart with Current Settings [2] Restart with Current Settings This option restarts the module but leaves the module’s configured nonvolatile configuration storage parameters at their current values. The module should restart in less than one minute. The following example shows the dialog associated with this option. Enter selection: DECswitch900EF/MP =============================================================...
Page 55: Show Current Settings
[3] Show Current Settings [3] Show Current Settings This option shows the module’s current settings. If the module is being configured for the first time, some of the fields will be blank. The following example shows the dialog associated with this option. Enter selection : 3 DECswitch900EF/MP ===================================================================...
Page 56: Configure Ip
[4] Configure IP . . . [4] Configure IP . . . The IP Configuration option provides you with 5 selections. The following example shows the dialog associated with this option. Enter selection: 4 DECswitch900EF/MP ================================================================== IP CONFIGURATION * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * *Configuration will not take effect until module is *restarted.
Page 57: Set Snmp Read/Write Community
[4] Configure IP . . . [1] Set SNMP Read/Write Community This option prompts you to enter the module’s SNMP read/write community name. The following example shows the dialog associated with this option. Enter selection: DECswitch900EF/MP ================================================================== SET SNMP READ/WRITE COMMUNITY Format: The format for a community name is a string, consisting of 4 to 31 printable ASCII characters, that describes the relationship between an SNMP...
Page 58: Set In-Band Interface Ip Address
[4] Configure IP . . . [2] Set In-Band Interface IP Address This option prompts you to change or enter the IP address and subnet mask for the in- band interface. You can only configure one in-band interface at a time. The module does not need to be configured with a subnet mask for SNMP and Telnet communications with management stations located on the same subnet as the module.
Page 59: Set Out-Of-Band Interface Ip Address
DEChub ONE docking station as an alternative to normal in-band management. To enable out-of-band management, you need to assign an OBM IP address and select an OBM port speed from the DECswitch 900EF/MP INSTALLATION MENU. The module does not need to be configured with a subnet mask for SNMP and Telnet communications with management stations located on the same subnet as the module.
Page 60: Set Default Gateway
[4] Configure IP . . . [4] Set Default Gateway This option sets the default gateway address, if necessary, for the in-band interface. This is the address of a router that the module will use when communicating to a remote host. The default gateway address must be an address in the same subnet as your in-band address.
Page 61: Configure Out-Of-Band Port
[5] Configure Out-of-Band Port . . . [5] Configure Out-of-Band Port . . . This option lets you set the out-of-band port speed. NOTE The port speeds at both ends of the communications link must be identical. The following example shows the dialog associated with this option. Enter selection: 5 DECswitch900EF/MP ==================================================================...
Page 62: Set Port Speed
[5] Configure Out-of-Band Port . . . [1] Set Port Speed This option lets you select the out-of-band port speed. The factory default for this option is 9600 baud. The OBM port speed that you select must match the speed of your OBM device.
Page 63: Go To Local Console
If you type RESTART at the Config (only)> prompt, the following message appears: Are you sure you want to restart the gateway? (Yes [No]): Enter yes to proceed.The DECswitch 900EF/MP Installation Menu is then displayed. Configuring the Module in a Standalone Unit 4-15...
Page 64: Go To Local Console (Commands)
Go To Local Console [3] Go To Local Console (Commands) If you have configured the module, then the following installation menu appears. Select [3] Go To Local Console to modify the configuration or to monitor the module. DECswitch900EF/MP ========================================================== DECswitch900EF/MP INSTALLATION MENU * * * * * * * * * * * * * * * * * * * * * * * * * * * * * To fully manage this router Telnet to one of its IP addresses or select item [3] below.
Page 65: Configuring The Module In A Dechub 900
Chapter 5 Configuring the Module in a DEChub 900 Overview Introduction This chapter describes how to configure your DECswitch 900EF Router when it resides in a DEChub 900 MultiSwitch. In this chapter Topic Page Accessing the Setup Port DEChub 900 MultiSwitch Installation Menu...
Page 66: Accessing The Setup Port
The setup port provides menus that allow you to access the DECswitch 900EF Router. These menus allow you to setup the module for basic connectivity. After the initial setup, you can configure the module software using a command-based interface.
Page 67 Boldface type in the screen display examples indicates user input. To access the setup menus, press the Return key on the setup port device until the DECswitch 900EF/MP INSTALLATION MENU appears. To configure the module using Go to the section titled...
Page 68: Dechub 900 Multiswitch Installation Menu
DEChub 900 MultiSwitch Installation Menu DEChub 900 MultiSwitch Installation Menu The following screen is an example of the DEChub 900 MultiSwitch INSTALLATION MENU. To access the module’s set up screen, you must choose option [9] Start Redirect Mode. DEChub 900 MultiSwitch ============================================================= DEChub 900 MultiSwitch INSTALLATION MENU Reset with Factory Defaults...
Page 69: Start Redirect Mode
900EF/MP INSTALLATION MENU, the screen display prompts you for a slot number (8) as shown in the following example. After you enter the number of the slot in which the DECswitch 900EF Router is installed, the console is redirected to this slot.
Page 70: Using Menus To Setup The Module
Using Menus to Setup the Module Using Menus to Setup the Module This section describes the options that are available from the DECswitch 900EF/MP INSTALLATION MENU when the module is installed in the DEChub 900 MultiSwitch. The following example shows the menu options available when the module is setup with factory defaults.
Page 71 DECswitch900EF/MP - slot 8 ============================================================= DECswitch 900EF/MP INSTALLATION MENU * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * To fully manage this router telnet to one of the * following IP addresses or select item [3] below.
Page 72: Restart With Factory Defaults
[1] Restart with Factory Defaults [1] Restart with Factory Defaults This option restarts the module, causing the module’s configured nonvolatile configuration storage parameters to be initialized to factory default values. (To retain current values, use option [2] Restart with Current Settings.) Allow approximately one minute for the module to restart and complete self-test.
Page 73: Restart With Current Settings
[2] Restart with Current Settings [2] Restart with Current Settings This option restarts the module but leaves the module’s configured nonvolatile configuration storage parameters at their current values. NOTE Allow approximately 1 minute for the module to Restart. The following example shows the dialog associated with this option. Enter selection: DECswitch900EF/MP - slot 8 =============================================================...
Page 74: Show Current Settings
[3] Show Current Settings [3] Show Current Settings This option shows the module’s current settings. If the module is being configured for the first time, some of the fields will be blank. The following example shows the dialog associated with this option. Enter selection : 3 DECswitch900EF/MP - slot 8 =================================================================...
Page 75: Ip Configuration
[4] IP Configuration [4] IP Configuration The IP Configuration option provides you with 5 selections. The following example shows the dialog associated with this option. Enter selection: 4 DECswitch900EF/MP - slot 8 ================================================================== IP CONFIGURATION * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * *Configuration will not take effect until module is *restarted.
Page 76: Set Snmp Read/Write Community
[4] IP Configuration [1] Set SNMP Read/Write Community This option prompts you to enter the module’s read/write community name. The following example shows the dialog associated with this option. Enter selection: DECswitch900EF/MP - slot 8 ================================================================== SET SNMP READ/WRITE COMMUNITY Format: The format for a community name is a string, consisting of 4 to 31 printable ASCII characters, that describes the relationship between an SNMP...
Page 77: Set In-Band Interface Ip Address
[4] IP Configuration [2] Set In-Band Interface IP Address This option prompts you to change or enter the IP address and subnet mask for the in- band interface. The module does not need to be configured with a subnet mask for SNMP communications with management stations located on the same subnet as the module.
Page 78: Set Out-Of-Band Interface Ip Address
[4] IP Configuration [3] Set Out-of-Band Interface IP Address This option prompts you to change or enter the IP address and subnet mask for the out- of-band interface. The module does not need to be configured with a subnet mask for SNMP communications with management stations located on the same subnet as the module.
Page 79: Set Default Gateway
[4] IP Configuration [4] Set Default Gateway This option sets the default gateway, if necessary. This is the address of a router that the module will use when communicating to a remote host. The default gateway address must be in the same subnet as your in-band address. The following example shows the dialog associated with this option.
Page 80: Go To Local Console
Go to Local Console Go to Local Console This option lets you configure the module.You must configure the module before it is operational. The Go to Local Console option provides two different configuration methods, depending on whether the module has been setup with factory defaults or has been previously configured.
Page 81: Go To Local Console (Qconfig)
DECswitch900EF/MP - slot 8 ============================================================= DECswitch 900EF/MP INSTALLATION MENU * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * To fully manage this router telnet to one of the * following IP addresses or select item [3] below.
Page 82: Go To Local Console (Commands)
DECswitch900EF/MP - slot 8 ============================================================= DECswitch 900EF/MP INSTALLATION MENU * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * To fully manage this router telnet to one of the * following IP addresses or select item [3] below.
Page 83: Configuration Commands
Chapter 6 Configuration Commands Overview Introduction After you have installed the DECswitch 900EF Router, you will need to configure the following. • FDDI Port • Ethernet Port • OBM Port • VLAN Interfaces The instructions provided in this chapter describe how to setup and configure these ports and interfaces.
Page 84: Accessing Configuration Commands
Accessing Configuration Commands Accessing Configuration Commands This section describes configuration commands that are unique to the DECswitch 900EF Router. To begin configuring the module, at the * prompt enter the following command: * talk 6 To configure the module using CONFIG commands, refer to the following sections. Option Page Configuring FDDI Port Connection...
Page 85: Configuring Fddi Port Connection
Configuring FDDI Port Connection Configuring FDDI Port Connection You can redirect the FDDI port only if the module is configured in a DEChub ONE- MX. To redirect the FDDI front and back ports, perform the following steps when prompted: Step Action Config>...
Page 86: Configuring Ethernet Port Connection
Configuring Ethernet Port Connection Configuring Ethernet Port Connection You can configure Ethernet port 4 only if the module is configured in a DEChub ONE. To configure Ethernet Port 4 for front (connector on the front of the module) or back (connector on the DEChub ONE) connection, perform the following steps when prompted:.
Page 87: Configuring Obm Port
Configuring OBM Port Configuring OBM Port You can configure the OBM port only if the module is configured in a DEChub ONE. To set the OBM port IP address and speed, perform the following steps when prompted: Step Action Config> set obm ip OBM address: [0.0.0.0]? 16.40.156.20 This is the out-of-band management port IP address.
Page 88: Configuring Virtual Lans
Configuring Virtual LANs Configuring Virtual LANs To create a virtual LAN, you must complete the following tasks: 1) Create a VLAN, providing a name and a list of bridge ports that will be included in the VLAN. A virtual interface (VI) number and a VLAN number are assigned to the VLAN.
Page 89: (Help)
Configuring Virtual LANs Creating, Deleting, and Modifying VLANs This section describes how to create, delete, and modify the Virtual LANs. The maximum number of VLANs is 7. The maximum number of ports is 7. To configure the virtual LAN interface, perform the following steps when prompted: Step Action Config>...
Page 90: Delete
Configuring Virtual LANs Syntax create vlan name [ports] port-list name must be a maximum of 32 ASCII characters, including at least one alphabetic character. VLAN names must be unique. port-list is a list of bridge ports that you want to include in the VLAN. You must specify valid bridge ports.
Page 91: List
Configuring Virtual LANs new-port-list is a list of bridge ports that you want to include in the VLAN. You must specify valid bridge ports. To add bridge ports, return to the ASRT Config> prompt and use the add port command. If you delete a bridge port which is in a VLAN, it will be removed from the VLAN.
Page 92: Assigning Frame Types To Vlans
Configuring Virtual LANs Assigning Frame Types to VLANs You must assign a frame type to each VLAN interface that you create. To assign a frame type to a VLAN, perform the following steps when prompted: Step Action Config> net vlan-interface-number Where vlan-interface-number is a valid VLAN number from 7-13.
Page 93: Assigning Ipx Encapsulation To Vlan Ports
Configuring Virtual LANs Frame Type Description Use If VLAN Contains..ETHERNET_SNAP Uses the 802.2 format with a Ethernet ports SNAP header. This only. encapsulation type is meant to be compatible with token ring SNAP encapsulation. However, it violates IEEE standards and is not interoperable across conformant bridges.
Page 95: Monitoring Commands
Overview Introduction This chapter describes commands used to monitor your DECswitch 900EF Router when it is installed in either a standalone unit DEChub ONE docking station or a DEChub 900 MultiSwitch. You should only use this chapter if the module has been previously configured.
Page 96: To Exit Monitor Mode
Monitoring FDDI Port Connection Monitoring Ethernet Port Connection Monitoring Virtual Interfaces Other monitoring commands that are used in the DECswitch 900EF Router can be found in the Network Interface Operating Guide. To Exit Monitor Mode To exit monitor mode and return to the * prompt, type control/p at the + prompt.
Page 97: Listing All Interfaces
Listing All Interfaces Listing All Interfaces To get a list of all interfaces (maximum of 13) in the module, perform the following step when prompted:. Step Action + int A list of interfaces and their type (FDDI, Ethernet, or virtual LAN) appears. The listing includes information about the number of self-tests and maintenance tests each interface has passed or failed.
Page 98: Monitoring Fddi Port Connection
Monitoring FDDI Port Connection Monitoring FDDI Port Connection To monitor an FDDI port connection, perform the following step when prompted:. Step Action + int 0 The following example shows a typical FDDI configuration. Self-Test Self-Test Maintenance Nt’ Interface Passed Failed Failed FDDI/0 FDDI/IEEE 802.2 MAC/data-link on FDDI interface...
Page 99: Monitoring Ethernet Port Connection
Monitoring Ethernet Port Connection Monitoring Ethernet Port Connection To monitor an Ethernet port connection, perform the following step when prompted:. Step Action + int ethernet-interface-number Where ethernet-interface-number is one of the valid Ethernet interfaces 1 - 6. The following example shows a typical Ethernet configuration. + int 2 Self-Test Self-Test...
Page 100: Monitoring Virtual Interfaces
Monitoring Virtual Interfaces Monitoring Virtual Interfaces Displaying VLAN Configurations To display a VLAN connection, perform the following step when prompted:. Step Action + int virtual-interface-number Where virtual-interface-number is a valid VI number from 7 - 13. The following example shows a typical VLAN configuration. + int 8 Self-Test Self-Test...
Page 101: Listing Vlan Connections
Monitoring Virtual Interfaces Listing VLAN Connections To list one or more VLANs, complete the following steps when prompted: Step Action + p asrt ASRT> vlan VLAN> list vlan vlan-number or list all Where vlan-number is the number assigned to the VLAN when it was first created.
Page 102: Listing A Virtual Interface
Monitoring Virtual Interfaces The following example shows a display for all VLANs. +p asrt ASRT> vlan VLAN> list all Name Ports VI Number Unconfigured boston salem chelsea hudson acton newport weston Listing a Virtual Interface To list information about a virtual interface, perform the following steps when prompted: Step Action...
Page 103: Removing The Module
Removing the Module Overview Introduction This chapter describes how to remove the DECswitch 900EF Router from a DEChub 900 MultiSwitch. To remove the DECswitch 900EF Router from a standalone module, refer to the DEChub ONE Installation manual. In this chapter...
Page 104: Removing The Cables
Removing the Cables Removing the Cables WARNING Some fiber optic equipment can emit laser or infrared light that can injure your eyes. Never look into an optical fiber or connector port. Always assume the cable is connected to a light source. To remove cables from the module, complete the step in the following table that is appropriate for your type of cable (see Figure 8-1).
Page 105: Figure 8-1Cable Removal
Removing the Cables Figure 8-1: Cable Removal NPG-0109-95F Removing the Module 8-3...
Page 106: Unseating The Module
Unseating the Module Unseating the Module To unseat the module from the DEChub 900, complete the following steps (see Figure 8-2). Step Action Lift the release lever (1) located at the top of the DEChub 900 slot. While holding up the release lever (2), pivot the module back on its bottom mounting tab (3).
Page 107: A Problem Solving
Appendix A Problem Solving Overview Introduction This appendix describes how to diagnose and solve problems with the module using the LED displays. In this appendix Topic Page LED Descriptions Problem Solving Using LEDs Problem Solving A-1...
Page 108: Led Descriptions
LED Descriptions LED Descriptions The module’s LEDs provide dynamic indications of the status of the module. The LEDs can be in various states (on, off, or flashing), and can change color (green or yellow) depending on the operational status of the module or the level of activity on the network.
Page 109: Table A-1Module Led States
LED Descriptions Table A-1 shows the states that are possible for each of the module’s LEDs. Table A-1: Module LED States On (Yellow) Flashing Name (Green) Power No power to Module module. receiving power. Passed Non-fatal Module Self-test failed (if self-test failure.
Page 110: Problem Solving Using Leds
Problem Solving Using LEDs Problem Solving Using LEDs When diagnosing a problem with the module, note that the problem is often indicated by the combined states of the module’s LEDs. Table A-3 lists the typical combined states of the LEDs for various error conditions that can occur during initial installation of the device, along with probable causes and corrective actions to take.
Page 111 Problem Solving Using LEDs Symptom Probable Cause Corrective Action Port State LED is 1. Connection is bad Correct the cable connection. off. (loose, or incorrect cable). 2. Port not None — normal operation. connected. Port State LED is Port failure. Either replace the module or contact your service on yellow.
Page 113: B Connector And Pin Assignments
Appendix B Connector and Pin Assignments Overview Introduction This appendix shows the pin assignments of the connectors, cables, and adapters that are part of, or can be used with, the module. In This Chapter Topic Page Connector Assignments Internal and External Crossover Configurations Connector and Pin Assignments B-1...
Page 114: Connector Assignments
Connector Assignments Connector Assignments Optical Bypass Relay (6-pin MJ) Connector The Optical Bypass Relay (OBR) feature on the module maintains FDDI dual-ring integrity if the module fails or if the power to the module is turned off. The following illustration shows the OBR 6-pin Modular Jack (Shielded RJ12) connector and its pin assignments.
Page 115: 10Baset (8-Pin Mj) Port Connector
Connector Assignments 10BaseT (8-pin MJ) Port Connector This section shows the 8-pin MJ (straight-through) connector and its pin assignments. Table B-2: 10BaseT Port Connector Pin Assignments Pin No. Assignment Unused Unused Unused Unused NOTE All 10BaseT port connectors on the module are straight-through connections. Figure B-2: 10BaseT Port Connector NPG-8719-95F Connector and Pin Assignments B-3...
Page 116: Aui (15-Pin D-Sub) Port Connector
Connector Assignments AUI (15-pin D-Sub) Port Connector This section shows the 15-pin AUI connector and its pin assignments. Table B-3: AUI Port Connector Pin No. Port Ground Ground Power rtn Ground Ground Power 12V Ground B-4 Connector and Pin Assignments...
Page 117: H8571-J Adapter
Connector Assignments Figure B-3: AUI Port Connector NPG-0222-95F H8571-J Adapter This section shows the H8571-J adapter (6-pin MMJ to 9-pin D-Sub connector) and its pin assignments. Figure B-4: H8571-J Adapter 9D-Sub(F) 6MMJ NPG-5342-95F Connector and Pin Assignments B-5...
Page 118: H8575-A Adapter
Connector Assignments H8575-A Adapter This section shows the H8575-A adapter (6-pin MMJ connector to 25-pin D-Sub connector) and its pin assignments. Figure B-5: H8575-A Adapter 25 D-Sub(F) 6 MMJ H8575-A NPG-8793-95F NOTE EOS/ESD protection devices are not shown in the illustration. B-6 Connector and Pin Assignments...
Page 119: Internal And External Crossover Configurations
(2) for connecting crossover (3) and straight-through (4) types of devices.Figure B-7 shows straight-through cables (1) for connecting these devices. The DECswitch 900EF Router uses straight-through connectors. If screened cabling is required, use BN26M. Figure B-6: External Crossover Configurations...
Page 121: C Product Specifications
Appendix C Product Specifications Overview Introduction This appendix lists the operating specifications and the acoustical specifi- cations for the DECswitch 900EF Router. In this chapter Topic Page Operating Specifications Connectors Acoustical Specifications Product Specifications C-1...
Page 122: Operating Specifications
Operating Specifications Operating Specifications Table C-1 lists the product specifications for the module. Table C-1: Product Specifications Parameter Specification Environment 5° C to 50° C (41 ° F to 122 ° F) Operating Temperature Relative Humidity 10% to 95% noncondensing Altitude •...
Page 123 Operating Specifications Parameter Specification Shock (Class A/B for products 10 G / 10 ms half sine pulse in three weighing under 100 lbs) orthogonal axes Vibration (Class C) 5 to 200 Hz sine sweep @ 0.25 G limited by 0.02" (0.5mm) displacement DA* 200 to 500 Hz sine sweep @ 0.10 G Certification...
Page 124: Connectors
Connectors Connectors Table C-2 lists connectors for the DECswitch 900EF. Table C-2: Connectors for the DECswitch 900EF Connectors Quantity Dual Attachment Station (DAS) FDDI port multimode optics (ANSI MIC). Shielded 6-pin MJ (OBR), 15-pin D-Sub (AUI ports), Shielded 8-pin MJ (10BaseT ports) with straight through connectors Table C-3 lists connectors for the DEChub ONE-MX.
Page 125: Acoustical Specifications
DECswitch 900EF & DEChub ONE-MX DEFBA-MA + DEF1H Current values for specific configurations are available from Digital Equipment Corporation representa- tives. 1 B = 10 dBA Schallemissionswerte Werteangaben nach ISO 9296 und ISO 7779/DIN EN27779 Table C-6: Aktuelle Werte für spezielle Produkt...
Page 127: Index
Index Numbers DEChub ONE C-4 DEChub ONE-MX C-4 10BaseT connector 2-4 2-15 DECswitch 900EF C-4 160-pin connector 2-6 Optical Bypass Relay (OBR) 2-4 48-pin connector 2-6 DAS FDDI port connector 2-4 Acoustical specifications C-5 DEChub 900 installation menu options German C-5...
Page 128 using commands to redirect 6-3 Module components 2-3 FDDI support 1-7 Module setup Features using menus 4-3 bridging 1-4 Monitor mode configuration 1-3 accessing 7-2 EasyStart 1-7 exiting 7-2 Ethernet support 1-7 FDDI support 1-7 hot swap 1-3 management 1-3 configuring 6-5 routing protocols 1-4 Operating specifications...
Page 129 accessing 4-2 support 1-5 connecting 3-4 virtual interface (VI) number 6-7 6-10 Setup port cabling 3-3 virtual LAN (VLAN) number 6-7 Signaling standards 3-2 SNMP support 1-6 Specifications acoustical C-5 operating C-2 Standalone installation menu options Configure IP 4-8 Configure Out-of-Band Port 4-13 Go to Local Console 4-15 Out-of-Band Port Speed 4-14 Restart with Current Settings 4-6...

Digital Equipment DECswitch 900EF Installation And Configuration Manual

Preface

Safety

1 Product Description

2 Installing the Module

3 Installing the Setup Port Cable

4 Configuring the Module in a Standalone Unit

5 Configuring the Module in a Dechub 900

6 Configuration Commands

7 Monitoring Commands

8 Removing the Module

A Problem Solving

B Connector and Pin Assignments

10 Baset (8-Pin MJ) Port Connector

C Product Specifications

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digital Equipment DECswitch 900EF

Summary of Contents for Digital Equipment DECswitch 900EF

Table of Contents
