- Page 1 In-ceiling Housing Installation Manual SHP-1680F...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Overview What’s Included Installation Instructions How to install (XNP-6120/HCP-6120 SERIES) How to install (XNV-6120 SERIES/XNV-6085 SERIES) How to install (XND-6085/XND-6085V SERIES) Product Specifications 2_ English... -
Page 3: Overview
OVERVIEW This In-CEILING HOUSING is a mounting ADAPTOR that is designed to mount the smart dome camera in built-in style on a double-layer ceiling. WHAT’S INCLUDED HOUSING SAFETY BRACKET (1EA) SAFETY WIRE (1SET) LOWER BRACKET TEMPLATE (1EA) SCREW (3EA) (for XNV-6120/XNV-6085/ XND-6085/XND-6085V) (1EA) INSTALLATION MANUAL English _3... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Select an installation position or place that can endure more than 4 times of the total weight of the installation structure. 2. At least 250mm or more of spare height is required above the CEILING BOARD. 3. CEILING BOARD’s thickness should be less than 40mm. 4. - Page 5 2. Fix the ANCHOR BOLT onto the concrete CEILING, and secure the SAFETY WIRE to the ANCHOR BOLT as below: ❶ Tighten the nut (“N1”) on the ANCHOR BOLT. ➋ Insert the provided SAFETY BRACKET into the ANCHOR BOLT. ➌ Tighten two nuts (“N2”,”N3”) onto the ANCHOR BOLT.
- Page 6 4. Push the HOUSING inside the CEILING through the CEILING hole, and tighten the SCREWs (x2) clockwise to fix the HOUSING on the CEILING. (The BRACKET will be positioned from <A> to <B> as shown.) Ensure that the HOUSING is firmly secured to the CEILING BOARD. BRACKET BRACKET HOUSING...
- Page 7 6. Remove the safety wire that is connected to the dome cover and camera body, and connect it inside of the dome cover as shown in the picture. Driver Camera body Safety wire Driver ➔ Dome Safety wire Dome cover 7.
- Page 8 8. Connect the camera to the bracket placed in the housing using the screws (3 EA). Reconnect the cover by turning the three bolts on the dome cover clockwise using the L wrench. CEILING HOUSING 9. Attach the COVER to the HOUSING. HOUSING COVER 8_ English...
-
Page 9: How To Install (Xnv-6120 Series/Xnv-6085 Series)
HOW TO INSTALL (XNV-6120 SERIES/ XNV-6085 SERIES) 1. Place the TEMPLATE on the CEILING BOARD and drill a guided hole. ❶ Remove the round filling (“C”) from the TEMPLATE. ➋ Place the TEMPLATE A onto the CEILING BOARD to which you will attach the CEILING mount ADAPTOR and drill a Ø213mm hole. - Page 10 3. Fix the ANCHOR BOLT onto the concrete CEILING, and secure the SAFETY WIRE to the ANCHOR BOLT as below: ❶ Tighten the NUT (“N1”) on the ANCHOR BOLT. ➋ Insert the provided SAFETY BRACKET into the ANCHOR BOLT. ➌ Tighten two NUTs (“N2”,”N3”) onto the ANCHOR BOLT.
- Page 11 4. To connect to the camera, insert the external cable through the side hole on the housing to the inside of the housing as shown in the figure. Refer to the installation manual of the camera that you want to install, and prepare necessary cables for camera connection.
- Page 12 6. As shown in the figure, pull out the protrusions of the rubber cap in the bottom to make a small hole and remove the cable through it to connect to the external cable. Alarm Cable Power Audio If waterproofing in the connected cable jacket is poor, it may cause leaks. Make sure you tape it tight and thoroughly.
- Page 13 7. Connect the camera to the bracket placed in the housing using the screws (3 EA). Reconnect the cover by turning the three bolts on the dome cover clockwise using the L wrench. 8. Attach the COVER to the HOUSING. Housing COVER English _13...
-
Page 14: How To Install (Xnd-6085/Xnd-6085V Series)
HOW TO INSTALL (XND-6085/XND-6085V SERIES) 1. Place the TEMPLATE on the CEILING BOARD and drill a guided hole. ❶ Remove the round filling (“C”) from the TEMPLATE. ➋ Place the TEMPLATE A onto the CEILING BOARD to which you will attach the CEILING mount ADAPTOR and drill a Ø213mm hole. - Page 15 3. Fix the ANCHOR BOLT onto the concrete CEILING, and secure the SAFETY WIRE to the ANCHOR BOLT as below: ❶ Tighten the NUT (“N1”) on the ANCHOR BOLT. ➋ Insert the provided SAFETY BRACKET into the ANCHOR BOLT. ➌ Tighten two NUTs (“N2”,”N3”) onto the ANCHOR BOLT.
- Page 16 4. To connect to the camera, insert the external cable through the side hole on the housing to the inside of the housing as shown in the figure. Refer to the installation manual of the camera that you want to install, and prepare necessary cables for camera connection.
- Page 17 6. Connect the camera to the bracket placed in the housing using the screws (3 EA). Reconnect the cover by turning the three bolts on the dome cover clockwise using the L wrench. In case of XND-6085, it can be assembled by pushing it without using bolts. 7.
-
Page 18: Product Specifications
PRODUCT SPECIFICATIONS Item Specifications Dimension (mm) D232 X H135.5 Weight 605g Temperature -10°C ~ 55°C Material Color Ivory 18_ English... - Page 19 MEMO English _19...
- Page 20 Head Offi ce 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwha-security.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom...
