Federal Signal Corporation FHLP-TAH Manual

2562580A REV. A 910

Safety Message to Installers of Federal Signal Products

People's lives depend on your proper installation of our products. It is important to read, understand, and
follow all instructions shipped with this product and the related add-on products. In addition, listed below are
some other important safety instructions and precautions you should follow:
• To properly install this equipment, you must have a good understanding of automotive electrical
procedures and systems, along with proficiency in the installation and use of safety warning equipment.
• Do not install equipment or route wiring in the deployment path of an airbag. Failure to observe this
warning will reduce the effectiveness of the airbag or potentially dislodge the equipment, causing serious
injury to you or others.
• To be an effective warning device, an emergency warning system produces bright light that can be
hazardous to your eyesight when viewed at a close range. Do not stare directly into the lights at a close
range or permanent damage to your eyesight may occur.
• If a vehicle seat is removed, verify with the vehicle manufacturer if the seat needs to be recalibrated for
proper airbag deployment.
• When drilling into a vehicle structure, be sure that both sides of the surface are clear of anything that
could be damaged. Remove all burrs from drilled holes. To prevent electrical shorts, grommet all drilled
holes through which wiring is run.
• Never attempt to install aftermarket equipment that connects to the vehicle wiring without reviewing a
vehicle wiring diagram available from the vehicle manufacturer. Insure that your installation will not effect
vehicle operation or mandated safety functions or circuits. Always check the vehicle for proper operation
after installation.
• Locate the controls so the VEHICLE and CONTROLS can be operated safely under all driving conditions.
• The flasher should be frequently inspected to ensure that it is operating properly and that it is securely
attached to the vehicle.
• File these instructions in a safe place and refer to them when installing and/or reinstalling the product.
Failure to follow all safety precautions and instructions may result in property damage, serious injury, or death.

Overview of the Model FHLP-TAH

The Model FHLP-TAH Headlight Flasher is a solid-state plug-in flasher designed for installation in 2007 and
newer models of the Police Package Chevrolet™ Tahoe 2007 and newer. The plug-in flasher operates from
+9 Vdc to 16 Vdc with a 55 W load output on each of two outputs. In addition, the flasher activates factory-
integrated tail light flashers. The Model FHLP-TAH has built-in shutdown protection against short circuit, loss
of ground, over-temperature, and reverse polarity.
Along with the PowerPulse™ flash pattern, the Model FHLP-TAH features High-Beam Override and
Nighttime Cutoff. In addition, when the high-beam switch is activated, the High-Beam Override (HBOR)
function of the flasher interrupts the flashing sequence to allow use of the high-beams. The HBOR function is
automatically disabled when the high-beam switch is de-activated, allowing the headlight flasher to resume
operation.
Model FHLP-TAH Headlight Flasher for the
Police Package Chevrolet Tahoe (2007+)
