Introduction Safety Information/Useful Tips ... 3 Before Calling Service ... 4 Basic Installation/Functions Hooking Up Your TV (Basic Connection) ... 5 Use/Care of remote Control ... 5 Connecting the Audio/Video Sockets (Playback) ... 6 Connecting the Audio/Video Sockets (Recording) ... 6 Functions of Remote Control ...
AFETY Safety Information • Disconnect mains plug when : – the red light below the TV screen is flashing continuously. – a bright white line is displayed across the screen. – cleaning the TV screen. Never use abrasive cleaning agents. Use a slight damp chamois leather or soft cloth.
EFORE Below is a list of frequently occurred symptoms. Before you call for service, make these simple checks. Some of these symptoms can easily be rectified if you know what to do. Symptom Colour patch (uneveness) No power No picture Good picture but no sound Good sound but poor...
OOKING UP 5-9/29061/E TV (B ASIC ONNECTION Antenna Connection • Connect the aerial plug to the antenna socket ¬ on the backcover. • Insert the mains plug into the wall socket. Mains Connection • For correct mains voltage, refer to type sticker at the rear of the TV set •...
ONNECTING THE UDIO IDEO OCKETS LAYBACK You can view the playback of VCR tapes (Video Disc players, camcorders, etc.) by using the AUDIO and VIDEO INPUT sockets on the rear of the TV. – Connect the VIDEO and AUDIO IN sockets on the rear of the TV to the AUDIO and VIDEO OUT sockets on the VCR.
Page 7
UNCTIONS OF & Power button – Switch set off temporarily to standby mode. (The red light indicator lights up when the set is on standby mode). – To switch on set from standby mode, press Channel +/– , Digit (0 -9) or Power button. é...
UNCTIONS OF 5-9/29061/E EMOTE ONTROL 2 A/V Button Allows you to select the AV channels. Frownie button Allows to delete stored personal preference channels in your Personal Preference list. For detailed description of functions, refer to section on “Personal Zapping ”. 4 Smart Picture Button Press the Smart Picture button repeatedly to access 5 different types of picture settings and...
UNCTIONS OF & é “ & Mains Power button é Standby light indicator “ Remote Sensor ˝ ˙ ‘ Volume buttons ¸ ˚ Channel buttons Note • You can enter the main menu by pressing both the Volume˝ and˙buttons at the same time.
ELECTING THE Operating instructions generally explains the operation of the TV set using the buttons on the remote control unless otherwise stated. Please read the following instructions carefully and follow the steps as shown to familiarise yourself with the installations and all features available in your set.
UTOMATIC Automatic tuning of channels allows you to store each programme automatically. Step Press button Enter main menu. Press button repeatedly until ¸ Install is selected. ˙ Enter install menu. Select Auto Store. ¸ Start automatic tuning of ˙ channels. When tuning is completed, exit menu from screen.
ANUAL Manual tuning of channels allows you to select your preferred channel number for every available programme. Step Press button Enter main menu. Press button repeatedly until ¸ Install is selected. ˙ Enter install menu. Press button repeatedly until ¸ Manual Store is selected.
Page 13
Step Press button ˙ ¸ ¸ ˙ 10-18/29061/E ANUAL UNING OF HANNELS HANNELS Start manual searching. Searching stops once a transmitting signal is found. Select Channel. Key in the channel number. Press button repeatedly until Store is selected. Store tuned channel. Note : If you want to continue searching for another transmitting...
ELECTING THE This feature allows you to select your desired Colour and Sound system. If Auto is selected, the respective colour and sound system will be automatically selected according to the transmission system. Note : Select your desired colour and sound system manually if reception is poor at Auto mode.
This feature allows you to adjust picture reception in areas of weak reception. Step Press button ¸ ˙ ¸ ˙ ¸ ˙ ˝ ¸ ˙ 10-18/29061/E UNING OF HANNELS Enter main menu. Press button repeatedly until Install is selected. Enter install menu. Press button repeatedly until Manual Store is selected.
This feature rearranges channel numbers. Step Press button Enter main menu. Press button repeatedly until ¸ Install is selected. ˙ Enter install menu. Press button repeatedly until ¸ Sort is selected. ˙ Enter sort mode. Select the channel number you want ¸...
This feature allows you to skip or edit channels which have bad or weak TV signal or channels that you do not watch often. Note : Once a channel is skipped, you cannot have access to it by the CH (Channel) + or – button. You can only have access to the channel by the Digit (0 -9) buttons.
This feature enables you to name or rename channels. Step Press button Enter main menu. Press button repeatedly until ¸ Install is selected. Enter install menu. ˙ Press button repeatedly until ¸ Name is selected. Enter name mode. ˙ Select the channel you want to ˚...
The picture menu allows you to make adjustments to the picture. Step Press button Display the main menu on screen. ˙ Enter Picture menu. Select item. ˚ ¸ Adjust level or select desired ˝ setting. ˙ Exit menu from screen. Picture menu items Brightness Colour...
DJUSTING THE The sound menu allows you to make adjustments to the sound. Step Press button Display the main menu on screen. ¸ Select Sound menu. ˙ Enter Sound menu. ˚ Select item. ¸ ˝ Select On or Off. ˙ Exit menu from screen.
The Timer feature allows you to set the timer to switch to another channel at a specified time while you are watching another channel or when the TV is on standby mode. Note : For the timer to function, the set must not be switched off. Once the set is switched off, the timer is disabled.
Page 22
Step Press button Select Stop Time. ¸ Key in the time you want the programme to be switched off. Select Channel. ¸ Key in the channel you want to switch to. ¸ Select Activate. ˙ Activate timer. You can select Once, Daily or Off.
CTIVATING THE The Child Lock feature allows you to lock channels to prevent your children from watching programmes you deem undesirable. Note : You can only have access to the locked channels via the remote control. Keep the remote control out of reach so as to prevent your children from having access to it. Step Press button Display the main menu on screen.
Page 24
CTIVATING THE Note : You need to key the access code only once. Step Press button Repeat Steps 1 to 8 as in “A CTIVATING THE HILD )” CCESS ¸ ˙ 21-27/29061/E HILD HANGE The Child Lock menu will Child Lock ✔...
Page 25
CTIVATING THE Step Press button Repeat Steps 1 to 8 as in “C Lock (A HILD CCESS )” ˙ ˚ ¸ ˙ 21-27/29061/E HILD Child Lock The Child Lock menu will ✔ Lock Channel π now appear. You can proceed to lock channel.
Page 26
CTIVATING THE You can choose to lock all channels in the Lock All mode in the Child Lock menu. Step Press button Repeat Steps 1 to 8 as in “C Lock (A HILD CCESS )” ¸ ˙ CTIVATING THE To unlock channels that you have locked, enter the Child Lock menu and select the Off option in the Clear All mode.
You can have a choice of two formats for your viewing pleasure, namely : - 4:3 mode and the EXPAND 4:3 mode through the FORMAT menu. Step Press button Display the main menu on screen. Press button repeatedly until ¸ Features is selected.
MART Whether you are watching a movie or video game, your TV has automatic video control settings matched to your current program source or content. The Smart Picture feature quickly resets your TV’s video controls of program for a number of different types of programs and viewing conditions you may have in your home.
Whether you are watching a movie or video game, your TV has automatic sound control settings matched to your current program source or content. The Smart Sound feature quickly resets your TV’s sound controls of program for a number of different types of programs and viewing conditions you may have in your home.
A list or series of favourite TV programs can be selected and stored in the 4 coloured buttons with the Personal Zapping feature. With this feature you can easily viewed up to a total of 10 preferred channels for each coloured button. Adding Channels to the Favourite list Step Press button...
Picture tube screen size Picture tube visible area Audio Output : Speaker TV System Playback System Set Dimensions : Width Depth Height Net Weight of Set (approximate ) Note For Operating Voltage, Frequency, Power Consumption and Version Number, refer to the type number at the rear of the set.
