Summary of Contents for Black Box LH1703A-SC-US
- Page 1 © Copyright 2003. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
- Page 2 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
- Page 4 FCC AND IC RFI STATEMENTS FEDERAL COMMUNICATIONS COMMISSION INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference...
- Page 5 100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
- Page 6 NOM STATEMENT 10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros aparatos (incluyendo amplificadores) que producen calor. 11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como se indique en el aparato.
- Page 7 100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS TRADEMARKS USED IN THIS MANUAL ST is a registered trademark of AT&T. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
-
Page 8: Table Of Contents
Troubleshooting ......21 5.1 Calling Black Box....21... -
Page 9: Specifications
1. Specifications NOTE In this manual (except where noted otherwise): • LH1703A-ST represents models LH1703A-ST-US, LH1703A-ST-EU, LH1703A-ST-UK, LH1703A-ST-AU, and LH1703A-ST-JP. • LH1703A-SC represents models LH1703A-SC-US, LH1703A-SC-EU, LH1703A-SC-UK, LH1703A-SC-AU, and LH1703A-SC-JP. • LH1704A-SC represents models LH1704A-SC-US, LH1704A-SC-EU, LH1704A-SC-UK, LH1704A-SC-AU, and LH1704A-SC-JP. - Page 10 CHAPTER 1: Specifications User Controls: (1) Button for MDI/MDI-X connection; (1) DIP switch for Link Fault Signaling (LFS) and Loopback Test (LBK) Connectors: LH1703A-ST: (1) RJ-45, (2) ST ® (1) barrel connector for Power; LH1703A-SC, LH1704A-SC, LH1705A-SC: (1) RJ-45, (2) SC, (1) barrel connector for Power Indicators: (7) LEDs: (2) Link, (2) Receive, (1) Full Duplex, (1) Link Fault Signaling, (1) Power Temperature Tolerance:...
- Page 11 100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS Power: All models: External power supply: Output: 12 VDC @ 0.8 A; LH1703A-ST-US, LH1703A-SC-US, LH1704A-SC-US, LH1705A-SC-US: Input: 120 VAC, 60 Hz (2-prong); LH1703A-ST-EU, LH1703A-SC-EU, LH1704A-SC-EU, LH1705A-SC--EU: Input: 230 VAC, 50 Hz (2-prong); LH1703A-ST-UK, LH1703A-SC-UK, LH1704A-SC-UK, LH1705A-SC--UK: Input: 230 VAC, 50 Hz (3-prong);...
-
Page 12: Introduction
CHAPTER 2: Introduction 2. Introduction 2.1 Description The 100BASE-TX to 100BASE-FX Media Converter Plus connects your twisted-pair Fast Ethernet to multimode or single-mode fiber without adding to your repeater count. These converters are unique because they support Link Fault Signaling (LFS) and Loopback (LBK). Link Fault Signaling allows constant connectivity to the network by diverting data transmission to a redundant link when a breakdown or error exists anywhere along the fiberoptic... - Page 13 100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS • LH1703A-SC: Choose this model to extend your Fast Ethernet network up to 1.2 mi. (2 km) over 820-nm multimode fiberoptic cable using SC connectors. • LH1704A-SC: Use this converter to extend your 100-Mbps Ethernet network up to 9.3 mi. (15 km) over 1310-nm single-mode fiberoptic cable via SC connectors.
-
Page 14: What The Package Includes
CHAPTER 2: Introduction Figure 2-2. 100BASE-TX to 100BASE-FX Media Converter Plus with SC connectors. 2.2 What the Package Includes • (1) 100BASE-TX to 100BASE-FX Media Converter Plus • (1) AC adapter • (4) Non-skid rubber feet • (2) Mounting screws •... -
Page 15: Installation
100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS 3. Installation 3.1 MDI/MDI-X Connection Before plugging in and installing your media converter, you’ll need to set the MDI/MDI-X button. This button selects whether you need to use crossover or straight- through twisted-pair cabling to connect the RJ-45 ports on the 100BASE-TX portion of your network. -
Page 16: Dip-Switch Setting
CHAPTER 3: Installation Table 3-1. Crossover selection. Connected Device Cable Configuration Setting Hub or switch Straight-through MDI-X Hub or switch Crossover DTE (NIC) Straight-through DTE (NIC) Crossover MDI-X 3.2 DIP-Switch Setting Once you’ve set the MDI/MDI-X button, you’ll need to set the LFS/LBK switch. - Page 17 100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS Table 3-2. LFS/LBK DIP-switch setting. Switch Setting Description Link Fault Signaling (LFS) Enables Link Fault Signaling mode. Set the LFS switch ON when a redundant link configuration exists. Disables Link Fault Signaling mode. Set the LFS switch OFF when a redundant link configuration does not exist.
-
Page 18: Typical Applications
CHAPTER 3: Installation 3.3 Typical Applications Once you’ve set the MDI/MDI-X button and the LFS/LBK DIP switch, you’ll need to determine which application you’ll use. See Figures 3-3 through 3-5. 1: T LAN S XAMPLE WITCH ORKGROUPS 328 ft. 328 ft. 328 ft. - Page 19 100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS 2: A LAN S XAMPLE WITCH AND A ETWORK ERVER 328 ft. 328 ft. 328 ft. (100 m) (100 m) (100 m) 328 ft. Fast Ethernet switch (100 m) 100BASE-TX to 100BASE-FX Media Converters Plus Server Multimode fiber cable, half duplex...
-
Page 20: Installing The Converter
CHAPTER 3: Installation 3.4 Installing the Converter After you set the MDI/MDI-X button as described in Section 3.1, set the LFS/LBK DIP switch as explained in Section 3.2, and determine how you will use your converter as shown in Section 3.3, you’ll need to place the converter on a desktop or mount it on a wall. - Page 21 100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS 3. Power on the converter. The power LED should light. If it does not, make sure that the power cable is plugged in properly. 4. Make sure that the Category 5 straight-through twisted-pair cable between the 100BASE-TX device (hub or switch) and the converter is no longer than 328 ft.
-
Page 22: Led Indicators
CHAPTER 4: LED Indicators 4. LED Indicators Once your 100BASE-TX to 100BASE-FX Media Converter Plus is properly installed, it operates maintenance-free. Several LEDs tell you the status of the converter and the network at a glance. See Figures 4-1 and 4-2. Figure 4-1. - Page 23 100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS Figure 4-2. LEDs on the converter with SC connectors. • The Power LED (located on the side of the converter) lights to indicate normal operation. • (2) Link LEDs light when receiving link pulses from a compliant device.
-
Page 24: Troubleshooting
Media Converter Plus is malfunctioning, do not attempt to alter or repair the unit. It contains no user-serviceable parts. Contact Black Box at 724-746-5500. Before you do, make a record of the history of the problem. We will be able to provide more efficient and... -
Page 25: Shipping And Packaging
100BASE-TX TO 100BASE-FX MEDIA CONVERTERS PLUS 5.2 Shipping and Packaging If you need to transport or ship your 100BASE-TX to 100BASE-FX Media Converter Plus: • Package it carefully. We recommend that you use the original container. • If you are shipping the media converter for repair, make sure you include everything that came in the original package.
