Juniper QFX5220-128C Quick Start Manual page 9

[edit]
root@# set system root-authentication plain-text-password
New password: password
Retype new password: password
6. (Optional) Configure the name of the switch. If the name includes spaces, enclose the name in quotation marks (" ").
[edit]
root@# set system host-name host-name
7. Configure the IP address and prefix length for the switch management interface.
[edit]
root@# set interfaces re0:mgmt-0 unit 0 family inet address address/prefix-length
CAUTION:
the same subnet, only one interface is usable and supported.
NOTE: On the QFX5220-128C, the management port re0:mgmt-0 is the bottom RJ-45 port on the right side
of the port panel and is labeled MGMT.
8. Create the mgmt_junos routing instance.
[edit]
root@# set routing-instances mgmt_junos
9. Configure the static routes to remote prefixes with access to the management port.
[edit]
root@# set routing-options static route remote-prefix next-hop destination-ip
10. Enable the management instance.
[edit]
root@# set system management-instance
11. Enable telnet service.
[edit]
root@# set system services telnet
Although the CLI permits you to configure two management Ethernet interfaces within
9
