  • Page 1 Brand Logo Specs (REV D) 20160329 Logo font: Helvetica Neue LT Std 75 Bold = PANTONE P 48-16 C (OR EQUIVALENT) = PANTONE P 179-11 C (OR EQUIVALENT) uAvionix Ping20Si Transponder Q U I C K S T A R T G U I D E...
  • Page 2 Mount The ping20si GPS antenna requires a clear view of the sky for proper operation. Avoid placing the device directly under props or near features that could ‘shadow’ or block the GPS antenna during flight. Avoid installing the ping20si under any signal blocking materials such as carbon fiber.
  • Page 3 Place the antenna in a location that will be least obstructed by the aircraft during normal flight. Connect power harness to ping20si. Connect the free end of the harness to a 3S battery or appropriate aircraft power source.
  • Page 4 Install Install the uAvionix Ping App from the Apple App Store or Google Play. Search for uAvionix Ping Installer or use the QR codes below. ping Programmer ping20Si Connect the using the provided JST ZHR-5-4 pin cable. The 5 pin connector should be connected ping to the transponder.
  • Page 5 Join Join your mobile device to the wireless network named Ping-XXXX using the procedure for your device. If a WPA uavionix. passphrase is required enter The process for iOS is shown below. Go to Settings > Wi-Fi, and verify Wi-Fi is turned on.
  • Page 6 Configure uAvionix Ping Configuration. Launch the application and tap Complete all fields as appropriate for your aircraft. Selected Device Type: ping200s/20s. Choose Control: Select a default power up mode. Standby: Transponder will not respond to interrogation. Replies to interrogation with 4 digit squawk code.
  • Page 7 A GPS fix is not necessary for programming but is required to monitor latitude longitude and GPS altitude. Disconnect power from ping20si Disconnect ping Programmer from ping20si. ping20si will not transmit if the ping Programmer...
