Toshiba SD-P120DTKE Owner's Manual

Portable tv/dvd player

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

PORTABLE TV/DVD PLAYER

SD-P120DTKE

OWNER'S MANUAL

DIGITAL VIDEO

SD-P120DTKE_ENG_01-68.indd 1

Introduction

Preparations

TV viewing

Playback

Function Settings

Connections

Others

PX1D00002741

2008/07/04 12:04:12

Table of Contents

Summary of Contents for Toshiba SD-P120DTKE

Page 1 PORTABLE TV/DVD PLAYER SD-P120DTKE OWNER’S MANUAL DIGITAL VIDEO SD-P120DTKE_ENG_01-68.indd 1 SD-P120DTKE_ENG_01-68.indd 1 Introduction Preparations TV viewing Playback Function Settings Connections Others PX1D00002741 2008/07/04 12:04:12 2008/07/04 12:04:12...
Page 2: Safety Precautions
SAFETY PRECAUTIONS WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. CAUTION: This equipment employs a Laser System.
Page 3 “This product is marked with “CE” and complies therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC and the EMC Directive 2004/108/EC.” Responsible for CE-marking is TOSHIBA INFORMATION SYSTEMS (U.K.) LTD, Toshiba Court, Weybridge Business Park, Addlestone Road Weybridge, Surrey, KT15 2UL U.K.
Page 4 SAFETY PRECAUTIONS Location of the required label Following information is only for EU-member states: The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This unit is fully transistorized and does not contain any parts that can be repaired by the user. DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
Page 6 IMPORTANT SAFETY INSTRUCTIONS ADDITIONAL SAFETY INSTRUCTIONS 13. When you use headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage. 14. Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a risk of ﬁ...
Page 7 Take the battery pack to an authorized Toshiba service provider. f) Keep the battery pack away from heat or ﬁ re. 2008/01/17 19:14:18...
Page 8 IMPORTANT SAFETY INSTRUCTIONS g) Never dispose of used battery packs with other ordinary solid wastes, since they contain toxic substances. Always dispose of used battery packs in accordance with community regulations that apply to the disposal of batteries. Cover the metal terminals with insulating tape, in order to prevent accidental short-circuiting.
Page 9 29. After unpacking coin-shaped batteries, store them in poly bags, etc. separately one by one when unused. If you leave them unwrapped, they may be short- circuited by contact with metal objects, resulting in battery leakage, heat or bursting. This may cause burns or injury.
Page 10: Precautions
Precautions Notes on handling Do not shock the LCD monitor. It may cause unit damage and malfunction. Do not use the player in a place subject to vibration. Neglecting this may cause malfunction of the player or damage to the disc. Do not leave the player in a vehicle.
Page 11 Notes on moisture condensation Moisture condensation damages the player. Please read the following carefully. Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass. In the same way, moisture may condense on the optical pick-up lens inside this unit, one of the most crucial internal parts of the player.
Page 12 Precautions (Continued) Notes on products incorporated laser system This product incorporates laser system. For proper and safe use of this product, read this owner’s manual carefully, and keep near at hand for future reference. When you need any repair of this product, consult the dealer where you purchased this product.
Page 13 Exemptions Toshiba is not liable for any damage caused by ﬁ res, earthquake, etc., uses by a third person, accidents, owner’s intentional or unintentional misuse, or uses in other improper conditions. Toshiba is not liable for incidental damages (such as proﬁ...
Page 14: Table Of Contents
Table of contents Introduction SAFETY PRECAUTIONS ... 2 IMPORTANT SAFETY INSTRUCTIONS ... 5 Precautions ... 10 Identiﬁ cation of Controls ... 16 Accessories ... 19 Notes and Information ... 20 Playable discs ...20 Preparations Preparation of the remote control ... 26 Installation ...
Page 15 Playing a desired scene ... 54 Skipping chapters or tracks ... 54 Locating by entering numbers ... 54 Marking the desired position to locate (Bookmark function) ...55 Playing in random order ... 56 Playing repeatedly ... 56 Repeating a speciﬁ c segment ...56 Repeating a title, chapter or track ...57 Playing in a favourite order ...
Page 16: Identiﬁ Cation Of Controls
Identiﬁ cation of Controls Main Unit See page in for details. Handle 27 LCD monitor Speakers Stand 27 SD-P120DTKE_ENG_01-68.indd 16 SD-P120DTKE_ENG_01-68.indd 16 Instructions and actual buttons Most instructions are based on remote control operation, unless otherwise noted. You can use the buttons on the remote control and those on the main unit as well when they have the same function.
Page 17 Left side Antenna jack 28 To connect an aerial HDMI terminal 79 Connect to HDMI output terminal of your HDMI equipment AV in jack 80 Connect to AV output terminal of your video equipment AV out jack 78 Connect to AV input terminal of your TV BITSTREAM/PCM jack 81 Connect to Digital input terminal...
Page 18 Identiﬁ cation of Controls (Continued) Remote control See page in for details. EPG button* POWER button MUTE button* EXIT button* WIDE button* FAVOURITE button* Number buttons REV button SLOW button* Direction buttons SKIP button buttons DISPLAY button MODE button MENU button TOP MENU button SUBTITLE button AUDIO button...
Page 19: Accessories
Accessories Check that the following accessories are supplied. Remote control (MEDR120BX) Audio/video cable Coin-shaped battery (CR2025) Battery pack* (SD-PBP120E) Headphones * Do not use an AC adapter, a power cord, and a battery pack other than one speciﬁ ed. Also, do not use these supplied accessories with any device other than this player. SD-P120DTKE_ENG_01-68.indd 19 SD-P120DTKE_ENG_01-68.indd 19 Power cord*...
Page 20: Notes And Information
Notes and Information Playable discs This player can play the following discs. Disc Disc Mark Disc Size DVD Video 12cm disc DVD-RW 12cm DVD-R 12cm Video CDs 12cm DIGITAL VIDEO Audio CDs 12cm CD-ROM 12cm CD-R/RW 12cm R e W r i t a b l e is a trademark of DVD Format/Logo Licensing Corporation.
Page 21 • Depending on the data recording method or the disc status, playback on this player may not be possible, even if the disc is labeled as those on the previous page. Toshiba cannot assure that all discs bearing the DVD or CD logos will operate as expected.
Page 22 Notes and Information (Continued) On handling discs Do not touch the playback side of the disc. Do not attach paper or tape to discs. On cleaning discs Fingerprints and dust on the disc may cause picture and sound deterioration. Wipe the disc from the centre outwards with a soft cloth.
Page 23 Saving data • It is recommended that you back up your memory card data. Toshiba is not liable for any damage caused by the use of any memory card with this player. Toshiba will not compensate for any lost data or recording(s) caused by the use of such cards.
Page 24 Notes and Information (Continued) Notices for use Ensure that you insert the memory card correctly into this player. Do not eject the memory card while it is in use. If ejected while in use information on the memory card may be lost. This memory card is a precision electrical instrument.
Page 25: Preparations
Preparations Preparations before using. ● Preparation of the remote control ● Installation ● Antenna connection ● Power connection ● Using the battery pack ● Powering on/off ● Changing the mode ● Using “Quick Menu” SD-P120DTKE_ENG_01-68.indd 25 SD-P120DTKE_ENG_01-68.indd 25 2008/03/11 11:30:59 2008/03/11 11:30:59...
Page 26: Preparation Of The Remote Control
Preparation of the remote control Insert the speciﬁ ed battery in the remote control. See page 8 , for safe use of coin-shaped batteries. Gently insert a ﬁ ngernail in groove 1 and pull out the holder in direction 2. Backside Take care not to break your ﬁ...
Page 27: Installation
Installation Read page 5 - 10 to secure a safe position. Handle Install on a smooth, level surface. Keep this strap stretched. Notes • Be careful not to damage the LCD when moving the player. • Do not hang or suspend the player. SD-P120DTKE_ENG_01-68.indd 27 SD-P120DTKE_ENG_01-68.indd 27 Open the stand.
Page 28: Antenna Connection
Antenna connection Aerial Aerial cable (not supplied) The tip of the outdoor aerial is sharp and can inﬂ ict injury such as puncture wounds. Be careful when handling it. CAUTION • Keep the supplied outdoor leads away from children. There is a danger of suffocation through strangulation.
Page 29: Power Connection
Power connection Connect the supplied AC adapter to wall outlet as below. Follow steps 1 to 3 to connect. When disconnecting, reverse this order. AC adapter Connect the supplied AC adapter and the power cord ﬁ rmly. To wall outlet Power cord SD-P120DTKE_ENG_01-68.indd 29 SD-P120DTKE_ENG_01-68.indd 29...
Page 30: Using The Battery Pack
Using the battery pack The supplied battery pack (lithium ion battery pack) can power the player for operation outdoors or in a place with no outlets. WARNING • Do not use a battery pack other than one speciﬁ ed as it can result in a ﬁ...
Page 31 Important • Detach the battery pack from the player if not used for prolonged periods. ■ Charging the battery pack The battery pack needs to be charged before use. (The battery indicator is shown in the upper left corner of the screen when the power in the battery pack is running low.) Perform a full charge before the ﬁ...
Page 32 Using the battery pack (Continued) ■ Detaching the battery pack Turn the player off. Disconnect the AC adapter and the power cord from the player. Turn the player upside down and lift the stand. Slide the battery pack’s lock switch in the direction of the arrow 1, then detach the battery pack in the direction of the arrow 2.
Page 33: Powering On/Off
Powering on/off Turning the power on/off Press POWER on the main unit. STAND-BY Power button indicator When the power turns on, STAND-BY indicator turns green. To turn the power off, press POWER on the main unit. Note • Turning on by POWER always sets the player in DTV mode.
Page 34: Changing The Mode
Changing the mode You can enjoy various contents of discs, the digital TV and other external equipment by changing the mode. Change it depending on your needs. Press MODE repeatedly to select the mode. Each time you press MODE, the mode changes on the screen as below. Select when you want to watch the digital TV broadcasting.
Page 35: Using "Quick Menu
Using “Quick Menu” When you want to change settings, open “Quick Menu”, a list of functions which are available in the current mode. It can be operated in the same manner in any mode. Press QUICK. “Quick Menu” appears. The contents may vary depending on the mode. e.g.
Page 36 SD-P120DTKE_ENG_01-68.indd 36 SD-P120DTKE_ENG_01-68.indd 36 2008/01/17 19:14:26 2008/01/17 19:14:26...
Page 37: Tv Viewing
TV viewing ● Preparation for TV viewing ● TV view operations ● System settings SD-P120DTKE_ENG_01-68.indd 37 SD-P120DTKE_ENG_01-68.indd 37 2008/01/17 19:14:26 2008/01/17 19:14:26...
Page 38: Preparation For Tv Viewing
Preparation for TV viewing Initial setup When you ﬁ rst use the DTV, the unit shows the language menu for initial setting. Follow through this process to search channels available in your area. Turn the power on. The language menu will appear in a few seconds. Press to select the desired language listed in the menu, and then...
Page 39 Channel scanning ■ Automatic channel scan If any menu screen doesn’t show up at the ﬁ rst use of this unit (see “Initial setup”), you can search channels by automatic channel scan. Also, you can add new channels to the channel list. 1 Press SET UP to display the main menu.
Page 40: Tv View Operations
TV view operations Channel selection You can select channels by the following ways: 1 Press 2 Press number buttons on the remote control. • e.g. To select 2 channel Press 2 • e.g. To select 56 channel Press 5 6 (Within about 1 second) To adjust the volume +/–...
Page 41 To adjust brightness of the LCD You can adjust the brightness of the LCD. Press DIMMER while pressing SHIFT. Each time you press DIMMER, the brightness level changes from 1 (dark) to 4 (bright). To set sleep timer This unit can be turned off automatically by setting a sleep time.
Page 42 TV view operations (Continued) Using the channel list ■ To display the channel list You can view the channel list previously stored by scanning. Press SET UP to display the main menu and select “Channel List” using then press ENTER. The channel list will appear.
Page 43 ■ “Quick Menu” in TV mode See page 35 on how to operate “Quick Menu”. e.g. 1 PICTURE A picture adjustment menu 66 appears. 2 SETUP A setting menu 70 appears. SD-P120DTKE_ENG_01-68.indd 43 SD-P120DTKE_ENG_01-68.indd 43 2008/03/11 15:32:37 2008/03/11 15:32:37...
Page 44 TV view operations (Continued) Customizing channel lineup You can store lists of your favourite channels. ■ To add channels to the favourite list 1 Press SET UP to display the main menu. 2 Press to select “Favourite List” and then press ENTER.
Page 45: System Settings
System settings ■ To display system information You can view the software version and hardware version of this unit. 1 Press SET UP to display main menu. 2 Press to select “System Setting” then press ENTER. 3 Press to select “System Info” then press ENTER.
Page 46 SD-P120DTKE_ENG_01-68.indd 46 SD-P120DTKE_ENG_01-68.indd 46 2008/01/17 19:14:27 2008/01/17 19:14:27...
Page 47: Playback
Playback Play your favourite disc. ● Loading a disc ● Connecting to headphones ● Playing a disc ● Changing a playback speed ● Playing a desired scene ● Playing in random order ● Playing repeatedly ● Playing in a favourite order ●...
Page 48: Loading A Disc
Loading a disc For disc compatibility information, see page 20 . Load a disc in the disc slot. Do not insert an 8cm disc. Never use incompatible discs. Neglecting this may cause malfunction. Insert a disc into the disc slot with the label side facing forward.
Page 49: Connecting To Headphones
Connecting to headphones You can connect headphones to the headphone jack using a stereo mini plug. Stereo mini plug (∅3.5mm) • Before connecting, temporarily turn down the volume with the volume button. Readjust to your preference when playback starts. • Turn off the player before you connect or disconnect the headphone cable.
Page 50: Playing A Disc
This type of damage is not covered by your Toshiba Warranty. To avoid this, be sure to press the STOP button once the movie is completed.
Page 51: Pausing Playback (Still Mode)
Pausing playback (Still mode) Press PAUSE/STEP during playback. The picture gets still and sound is muted. To resume normal playback, press PLAY. Adjusting the volume of the speakers or the connected headphones +/– Press (Volume button). The volume indicator will appear in the display. VOL + : Increases the volume.
Page 52 Playing a disc (Continued) ■ About the screen saver If 20 minutes elapse while the power is on and there is no disc in the player or while the disc is stopped, the screen saver is automatically displayed (when “Screen saver” (refer to “Function Settings”) is set to “On”...
Page 53: Changing A Playback Speed
Changing a playback speed Playing in fast reverse or fast forward DVD-V Press REV or FWD during playback. : Fast reverse playback : Fast forward playback Each time you press the REV or FWD button, the playback speed changes. Press PLAY to resume normal playback. •...
Page 54: Playing A Desired Scene
Playing a desired scene DVD-V Skipping chapters or tracks Press SKIP ( ) repeatedly to locate the chapter or track you want. Playback starts from the selected chapter or track. : Playback starts from the beginning of the next chapter or track. : Playback starts from the beginning of the current chapter or track.
Page 55: Marking The Desired Position To Locate (Bookmark Function)
Notes • Pressing the CLEAR button while pressing the SHIFT button resets the numbers. • Some discs may not respond to this process. • Some scenes may not be located precisely as you speciﬁ ed. Marking the desired position to locate (Bookmark function) First register a bookmark referring to “To register a bookmark”...
Page 56: Playing In Random Order
Playing in random order DVD-V During playback, press RANDOM to display “Shufﬂ e On” on the screen. Each time you press the button, the random mode “Shufﬂ e On” and “Shufﬂ e off” alternate. The mode on the screen will disappear in a few seconds if not operated.
Page 57: Repeating A Title, Chapter Or Track
Repeating a title, chapter or track During playback, press REPEAT repeatedly to select the repeat mode. Each time you press the button, the repeat mode changes on the screen. Repeat playback starts after ﬁ nishing the current chapter or track. Disc Mode Repeating range...
Page 58: Playing In A Favourite Order
Playing in a favourite order DVD-V During stop, press MEMORY. The programming display appears. e.g. DVD-V Program Enter a track number when Title 1 using a video CD. Title 2 Title 3 Title 4 Title 5 Title 6 Clear Clear All Play Program Setting the title, chapter or track in the order you wish to play.
Page 59: Zooming A Picture
Zooming a picture DVD-V Press ZOOM during playback. The zoom icon appears. This operation is available also during slow, still, fast forward or fast reverse playback. Select the zoom point and magniﬁ cation level. • Magniﬁ cation level: Press ZOOM repeatedly. The magniﬁ...
Page 60: Changing The Camera Angle
Changing the camera angle DVD-V Press ANGLE while playing a scene recorded with multiple camera angles. The angle icon ( ) appears on the screen. e.g. Number of angles Angle icon Current angle This display does not appear if the disc includes no scenes recorded with multiple angles.
Page 61: Selecting A Playback Sound
Selecting a playback sound DVD-V Press AUDIO during playback. The current audio setting is displayed. e.g. D 2 ch Sound recording Audio language system Press AUDIO while the audio setting is displayed on the screen. Each time you press the button, you can select a preferred sound from those included on the DVD video disc.
Page 62: Playing Audio/Video/Picture Fi Les
Use of CD-RW for MP3 ﬁ les is not recommended. You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission. ■ JPEG media compatibility with this player...
Page 63 When using a memory card 1 Press MODE repeatedly CARD until “ ” appears. 2 Insert a memory card into the slot. Insert a media you want to play. The menu appears. e.g. /Track01.CDA Track01 Track02 Repeat Mode Track03 Track04 Track05 Track06 Track07...
Page 64 Playing audio/video/picture ﬁ les (Continued) ■ Playing repeatedly (Audio CD/MP3) Select “Repeat” on the settings screen using during playback then press ENTER. Each time you press ENTER, the repeat mode changes. Off: Resume to normal playback. Single: Repeat current track. All: Repeats all tracks in order.
Page 65 ■ Playing in a favourite order (Audio CD/MP3) You can combine your favourite tracks/ﬁ les and play in the order you determine. 1 Select “Edit mode” on the settings screen using then press ENTER. 2 Position the cursor using to the track/ﬁ le list. 3 Select tracks/ﬁ...
Page 66: Adjusting The Picture
Adjusting the picture DVD-V These adjustments are effective only on the LCD of this player. When using a connected monitor, make picture adjustment on the monitor. Press PICTURE. A picture adjustment menu appears. e.g. Set the details. Refer to the table on the right. When complete, press PICTURE to turn off the menu.
Page 67: Selecting The Sound Enhancement
Selecting the sound enhancement DVD-V Press E.A.M.* The current sound enhancement setting appears. * E.A.M. = Enhanced Audio Mode Press E.A.M. repeatedly. • [3D Off] Normal sound. • [3D On] To obtain expansive virtual surround sound effects from just two speakers. Notes •...
Page 68 SD-P120DTKE_ENG_01-68.indd 68 SD-P120DTKE_ENG_01-68.indd 68 2008/01/17 19:14:32 2008/01/17 19:14:32...
Page 69: Function Settings
Function Settings You can change the default settings to customize performance to your preference. Customizing the function settings SD-P120DTKE_ENG_69-92.indd 69 SD-P120DTKE_ENG_69-92.indd 69 2008/01/17 19:15:08 2008/01/17 19:15:08...
Page 70: Customizing The Function Settings
Customizing the function settings DVD-V You can change the default settings to customize performance to your preference. Press SET UP during stop. The setting menu appears. Press to select the icon of the setting (listed below) to change, then press Press to select the setting you want to change, then press ENTER.
Page 71 Video Aspect Ratio DVD-V View Mode DVD-V Audio E.A.M. DVD-V D.R.C. DVD-V Digital Out DVD-V Rating Parental control DVD-V DVD-V Screen saver DVD-V Default Default ® DivX Registration SD-P120DTKE_ENG_69-92.indd 71 SD-P120DTKE_ENG_69-92.indd 71 To select a picture size according to the aspect ratio of your TV, when connected to this player to monitor playback picture.
Page 72 Customizing the function settings (Continued) Language OSD Menu DVD-V English: To view on-screen displays in English. Français: To view on-screen displays in French. Español: To view on-screen displays in Spanish. Deutsch: To view on-screen displays in German. Nederlands: To view on-screen displays in Dutch. Svenska: To view on-screen displays in Swedish.
Page 73 DivX subtitle Western European: To display subtitles in west European language. Central European: To display subtitles in Central European language. Cyrillic: To display subtitles in Slavonic Cyrillic language. Notes • Some DVD video discs may be set to display subtitles in a different language than you selected.
Page 74 Customizing the function settings (Continued) Audio E.A.M. DVD-V Normal: Normal sound. To obtain expansive virtual surround sound effects from just two speakers. Note • Pressing the E.A.M. button on the remote control also allows you to achieve the same setup. D.R.C.
Page 75 Rating Parental control DVD-V DVD video discs equipped with the parental lock function are rated according to their content. The contents allowed by a parental lock level and the way a DVD video disc can be controlled may vary from disc to disc.
Page 76 Customizing the function settings (Continued) To change your 5-digit security code 1 After selecting “Set Password”, press the 9 button ﬁ ve times then press ENTER. The 5-digit security code is cleared. 2 After selecting “Set Password”, press the number buttons to create a new 5-digit security code.
Page 77: Connections
Connections You can connect the player to a TV or audio system. Viewing on a connected TV Connecting to a device equipped with HDMI input Viewing pictures from connected video equipment Connecting to audio equipment SD-P120DTKE_ENG_69-92.indd 77 SD-P120DTKE_ENG_69-92.indd 77 2008/01/17 19:15:09 2008/01/17 19:15:09...
Page 78: Viewing On A Connected Tv
Viewing on a connected TV You can connect a TV to this player to view playback picture on it. Connect a TV to the AV OUT jack of this player. Audio/video cable (supplied) To AV OUT Connection to this jack disables the LCD of the player.
Page 79: Connecting To A Device Equipped With Hdmi Input
Connecting to a device equipped with HDMI input This player is compatible with 480i/480p/720p/1080i signals. Connect HDMI equipment to the HDMI terminal of this player. HDMI cable (not supplied) HDMI OUTPUT HDMI compatible device SD-P120DTKE_ENG_69-92.indd 79 SD-P120DTKE_ENG_69-92.indd 79 HDMI Press MODE repeatedly so that “ appears on the LCD.
Page 80: Viewing Pictures From Connected Video Equipment
Viewing pictures from connected video equipment You can use the LCD of this player to monitor pictures of connected video equipment. Connect video equipment to the AV IN jack of this player. To AV IN Signal ﬂ ow Yellow (Video) To video output White (Left) Video equipment...
Page 81: Connecting To Audio Equipment
Connecting to audio equipment You can enjoy high quality dynamic sounds by connecting the player to audio equipment. The connecting method depends on the types of audio input, digital or audio. Select the method according to the type of your equipment.
Page 82: Connecting To An Audio System Equipped With Analog Audio Inputs
Connecting to audio equipment (Continued) CAUTION • When you are connecting (via the BITSTREAM/PCM jack) an AV decoder that does not have Dolby Digital, Digital Theater Systems (DTS) or MPEG2 decoding function, be sure to set “Digital Out” to “PCM” from the on-screen displays .
Page 83: Others
Others Useful informations. Output sound conversion table Before calling service personnel Speciﬁ cations SD-P120DTKE_ENG_69-92.indd 83 SD-P120DTKE_ENG_69-92.indd 83 2008/01/17 19:15:10 2008/01/17 19:15:10...
Page 84: Output Sound Conversion Table
Output sound conversion table Discs Sound recording system BITSTREAM/PCM jack Dolby Digital Bitstream 48 kHz Linear 96 kHz PCM* video discs Bitstream MPEG1, MPEG2 Bitstream VIDEO CDs MPEG1 Bitstream Linear PCM 44.1 kHz AUDIO CDs Bitstream *PCM: down sampling PCM •...
Page 85: Before Calling Service Personnel
Before calling service personnel Check the following guide for the possible cause of a problem before contacting service. Symptom Cause No power. • The AC adapter or power plug is disconnected. • Connect the AC adapter or power plug securely. •...
Page 86 Before calling service personnel (Continued) Symptom Cause The playback picture has • The disc is dirty. occasional distortion. • Player is in fast forward or fast reverse mode. • The player was moved or given a shock. • The disc is not set correctly. Brightness is unstable or •...
Page 87 Symptom Cause The remote control does • The remote control is not pointed at not work properly. the remote sensor of the player. • The remote control is too far from the player. • The battery in the remote control is exhausted.
Page 88: Speciﬁ Cations
Speciﬁ cations Player Power supply DC 12 V 100 – 240 V AC, 50/60 Hz (with the supplied AC adapter) Mass Approximately 3.4 kg (Including the battery pack) External dimensions 342 × 324 × 62 mm (W/H/D) (Not including stand) Signal system PAL/3.58NTSC Laser...
Page 89 Liquid crystal display Panel size 29.9 cm (11.8 inches diagonally measured) Projection system IPS (In-Plane-Switching) Driving system Amorphous silicon TFT active matrix Resolution 786 (H) × 466 (V) pixels (effective pixel rate : more than 99.99%) This model complies with the speciﬁ cations. •...
Page 90 Memo SD-P120DTKE_ENG_69-92.indd 90 SD-P120DTKE_ENG_69-92.indd 90 2008/01/17 19:15:11 2008/01/17 19:15:11...
Page 91 Memo SD-P120DTKE_ENG_69-92.indd 91 SD-P120DTKE_ENG_69-92.indd 91 2008/01/17 19:15:11 2008/01/17 19:15:11...
Page 92 © 2008 Toshiba Corporation SD-P120DTKE_ENG_69-92.indd 92 SD-P120DTKE_ENG_69-92.indd 92 Printed in China 2008/01/17 19:15:12 2008/01/17 19:15:12...
