- Page 1 IDP-15BV DRILL PRESS Original: Operating Instructions JPW (Tool) AG Tämperlistrasse 5 CH-8117 Fällanden Switzerland Phone +41 44 806 47 48 +41 44 806 47 58 www.jettools.com M-50000986M 2017-05...
- Page 2 CE‐Conformity Declaration CE‐Konformitätserklärung Déclaration de Conformité CE Product / Produkt / Produit: Drill Press Säulenbohrmaschine Perceuse à colonne IDP‐15BV Brand / Marke / Marque: JET Manufacturer / Hersteller / Fabricant: JPW (Tool) AG, Tämperlistrasse 5, CH‐8117 Fällanden Schweiz / Suisse / Switzerland We hereby declare that this product complies with the regulations Wir erklären hiermit, dass dieses Produkt der folgenden Richtlinie entspricht Par la présente, nous déclarons que ce produit correspond aux directives suivantes 2006/42/EC Machinery Directive Maschinenrichtlinie Directive Machines 2014/30/EU electromagnetic compatibility elektromagnetische Verträglichkeit compatibilité électromagnétique designed in consideration of the standards und entsprechend folgender zusätzlicher Normen entwickelt wurde et été développé dans le respect des normes complémentaires suivantes EN ISO 12100:2010 EN 12717:2001+A1:2009 EN 60204‐1:2006+A1:2009 EN 61000‐6‐2:2005 EN 61000‐6‐4:2007+A1:2011 ...
-
Page 3: Special Safety Rules For Drill Press
EN – ENGLISH NOTE: 1.0 Special Safety Rules For Drill Press: 1. Caution : This drill press is intended for use only with drill bits. This use of other accessories may be hazardous. 2. Correct drilling speeds : Factors which determine the best speed to use in any drill press operation are : Kind of material being worked, size of hold, type of drill or other cutter, and quality of cut desired. -
Page 4: Electric
VII Electric ELECTRICAL CONNECTION/DISCONNECTION & OPERATION For three phase : 1. Electrical connection: A cable with four wires is equipped to connect your machine into the 3 phase power supply. Please connect your machine into the power supply with hand-operated disconnecting device, which is in compliance with subclause 5.3 of EN 60204-1, such as on fuse breaker or plug/socket combination. -
Page 5: Table Of Contents
11.0 TROUBLESHOOTING IDP-15BV ......................12 12.0 REPLACEMENT PARTS .......................... 13 12.1.1 IDP‐15BV – ........................ 14 RILL RESS XPLODED 12.1.2 IDP‐15BV – ........................ 15 RILL RESS ARTS 13.0 ELECTRICAL CONNECTIONS FOR IDP-15BV..................17... -
Page 6: Specifications
4.0 Specifications Model number ........................... IDP-15BV Stock number ..........................50000986M Motor and electrical: Motor type ....................totally enclosed fan cooled, induction Horsepower ..............................1HP Voltage ..............................230V Cycle ................................ 50Hz Listed FLA (full load amps) ........................14A Starting amps ............................6.8A Running amps (no load) .......................... - Page 7 L = length; W = width; H= height; D= depth The specifications in this manual were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations.
-
Page 8: Setup And Assembly
5.4.1 Chuck and arbor installation Read and understand the entire contents this manual before attempting Thoroughly clean arbor (A, Figure 6-2), chuck (B) assembly or operation. Failure to comply may and spindle (C). Any grease or residue in these cause serious injury. areas can cause the pieces to separate and create a safety hazard as well as damage to the tool. -
Page 9: Electrical Connections
6.2 Extension cords The use of extension cords is discouraged; try to position machines near the power source. If an extension cord is necessary, make sure it is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. -
Page 10: Return Spring Adjustment
IDP-15BV: Loosen set screw (H) with 1/4" hex wrench. IDP-15BV: Loosen hex cap screw (J) with 5/8” or adjustable wrench. Tilt table to desired angle, referring to scale and pointer atop table bracket. -
Page 11: User-Maintenance
Check that bolts are tight and electrical cords are in Workpiece must be clamped good condition. If an electrical cord is worn, cut, or to table or secured in a drill press vise that is damaged in any way, have it replaced immediately. securely fastened to table. -
Page 12: Troubleshooting Idp-15Bv
11.0 Troubleshooting IDP-15BV Symptom Possible Cause Correction * Drill press unplugged from wall, or Check all plug connections. motor. Drill press will not Fuse blown, or circuit breaker tripped. Replace fuse, or reset circuit breaker. start. Cord damaged. Replace cord. -
Page 13: Replacement Parts
Replacement parts are listed on the following pages. Some parts are shown for reference only, and may not be available individually. Non-proprietary parts, such as fasteners, can usually be found at local hardware stores, or may be ordered from JET. -
Page 14: Idp-15Bv Drill Press - Exploded View
12.1.1 IDP-15BV Drill Press – Exploded View... -
Page 15: Idp-15Bv Drill Press - Parts List
12.1.2 IDP-15BV Drill Press – Parts List Index No Part No Description Size 1 ....PM-212V001 ..... Base Plate .............. Ø140 ........1 2-3 ..... PM-212V002 ..... Column Ass'y ............Ø73 ......... 1 4 ....PM-212V004 ..... Rack ................ 520 L ........1 5 .... - Page 16 Index No Part No Description Size 60 ....PM-212V060 ..... Belt ................A37 .......... 1 61 ....PM-212V061 ..... Nut ................1"LT ......... 1 62 ....PM-212V062 ..... Pulley ........................1 63 ....PM-212V063 ..... Retaining Ring ............Ø45 ......... 2 64 ....
-
Page 17: Electrical Connections For Idp-15Bv
13.0 Electrical Connections for IDP-15BV Making of Item Description & Maker Type Technical data conformity designation function granted Plug for supply LIAN DUNG LT-32 10~16A , 250V Three phase Supply cable 3G 1.5mm TIEN TUNG H05VV-F VDE 0620 single phase...
