Owner's Record The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV. Model number: Serial number: 36HF12...
Dear Customer, Thank you for purchasing this Toshiba TV. This manual will help you use the many exciting features of your new TV. Before operating the TV, please read this manual completely, and keep it nearby for future reference. Safety Precautions...
Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings.
Page 4
Care For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions: 26) Always sit approximately 10–25 feet away from the TV and as directly in front of it as possible. The picture can appear dull if you sit too far to the left or right of the TV, or if sunlight or room lights reflect on the screen.
Using the remote control with a VCR or cable TV converter ... 14 Programming the remote control for use with a non-Toshiba VCR or cable TV converter ... 15 VCR code table ... 16 Cable TV converter code table ... 17 Learning about the remote control ...
Congratulations! You have purchased one of the finest TVs on the market. The goal of this manual is to guide you through setting up and operating your Toshiba TV as quickly as possible. Instructions in this manual are based on using the remote control.
NOTE REGARDING PICTURE QUALITY When connecting video equipment to your Toshiba TV: For GOOD picture quality: Use a standard yellow video cable. For BETTER picture quality: If your equipment has S-video connectors, use an S-video cable instead of a standard yellow video cable.
Connecting a cable converter box This connection allows you to watch basic and premium cable channels. To use the TV’s features, select ANT-1. To view premium channels, select ANT-2, tune the TV to channel 3 or 4 (whichever channel is vacant in your area), and use the converter box to change channels.
Connecting a DVD player or satellite receiver and a VCR This connection allows you to watch DVD/satellite, VCR, and TV programs, and record one TV channel while watching another channel. You will need: • two (or three, if satellite receiver is used) coaxial cables (one or more may be provided by your cable or satellite company) •...
TV programs. You can record one channel while watching another channel. Your TV has ColorStream (component video) inputs. Connecting your TV to a component video-compatible DVD player (such as a Toshiba DVD player with ColorStream ® quality and realism. You will need: •...
Connecting a DTV receiver/set-top box with component video and a VCR This connection allows you to watch DTV (digital TV broadcast), VCR, and TV programs, and record DTV and TV programs. You can record from one source while watching a program from another source.
Connecting two VCRs This connection allows you to record (dub/edit) from one VCR to another VCR while watching a videotape. You can also record from one TV channel while watching another TV channel. You will need: • two coaxial cables (one or more may be provided by your cable company) •...
Connecting an audio system This connection allows you to use an audio amplifier to adjust the audio level. This also allows you to use external speakers. To control the audio, turn on the TV and the stereo amplifier, and turn off the built-in speakers (see “Turning off the built-in speakers” on page 45).
With the remote control, you can operate your TV, most VCR models, and cable TV converters together, even if they are different brands. If you will be using your TV with a Toshiba VCR, your remote control is already programmed and ready to use. If you own different brands of VCRs and/or converters, you first have to program your remote control.
VCR or cable TV converter The remote control is pre-programmed to operate Toshiba VCRs. To use the remote control to operate a non-Toshiba VCR or cable converter, follow the steps below to program the remote control. 1. Refer to the “VCR code table” or “Cable TV converter code table”...
Learning about the remote control turns the TV on and off POWER displays screen information (page 46) RECALL illuminates the keypad for five seconds LIGHT sets the TV to turn off at a specific time (page 41) TIMER selects video input source (pages 20, 39) TV/VIDEO mutes the sound (page 42) MUTE...
Setting up your TV Learning about the menu system After you have installed the batteries and programmed the remote control, you will need to set some preferences on the TV using the menu system. You can access the menus using the buttons on your TV or remote control.
Changing the on-screen display language Choose from three different languages (English, French and Spanish) for the on-screen display of adjustment menus and messages. To select a language: 1. Press MENU, and then press x or • until the SET UP menu appears.
Adding channels to the TV’s memory When you press Channel y or z, your TV will stop only on the channels stored in the TV’s channel memory. Follow the steps below and on the next page to program all active channels into the TV’s memory.
3. Press y or z to highlight ADD/ERASE. SET UP LANGUAGE ENGL SH 0 0 : 0 0 CLOCK ANT1 / CABLE CABLE CH PROGRAM ERASE ERASE T I LT CORRECT I ON 4. Press x or • to select ADD or ERASE, depending on the function you want to perform.
Using the TV’s features Adjusting the channel settings Switching between two channels You can switch between two channels without entering an actual channel number each time. To switch between two channels: 1. Select the first channel or video mode you want to view. 2.
To clear a favorite channel: 1. Press MENU, and then press x or • until the CUSTOM menu appears. 2. Press y or z to highlight FAVORITE CH2, for example. 3. Press x or • to display the FAVORITE CH2 menu. CUSTOM T I MER 0 0 0...
Page 25
4. Press the Channel Number buttons to select a channel you want to label. CUSTOM T I MER 0 0 0 FAVOR I FAVOR I CH L A B E L I NG I NPUT I DEO LABEL LABEL - --- BACKGROUND CLEAR 5.
Viewing the wide-screen picture formats You can view programs that have the conventional TV picture format (4:3 aspect ratio) and the wide-screen format (16:9 aspect ratio). This feature is available for 1080i digital broadcasts and 480p/480i DVD signals connected to the ColorStream HD1 and HD2 jacks. Selecting the image shape 1.
Watching PIP/double-window The PIP/double-window feature allows you to watch two pictures at the same time. The sub-picture can be a TV broadcast or come from an external source, such as a VCR. To display a TV broadcast as a sub-picture: 1.
Switching the main and sub-pictures Press SWAP while you are using the PIP feature to switch the main and sub-pictures. The main and sub-pictures will switch each time you press the SWAP button. PIP mode Double-window mode Changing the position of the small picture Press LOCATE repeatedly while you are watching a small picture.
Using the multi-window feature The multi-window feature provides two functions. One is the Favorite that scans the channels programmed in the TV memory by the FAVORITE CH function (9-picture multi-search) and other is the Strobe that is convenient when watching a quickly moving picture such as a sport program.
Using the LOCKS menu The LOCKS menu includes the V-Chip, CH Lock, Video Lock, and New PIN Code functions. You can use these functions after entering the correct PIN code. Entering the PIN code 1. Press MENU, and then press x or • until the LOCKS menu appears.
Using the V-CHIP menu Some TV programs and movies include signals that classify the content of the program (violence, sex, dialog, language). The V-CHIP control feature in this TV detects the signals and blocks the programs according to your selections. To use this feature, perform the following setup.
MPAA RATING (Independent rating system for movies) 1. From the LOCKS menu, select MPAA RATING. 2. Press x or • to display the MPAA RATING menu, then press z or y to highlight MPAA RATING. 3. Press x or • to display the MPAA RATING menu. LOCKS MPAA RAT I NG NC1 7...
Unlocking programs temporarily 1. If you try to watch a TV program that exceeds the rating limits you set, the TV enters into the program lock mode. TH I S PROGRAM HAS BEEN BLOCKED ! EXCEEDS SET L I I TS PUSH MUTE TO ENTER CABLE 2.
Using the front panel lock feature Lock the front panel buttons to prevent the buttons from being pressed accidentally (by children, for example). When the front panel lock is in ON mode, all control buttons on the TV front panel (except POWER) do not operate.
Adjusting the picture Selecting the picture mode You can select your desired picture type from four picture modes: Sports, Standard, Movie, and Preference. Mode Picture Quality Sports Bright and dynamic picture (factory setting) Standard Standard picture setting (factory setting) Movie Movie-like picture setting (factory setting) Preference Your personal preference*...
Saving new preference You can save the PICTURE qualities (contrast, brightness, color, tint, and sharpness) you adjusted in the picture preference mode. To save your new preferences: 1. Press MENU, and then press x or • until the PICTURE menu appears.
Selecting the cinema mode When you view a DVD movie (3-2 pulldown processed) from a DVD player connected to the ColorStream (component video) inputs on the TV, smoother and more natural motion can be obtained by setting the CINEMA MODE to FILM (auto). To set the CINEMA MODE to FILM (auto): 1.
Selecting the video input source Press the TV/VIDEO on the remote control or the TV to view a signal coming from another device connected to your TV, such as a VCR or video disc player (see illustrations below). You can select ANT 1, VIDEO 1, VIDEO 2, VIDEO 3, ColorStream HD1, ColorStream HD2, or ANT 2 depending on which input jacks are used for connecting the devices (see “Connecting your TV”...
Using the closed caption feature The closed caption feature has two options: • Captions—An on-screen display of the dialogue, narration, and sound effects of TV programs and videos that are closed captioned (usually marked as “CC” in TV listings). • Text—An on-screen display of information not related to the current program, such as weather or stock data (when provided by individual stations).
Setting the sleep timer To set the sleep timer to turn the TV off automatically: 1. Press TIMER to set the length of time until the TV turns off. T I MER Every time you press the button, the time display will increase by 10 minutes, up to 180 minutes.
Adjusting the sound Muting the sound Press MUTE to temporarily reduce (1/2 MUTE) or turn off (MUTE) the sound. While the sound is off, the screen will display the word “1/2 MUTE” or “MUTE” in the lower right corner. Every time you press the button, the mute mode will change in the following order.
Using the SRS 3D surround sound feature The SRS 3D surround sound feature expands the audio listening field wider and deeper to create exceptional sound quality from the TV’s speakers. The feature uses stereo signals from a TV broadcast or video input.
Resetting audio adjustments The RESET function returns the audio adjustments to the following factory settings: Bass ... center (50) Treble ... center (50) Balance ... center (0) To reset the audio adjustments: 1. Press MENU, and then press x or • until the AUDIO menu appears.
Turning off the built-in speakers Use this feature to turn the TV speakers off when you connect an audio system (see “Connecting an audio system” on page 13). To turn off the built-in speakers: 1. Press MENU, then press x or • until AUDIO menu appears. 2.
® Using the StableSound feature When the signal source is changed, the StableSound the high volume level to prevent extreme changes in volume (for example, to prevent the sudden increase in volume that often happens when a TV program switches to a commercial). To turn on the StableSound feature: 1.
Viewing the demonstration mode When you press DEMO on the TV, the TV will automatically demonstrate several of your TV’s features. This function is provided for demonstration purposes only. To stop the demonstration mode: Press DEMO again. Understanding the auto power off feature The TV will automatically turn itself off after approximately 15 minutes if it is tuned to a vacant channel or if a station completes its broadcast for the day and stops broadcasting on that channel.
Appendix Specifications Television System NTSC standard Channel Coverage VHF: 2 through 13 UHF: 14 through 69 Cable TV: Mid band (A-8 through A-1, A through I) Power Source 120 V AC, 60 Hz Power Consumption 175 W (average) Audio Power 10 W + 10 W Speaker Type Two 2-3/8 ×...
Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solutions. Problem Solution TV will not turn on • Make sure the power cord is plugged in, then press POWER. •...
WHICH AN ACTION MAY BE BROUGHT, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES; THEREFORE, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU UNDER SUCH CIRCUMSTANCES. FST PURE ® is a registered trademark of Toshiba America Consumer Products, Inc. REV. MAR02...
ON THE TIME WITHIN WHICH AN ACTION MAY BE BROUGHT, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES; THEREFORE, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU UNDER SUCH CIRCUMSTANCES. FST PURE ® is a registered trademark of Toshiba America Consumer Products, Inc. REV. MAR02...
Index A/V receiver connection ... 13 ANT 1/2 ...20 Antenna cables ... 7 Audio cables ... 7 AUDIO OUT sound, selecting ... 45 Audio system connection ... 13 Auto power off ... 47 BACKGROUND selection ...46 Back of the TV ... 6 Cable converter box connection ...
