Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to result in interference to radio and TV reception. Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties authorized by Toshiba, could void the user’s authority to operate the equipment.
Page 3
In the spaces provided below, record the Model and Serial No. located on the bottom of your unit. Model No. Retain this information for future reference. Location of the required label LCD TV/DVD COMBINATION Serial No. 5000...
Introduction IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard.
Page 5
21. When you use this product in an airplane, follow the instructions of the airline. Disregarding them may cause harmful interference to radio communication. 22. Do not look close the pick-up lens or stare into laser beam. Doing so may cause damage to eyesight.
Page 6
Introduction IMPORTANT SAFETY INSTRUCTIONS j) Some cars may not have a compatible socket. NEVER modify this adapter to fit an incompatible cigarette lighter socket and/or power port. NEVER modify an incompatible cigarette lighter socket and/or power port to accept this adapter. Failure to observe the above warnings could cause smoke, fire, burns and/or electric shock.
Precautions Notes on handling Do not shock the LCD monitor. It may cause unit damage and malfunction. Do not use the unit in a place subject to vibration. Neglecting this may cause malfunction of the unit or damage to the disc. Do not leave the unit in a vehicle.
Introduction Notes and Information Structure of disc contents Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. VIDEO CDs/audio CDs are divided into tracks. DVD video disc Title 1 Chapter 1 Chapter 2 Chapter 1 VIDEO CD/Audio CD Track 1 Track 2...
If you happen to experience and difficulty playing a DVD on a Toshiba TV/ DVD combination, please feel free to call our Contact listed in “How to Obtain Service”...
Page 10
Introduction Notes and Information (continued) Exemptions Toshiba Corporation is not liable for any damage caused by fire, natural disaster (such as thunder, earthquake), acts by third parties, accidents, owner’s intentional or unintentional misuse, or uses in other improper conditions. Toshiba Corporation is not liable for incidental damages (such as profit loss or interruption in business, etc.) caused by use or inability to use of this...
Table of Contents Introduction SAFETY PRECAUTIONS ... 2 IMPORTANT SAFETY INSTRUCTIONS ... 4 Precautions ... 7 Notes and Information ... 8 Notes on region numbers ... 9 Table of Contents ... 11 Identification of Controls ... 12 Main unit ... 12 Side view ...
Introduction Identification of Controls See the page in for details. Main unit LCD monitor Disc cover Speakers CLOSE OPEN AV SOURCE CHANNEL PLAY/PAUSE VOLUME STOP SKIP button SKIP button STOP button CHANNEL buttons VOLUME buttons AV SOURCE button OPEN button PLAY/PAUSE button...
Side view PICTURE Headphone jack 1 DC IN jack Headphone jack 2 PICTURE button AUDIO OUT COMPONENT VIDEO IN POWER AUDIO OUT (Left) POWER button AUDIO OUT (Right) COMPONENT VIDEO IN Rear view BITSTREAM/PCM OUT S-VIDEO IN VIDEO IN AUDIO IN AUDIO IN jack (Right) VHF/UHF (75Ω) jack AUDIO IN jack (Left)
Introduction Identification of Controls (continued) The instructions in this manual describe the functions of the remote control. See the page in Remote control RMT CODE button (See below) POWER button SET UP button SLEEP button MEMORY button REPEAT button DISPLAY button CAP/TEXT button RANDOM button Number buttons...
Loading the remote control battery Open the cover. Insert batteries (R03 size) Make sure to match the + and – on the batteries to the marks inside the battery compartment. Close the cover. Notes on batteries Improper use of batteries may cause battery leakage and corrosion.
Introduction Antenna Connection Connecting an antenna to this unit Connect the antenna to this unit for viewing broadcast signals. Connecting to cable TV signal If you subscribe to a cable service in which basic cable channels are unscrambled and premium channels require the use of a Converter/Descrambler box, you may wish to use a two-set signal splitter (sometimes called a “two-set coupler”) and an A/B Switch box from the cable installer or an electronics supply store.
Power Connection Connect the supplied AC adapter to power the unit. Caution • Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire or electric shock. •...
Introduction How to use the main unit You can use the main unit in three ways. Open the LCD monitor Firmly press down on the main unit to setup the LCD monitor. Open the LCD monitor. If the LCD monitor is opened more than 90 degrees, the main unit may overturn, so be careful.
How to use when hanging it on a wall You can use the main unit with the LCD monitor bent back 180 degrees. A professional will perform the wall installation. If you want to install the main unit this way, contact your local Toshiba sales department.
TV Viewing Settings for watching TV Channel Setting Selecting the Channel Settings the Sound Closed caption function/ V-CHIP function Adjusting the Picture...
TV Viewing Settings for watching TV Steps for watching TV Antenna Connection Power Connection Selecting the TV mode Selecting the Display Language Channel setting Watch TV Turning on the power Turn on the power. POWER The unit turns on and the POWER indicator on the unit illuminates in green.
Selecting the TV mode The unit can switch between TV mode and DVD mode etc. To watch TV, first switch to TV mode. INPUT Press the INPUT SELECT button SELECT repeatedly to select the TV mode. (The AV SOURCE button on the main unit are also available.) COMPONENT S-VIDEO...
TV Viewing Channel Setting Auto channel programming Press SETUP. SET UP LCD SETUP LANGUAGE : ENGLISH CC MODE SETUP V-CHIP SETUP TV SETUP TV/CABLE : TV AUTO CH PROGRAM MANUAL CH PROGRAM Select the “TV/CABLE”. Press to select TV/CABLE. ENTER Each time you press ENTER, TV or ENTER CABLE changes.
Page 25
Manual channel programming Dispay the “LCD SETUP” menu, and set “TV/CABLE” to “TV” or “CABLE”. Press to select “CH PROGRAM”, then press ENTER. The following on-screen display appears. ENTER MANUAL CH PROGRAM ADJUST ENTER SKIP : RESET RETURN Press to select “CH”, then press to select a channel you want to change.
TV Viewing Selecting the Channel Selecting the channel To select the channel Press the number buttons. e.g. Select 125 channel To select to the next programmed channel Press the CHANNEL on the main unit or remote control. CHANNEL CHANNEL Changing the channel with CHANNEL whether or not to skip the channel, see “To add or erase channels manually”.
Setting the Sound Settings the sound To adjust the volume of the speakers or the connected headphones Turn volume control. +: Increase volume. VOLUME -: Decrease volume. VOLUME To mute the sound Press MUTE to temporarily turn off the sound. MUTE •...
TV Viewing Closed caption function/V-CHIP function Closed caption function You have two options with the closed caption feature (CC MODE): captions or text. A caption is a printed version of the dialogue, narration and/or sound effects of a TV program. Text is information not related to the program that appears on half of the TV screen when available.
Page 29
V-CHIP SETUP The V-CHIP function is available only for the U.S. V-CHIP system. The Canadian V-CHIP system is not supported. You can prevent others from viewing certain programs or channels by blocking them using or channels by blocking them using the V-CHIP feature. PASSWORD SETUP 1 Press to select PASSWORD SETUP, then...
Page 30
TV Viewing Closed caption function/V-CHIP function (continued) V-CHIP SETUP To set ENABLE BLOCKING 1 Enter V-CHIP SETUP and enter a password. 2 Press to select “ENABLE BLOCKING”. PASSWORD SETUP ENABLE BLOCKING : ON CHANGE PASSWORD : RETURN 3 Press ENTER to select “ON” or “OFF”. ON: To activate the “ENABLE BLOCKING”...
Page 31
MPAA RATING 1 Press to select the “MPAA RATING”, then press ENTER. V-CHIP SETUP PASSWORD SETUP TV RATING MPAA RATING MPAA UNRATED : OFF TV NONE RATING : OFF RETURN 2 Press to select the setting you want to change, then press ENTER.
TV Viewing Adjusting the Picture You can easily select a preferred picture. DVD-V Adjusting the picture Press PICTURE. Alternatively press PICTURE on the main unit. The picture setting display appears. PICTURE PICTURE PICTURE BRIGHTNESS 15 TINT COLOR CONTRAST SHARPNESS Adjust +–...
About this manual • The numbers indicated by lines on the illustrations correspond to the associated steps of the operation. • Aside from the section “Playing a Disc”, explanations of operations only include illustrations of the corresponding buttons on the remote control. The buttons sharing the same name on the main unit can also be used in an identical manner.
Basic playback Playing a Disc This section shows you the basics on how to play a disc. indicates a reference page of this manual. See the page in for details. DVD-V Basic playback Changing to the DVD mode The LCD TV/DVD combination can be switched to TV mode, DVD mode etc.
Page 35
To obtain a higher quality picture (When connected to a TV) SET UP Occasionally, some picture noise not usually visible during a normal broadcast may appear on the TV screen while playing a DVD video disc because the high resolution pictures on these discs include a lot of information. While the amount of TOP MENU noise depends on the TV you use with this unit, you should generally reduce the sharpness adjustment on the connected TV when viewing DVD video discs.
Page 36
Basic playback Playing a Disc (continued) Basic playback (continued) Power button PLAY STOP Volume control To adjust the volume of the speakers or the connected headphones Turn volume control. VOLUME + : Increase volume. – : Decrease volume. VOLUME To pause playback (still mode) Press PAUSE/STEP during playback.
Page 37
About the screen saver If you pause a picture of a DVD video disc and leave it still for approximately 20 minutes, the screen saver of the unit automatically appears (when “Screen Saver” is set to “On” ). To turn off the screen saver, press any button on the main unit or remote control.
Basic playback Variable Speed Playback You can play discs at various speeds, and resume playback from the location where you stopped playback. DVD-V Playing in fast reverse or fast forward directions Press REV or FWD on the remote control during playback. REV: Fast reverse playback FWD: Fast forward playback Each time you press the REV or FWD...
DVD-V Playing in slow-motion Press SLOW. Each time you press the SLOW SLOW FWD button, the slow-motion speed changes. SLOW REV If you press the SLOW REV button during playback, you can view the picture in reverse slow- motion. (Only when using a DVD video disc.) Each time you press the SLOW button, the slow-motion...
Basic playback Locating a Specific Title, Chapter, or Track Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. Contents of VIDEO CDs and audio CDs are divided into tracks. You can quickly locate any specific title, chapter, or track. DVD video disc Title 1 Chapter 1...
DVD-V Locating a desired section by entering its corresponding number Press T several times. The display changes each time this button is pressed. If you want to locate a title, chapter or track, display “Title,” “Chapter,” or “Track” respectively. You can also enter the time counter of the desired location.
Basic playback Locating a Specific Title, Chapter, or Track (continued) DVD-V Locating a specific chapter or track Press SKIP ( ) repeatedly to locate the chapter or track you want. Playback starts from the selected chapter or track. To locate succeeding chapters or tracks. SKIP SKIP Playback starts from the beginning of the...
(including CD-R containing MP3/WMA files). Given the fact that technology in this area is still maturing, Toshiba cannot guarantee that all genre of recordable discs will produce optimal playback quality. The technical criteria set out in this owner’s manual are meant as a guide only.
Basic playback Viewing JPEG Files You can play JPEG files that have been recorded on a CD-R on this unit. Viewing JPEG Files Preparation Prepare a disc that contains JPEG files you want to view Set a disc contains JPEG files and close the disc cover.
Page 45
To rotate a picture Press during playback. : A picture is vertically reversed. : A picture is horizontally reversed. ENTER : Rotate counterclockwise (by 90°). : Rotate clockwise (by 90°). To zoom in a picture 1 Press ZOOM during playback. ZOOM You will enter the zoom mode.
Page 46
Basic playback Viewing JPEG Files (continued) JPEG files compatibility Discs and pixels whose compatibility with this unit has been confirmed by TOSHIBA are as follows. Kodak Picture CD JPEG disc compatibility with this unit is limited as follows: • Playable discs: CD-ROM, CD-R, CD-RW •...
Advanced playback Customizing the performance of your unit. Directly Accessing a Specific Location Repeat Play Playing in a Favorite Order Playing in Random Order Zooming a Picture Selecting the Sound Enhancement (E.A.M.) Selecting a Camera Angle Selecting Subtitles Selecting a Language Operating in the On-screen Display Mode Adjusting the Picture...
Advanced playback Directly Accessing a Specific Location You can access a specific location by entering its corresponding time (hours, minutes, seconds). DVD-V Entering the time counter of the desired location Press T several times. The display changes each time this button is pressed.
Repeat Play You can play a specific title, chapter, track, or segment repeatedly. (Title repeat, chapter/track repeat, A-B repeat) DVD-V Repeating a title, chapter, or track Press REPEAT. Each time you press the REPEAT REPEAT button, the repeat mode changes as follows.
Advanced playback Playing in a Favorite Order You can combine your favorite titles, chapters, or tracks and play them in the order you determine. You can program up to 20 selections into the memory. (Memory playback) DVD-V Setting titles, chapters, or tracks in a favorite order Press MEMORY during stop.
Playing in Random Order You can play chapters or tracks in random order. (Random playback) DVD-V Playing chapters or tracks in random order Press RANDOM. Each time you press the RANDOM CAP/TEXT button, the random mode changes as follows. RANDOM Shuffle Shuffle Plays chapters once on a...
Advanced playback Zooming a Picture You can magnify areas within a picture. DVD-V Zooming a picture During normal, slow, still, fast reverse or fast forward playback, press ZOOM. The unit enters the zoom playback ZOOM mode, and the zoom icon appears. e.g.
Selecting the Sound Enhancement (E.A.M.*) You can easily select a preferred audio enhancement. *E.A.M.: Enhanced Audio Mode DVD-V Selecting the sound enhancement Press E.A.M. The sound enhancement menu E.A.M. appears. E.A.M. : Normal Select the sound enhancement by pressing E.A.M. Each time you press the button, the E.A.M.
Advanced playback Selecting a Camera Angle If a scene was recorded with multiple angles, you can easily change the camera angle of the scene you are viewing. DVD-V Changing the camera angle Press ANGLE while playing a scene recorded with multiple angles. While playing a scene recorded with ANGLE multiple angles, the angle icon (...
Selecting Subtitles You can display subtitles on the screen and select a subtitle language from those included on the DVD video disc. Good evening! Bonsoir! ¡Buenas tardes! DVD-V Selecting a subtitle language Press SUBTITLE during playback. The current subtitle setting is SUB TITLE displayed.
Advanced playback Selecting a Language You can select a preferred language and sound recording system from those included on the disc. Good morning! Bonjour! DVD-V Selecting a playback audio setting Press AUDIO during playback. The current audio setting is MONO/ STEREO/SAP displayed.
Page 57
Output sound conversion table (sampling frequency/quantization bit) Sound recording system Discs Dolby Digital 48 kHz/16 bit 48 kHz/20 bit Linear 48 kHz/24 bit video discs 96 kHz/16 bit 96 kHz/20 bit 96 kHz/24 bit MPEG1, MPEG2 VIDEO CDs MPEG1 Linear PCM 44.1 kHz/16 bit Audio CDs •...
Advanced playback Operating in the On-screen Display Mode When you turn on the on-screen display, you can view information on operational status and access features and settings. DVD-V On-Screen Display Operation Press DISPLAY during playback. The following display appears. DISPLAY e.g.
Page 59
When playing a VIDEO CD or audio CD To select a track. To select the audio channel (Stereo, Mono L&R, Left, Right). To select a playback audio setting. To repeat a track or entire disc. e.g. Current track number Note Some discs may not be compatible with a set of these operations.
Advanced playback Adjusting the Picture You can easily select a preferred picture. DVD-V Adjusting the picture Press PICTURE. Alternatively press PICTURE on the main unit. The picture setting display appears. PICTURE PICTURE PICTURE BRIGHTNESS 15 TINT COLOR CONTRAST SHARPNESS Adjust +–...
Function setup Customizing the Function Settings You can change the default settings to customize performance to your preference. DVD-V Setting procedure Press SETUP during stop. The following on-screen display SET UP appears. TV Shape Language Audio Operation Equalizer Mode Press ENTER to select Press to select the setting you want to change, then press ENTER.
Page 63
Setting TV Shape TV Shape Language On-screen Audio Subtitle Disc Menu Audio E.A.M. D.R.C. Audio Out Select Operation Parental Screen Saver Menu Style Default Equalizer EQ Mode Mode Details Details To select a picture size according to the aspect DVD-V ratio of your TV.
Function setup Customizing the Function Settings (continued) Setting details TV Shape Setup Menu TV Shape DVD-V 4:3 Normal: Select when a standard 4:3 TV is connected. Displays pictures cropped to fill your TV screen. Either or both sides of the picture are cut off. 4:3 Letterbox: Select when a standard 4:3 TV is connected.
Page 65
AUDIO MENU » E.A.M. D.R.C. Audio Out Select Setup Menu E.A.M. DVD-V You can obtain expansive virtual surround sound effects from just two speakers. Normal: Normal sound. To obtain expansive virtual surround sound effects from just two speakers. 3D (Headphone): To obtain expansive virtual surround sound effects when using headphone.
Page 66
Function setup Customizing the Function Settings (continued) Setting details Parental Screen Saver Menu Style Default Setup Menu Parental DVD-V DVD video discs equipped with the parental lock function are rated according to their content. The contents allowed by a parental lock level and the way a DVD video disc can be controlled may vary from disc to disc.
ON : To use the menu when playing a PBC-featured VIDEO CD. OFF : When playing a VIDEO CD without using the menu. Screen Saver DVD-V ON : The screen saver operates. OFF : The screen saver is disengaged. Menu Style DVD-V You can change setup menu configuration.
Connections You can connect the unit to a TV or audio system. Also, you can connect a battery pack to power the unit. Connecting from other equipment Connecting to Headphones Connecting to Audio Equipment Using the automobile/vehicle adapter or power port...
Connections Connecting from other equipment By connecting the video output terminals of external equipment (such as a DVD player or a tuner) to the unit, video from external equipment can be viewed on the unit. Connecting to a S-VIDEO IN/VIDEO IN/COMPONENT VIDEO IN jack Connecting to a S-VIDEO IN jack External equipment S-VIDEO OUT...
Connecting to an audio system Signal flow AUDIO OUT Notes • Refer to the owner’s manual of the connected equipment as well. • When you connect the unit to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.
Connections Connecting to Headphones You can listen to movies and music privately by connecting headphones. Headphones (not supplied) (headphone) jack Caution When you use headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage. Connecting headphones Connect headphones to the headphone jack using a stereo mini plug.
Connecting to Audio Equipment You can enjoy high quality dynamic sounds by connecting the unit to audio equipment. • For details of output sound, see • This section uses the following reference marks. : Front speaker : Rear speaker : Sub woofer : Center speaker : Signal flow Notes...
Connections Connecting to Audio Equipment (continued) Connecting to an amplifier equipped with a Dolby Digital decoder Dolby Digital Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by connecting the unit to a 6 channel amplifier equipped with a Dolby Digital decoder or Dolby Digital processor.
Connecting to an amplifier equipped with a DTS decoder Digital Theater Systems (DTS) DTS is a high quality surround technology used in theaters and now available for home use, on DVD video discs or audio CDs. If you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS encoded sound tracks on DVD video discs or audio CDs.
Connections Connecting to Audio Equipment (continued) Connecting to an amplifier equipped with a digital audio input 2 channel digital stereo You can enjoy the dynamic sound of 2 channel digital stereo by connecting an amplifier equipped with a digital audio input and speaker system (right and left front speakers).
Using the automobile/vehicle adapter or power port For use of the DVD player in a car, this adapter can power the DVD player from the cigarette lighter socket. Warning • NEVER operate the unit or view a DVD Video while operating an automobile or other vehicle. Note: doing so is illegal in many jurisdictions.
Page 78
Connections Instructions for Use 1 Turn off the unit. 2 Insert the pin plug of the adapter into the DC IN 15V jack of the unit. The LED illuminates when powered. 3 Insert the plug of the adapter into the cigarette lighter socket or power port fully.
Others Before Calling Service Personnel Check the following guide for the possible cause of a problem before contacting service. Symptoms and correction Symptom Cause No power. • The AC adapter or power plug is disconnected. The LCD turned off by itself. •...
Page 81
Symptom Cause The remote control does not • The remote control is not pointed at the work properly. remote sensor of the player. • The remote control is too far from the player. • The batteries in the remote control are exhausted.
Others Specifications Unit / Connectors / Liquid crystal display / Supplied accessories Unit Power supply Mass External dimensions Signal system Laser Frequency range Operating conditions Connectors Audio output (AUDIO OUT) Audio output (BITSTREAM/PCM OUT) Video input (VIDEO IN) S video input (S-VIDEO IN) Component input (COMPONENT VIDEO IN) Audio input (AUDIO IN) Headphone terminal...
LIMITED WARRANTY LCD TV/DVD COMBINATION Toshiba America Consumer Products, L.L.C. (“TACP”) and Toshiba Canada Limited (“TCL”) make the following limited warranties. These limited warranties extend to original consumer purchaser or any person receiving this set as a gift from the original consumer purchaser and to no other purchaser or transferee.
Page 84
Canadian consumers are requested to complete the special Canadian “Warranty Registration Form” enclosed, and forward this completed form with a copy of bill of sale to TOSHIBA OF CANADA to “Register and Validate” their warranty. Product must be purchased from an Authorized Canadian Dealer.
