DVD PLAYER OWNER’S MANUAL MODEL : SD-K615 Surround Sound Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely. -
Page 2: Safety Precautions
Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following proce- dures for installation, use, and servicing. -
Page 4: Table Of Contents
Table of Contents Introduction Safety Precautions ......2 IMPORTANT SAFETY INSTRUCTIONS ..3 Table of Contents . -
Page 5: Before Use
Before Use Playable Discs DVD Video (8 cm / 12 cm disc) Video CD (VCD) (8 cm / 12 cm disc) Audio CD (8 cm / 12 cm disc) In addition, this unit can play a CD-R or CD-RW that contains audio titles or MP3 files. -
Page 6: Precautions
Before Use (Cont’d) Precautions Handling the unit When shipping the unit The original shipping carton and packing materials come in handy. For maximum protection, re-pack the unit as it was originally packed at the factory. When setting up the unit The picture and sound of a nearby TV, VCR, or radio may be distorted during playback. -
Page 7: Front Panel And Display Window
Front Panel and Display Window ON/STANDBY indicator Lights red when the player is in Standby mode (off). CLEAR REPEAT Removes a track number Repeat chapter, in the program menu or track, title, Disc, a mark on the MARKER all. SEARCH menu. RANDOM Plays tracks in random... -
Page 8: Remote Control
Remote Control OPEN/CLOSE Opens and closes the disc tray. GUI DISPLAY Accesses on-screen display SETUP Accesses or closes setup menu. TOP MENU Displays the Title menu of the disc if available. 1 1 2 2 3 3 4 4 (left/right/up/down) Selects an item in the menu. -
Page 9: Rear Panel
Rear Panel Select either S-VIDEO or COMPONENT, depending on COMPONENT VIDEO OUT (Y P Connect to a TV with Y P Connect to a TV with video inputs. AC Power Cord Plug into the power source. OPTICAL (Digital audio out jack) Connect to digital (optical) audio equipment. -
Page 10: Connections
Connections Tips Depending on your TV and other equipment you wish to connect, there are various ways you could connect the player. Use only one of the connections described below. Please refer to the manuals of your TV, VCR, Stereo System or other devices as necessary to make the best connections. -
Page 11: Connecting To Optional Equipment
Connections (Cont’d) Connecting to Optional Equipment Connecting to an amplifier equipped with two channel analog stereo or Dolby Surround Connect the Left and Right AUDIO OUT jacks on the DVD Player to the audio left and right in jacks on your amplifier, receiver or stereo system, using the supplied audio cables (A). -
Page 12: Before Operation
Before Operation General Explanation This manual gives basic instructions for operating the DVD Player. Some DVDs require specific operation or allow only limited operation during playback. When this occurs, the symbol appears on the TV screen, indi- cating that the operation is not permitted by the DVD Player or is not available on the disc. -
Page 13: Initial Settings
Before Operation (Cont’d) Initial Settings You can install your own Personal Preferences. Initial Settings General Operation Press SETUP. The setup menu appears. Original Disc Audio Disc Subtitle English Disc Menu French Rating German Area Code Spanish TV Aspect Italian Menu Language Chinese Progressive Scan Polish... -
Page 14: Sound
Before Operation (Cont’d) Sound Digital Audio Output Each DVD disc may have a variety of audio output options. Set the player’s Digital Audio Output according to the type of audio system you use. DOLBY DIGITAL/PCM: Select “DOLBY DIGITAL/PCM” if you connect the DVD Player’s DIGITAL OUT jack to a Dolby Digital decoder (or an amplifier or other equip- ment with a Dolby Digital decoder). -
Page 15: Parental Control
Before Operation (Cont’d) Parental Control Rating Movies on DVDs may contain scenes not suitable for children. Therefore, discs may contain Parental Control information that applies to the complete disc or to certain scenes on the disc. These scenes are rated from 1 to 8, and alternatively, more suitable scenes are available for selection on some discs. -
Page 16: Operation With Dvd, Video Cd And Audio Cd
Operation with DVD, Video CD and Audio CD Playing a DVD, Video CD and Audio CD Playback Setup VCD2.0 Turn on the TV and select the video input source corresponding to the DVD player. Audio system: Turn on the audio system and select the input source connected to the DVD player. -
Page 17: General Features
Operation with DVD, Video CD and Audio CD (Cont’d) General Features Note Unless stated otherwise, all operations described use the remote control. Some features may also be available from the Setup menu. Moving to another TITLE When a disc has more than one title, you can select to another title as follows: Press GUI DISPLAY when playback is stopped. -
Page 18: Repeat
Operation with DVD, Video CD and Audio CD (Cont’d) General Features (cont’d) Repeat VCD2.0 VCD1.1 DISC CHAPT TITLE TRACK DVD Video Discs - Repeat Chapter/Title/Off 1 To repeat the chapter currently playing, press REPEAT. The Repeat Chapter icon appears on the TV screen. 2 To repeat the title currently playing, press REPEAT a second time. -
Page 19: Marker Search
Operation with DVD, Video CD and Audio CD (Cont’d) General Features (cont’d) Marker Search VCD2.0 MARKER SEARCH You can start playback from a memorized point. Up to nine points can be memorized. To enter a mark, follow these steps. 1 During disc playback, press MARKER at the location you want to memorize. -
Page 20: Programmed Playback With Video Cd And Audio Cd
Programmed Playback with Video CD and Audio CD Programmed Playback with Video CD and Audio CD Note On a Video CD with PBC, you must set PBC to Off on the setup menu to use the Program function. See page 14. Insert a Video CD or Audio CD and close the tray. -
Page 21: Operation With Mp3 Disc
MP3 files). That require certain pre-existing conditions (see above) to insure compatible playback. Customers should also note that permission is required in order to download MP3 files and music from the Internet. TOSHIBA cannot grant such permission. Permission should always be sought from the copyright owner. -
Page 22: Programmed Playback With Mp3 Disc
Programmed Playback with MP3 Disc Programmed Playback with MP3 Disc Program allows you to store your favorite tracks for a particular disc in the player memory. Program can contain 60 tracks. Insert the disc and close the tray. The menu is displayed on the TV screen. Press PROGRAM during playback or in the stop mode to enter the Program Edit mode. -
Page 23: Additional Information
Additional Information Last Condition Memory VCD1.1 This player memorizes the last condition for the last disc you have watched. Settings remain in memory even if you remove the disc from the player or switch off the player. If you load a disc that has its settings memo- rized, the latest stop position is automatically recalled. -
Page 24: Troubleshooting
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Symptom No power. The power cord is disconnected. The power is on, but No disc is inserted. the DVD player does not work. The TV is not set to receive DVD signal No picture. -
Page 25: Language Code List
Language Code List Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu” (See page 13). Code Language Code 6565 Afar 7079 6566 Abkhazian 7082 6570 Afrikaans 7089 6577 Ameharic 7165 6582 Arabic 7168 6583 Assamese 7176... -
Page 26: Area Code List
Area Code List Enter the appropriate code number for the initial setting “Area Code” (See page 15). Code Area Code Area Andorra United Arab Emirates Afghanistan Antigua and Barbuda Anguilla Albania Armenia Netherlands Antilles Angola Antarctica Argentina American Samoa Austria Australia Aruba Azerbaidjan... -
Page 27: Specifications
Specifications General Power requirements Power consumption Dimensions (approx.) Mass (approx.) Operating temperature Operating humidity System Laser Signal system Frequency response Signal-to-noise ratio Harmonic distortion Dynamic range Outputs VIDEO OUT S-VIDEO OUT COMPONENT VIDEO OUT Audio output (digital audio) Audio output (optical audio) Audio output (analog audio) Accessory Video cable . -
Page 28: Limited Warranty Dvd Video Player
LIMITED WARRANTY DVD VIDEO PLAYER Toshiba America Consumer Products, Inc. (“TACP”), Toshiba Hawaii (“THI”) and Toshiba Canada Limited (“TCL”) make the follow- ing limited warranties. These limited warranties extend to original purchaser or any person receiving this set as a gift from the orig- inal purchaser and to no other purchaser or transferee. - Page 29 Canadian consumers are requested to complete the special Canadian “Warranty Registration Form” enclosed, and forward this completed form with a copy of bill of sale to TOSHIBA OF CANADA to “Register and Validate” their warranty. Product must be purchased from an Authorized Canadian Dealer. Products purchased in the U.S.A. and used in Canada are not covered by these warranties.
