- Page 1 DIGITAL VIDEO DVD VIDEO PLAYER SD-9200 Sep., 2000 s...
-
Page 2: Introduction
- Consult the dealer or an experienced radio/TV technician for help. WARNING: Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties authorized by Toshiba, could void the user’s authority to operate the equipment. The lightning flash with arrowhead symbol, within an equilat- eral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... - Page 3 In the spaces provided below, record the Model and Serial No. located on the rear panel of your DVD player. Model No. Retain this information for future reference. Location of the required label PRODUCT IS CERTIFIED BY THE MANUFACTURER TO COMPLY WITH DHHS RULE 21 CFR SUBCHAPTER J APPLICABLE AT THE DATE OF MANUFACTURE.
-
Page 4: Important Safety Instructions
Introduction IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. - Page 5 6. Water and Moisture Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool and the like. 7. Cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
- Page 6 Introduction IMPORTANT SAFETY INSTRUCTIONS 13. Accessories Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product.
- Page 7 19. Servicing Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 20. Replacement Parts When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part.
-
Page 8: Precautions
Introduction Precautions Notes on handling When shipping the DVD player, the original shipping carton and packing materials come in handy. For maximum protection, repack the unit as it was originally packed at the factory. Do not use volatile liquids, such as insect spray, near the DVD player. -
Page 9: Notes On Discs
Notes on Discs On handling discs Do not touch the playback side of the disc. Playback side Do not attach paper or tape to discs. On cleaning discs Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outwards with a soft cloth. -
Page 10: Notes On Region Numbers
Introduction Notes on Discs (continued) About this owner’s manual This owner’s manual explains the basic instructions of this DVD player. Some DVD video discs are produced in a manner that allows specific or limited operation during playback. As such, the DVD player may not respond to all operating commands. -
Page 11: Table Of Contents
Table of Contents Introduction SAFETY PRECAUTIONS ... 2 IMPORTANT SAFETY INSTRUCTIONS ... 4 Precautions ... 8 Notes on Discs ... 9 Notes on region numbers ... 10 Table of Contents... 11 Identification of Controls ... 12 Front panel ... 12 Rear panel ... -
Page 12: Identification Of Controls
Introduction Identification of Controls See the page in for details. Front panel POWER indicator POWER POWER button Rear panel ® ColorStream (Component video) VIDEO OUT jacks (Y/P VIDEO OUT jack VIDEO OUT VIDEO S VIDEO OUT jack When connecting the optical digital cable, remove the cap and fit the connector into the jack firmly. -
Page 13: Dvd Display
DVD display Chapter/track number indicator Title/group number indicator HDCD indicator TITLE GROUP HDCD DVD-AUDIO V C D VIDEO CD/CD indicator DVD/DVD-AUDIO indicator Play mode indicator The indicators vary depending on the kinds of discs you play. DVD video disc • During playback: Example TITLE GROUP... -
Page 14: Remote Control
Introduction Identification of Controls (continued) The instructions in this manual describe the functions on the remote control. See the page in Remote control OPEN/CLOSE button QUICK button ANGLE button V-REMOTE button TOP MENU button Cursor control/ENTER button • Cursor control – to move the cursor Push toward the direction you want. -
Page 15: Loading Batteries
Loading batteries Open the cover. Insert batteries (AAA size). Make sure to match the + and – on the batteries to the marks inside the battery compartment. Close the cover. Notes on batteries Improper use of batteries may cause battery leakage and corrosion. -
Page 16: Connections
Connections Read this chapter first to make all necessary preparations. Connecting to a TV Connecting to an audio system and TV equipped with component video inputs Connecting to an amplifier equipped with a Dolby Digital decoder Connecting to an amplifier equipped with Dolby Pro Logic Surround Connecting to an amplifier... -
Page 17: Connecting To A Tv
Connections Connecting to a TV Connect the DVD player to your TV. For details of output sound, see Connecting to a TV Signal flow VIDEO OUT VIDEO To S VIDEO OUT To VIDEO OUT Notes • Refer to the owner’s manual of the connected TV as well. •... -
Page 18: Connecting To An Audio System And Tv Equipped With Component Video Inputs
Connecting to an audio system and TV equipped with component video inputs Signal flow VIDEO OUT VIDEO To Y To P To P VIDEO VIDEO VIDEO To P video input To P video input To Y video input PROGRESSIVE outputs/inputs (ColorStream Some TVs or monitors are equipped with component video inputs that are capable of reproducing a progressively scanned video signal. -
Page 19: Connecting To Optional Equipment
Connections Connecting to Optional Equipment You can enjoy high quality dynamic sounds by connecting the DVD player to optional audio equipment. • For connection to your TV, see “Connecting to a TV” 18 19 • For details of output sound, see •... -
Page 20: Connecting To An Amplifier Equipped With A Dolby Digital Decoder
Connecting to an amplifier equipped with a Dolby Digital decoder Dolby Digital Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by connecting the DVD player to a 6 channel amplifier equipped with a Dolby Digital decoder or Dolby Digital processor. -
Page 21: Connecting To An Amplifier Equipped With A Dts Decoder
Connections Connecting to Optional Equipment (Continued) Connecting to an amplifier equipped with a DTS decoder Digital Theater Systems (DTS) DTS is a high quality surround technology used in theaters and now available for home use, on DVD video discs or audio CDs. If you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS encoded sound tracks on DVD video discs or audio CDs. -
Page 22: Connecting To An Amplifier Equipped With 5.1Ch Audio Inputs
Connecting to an amplifier equipped with 5.1ch audio inputs 5.1ch surround sound The Dolby Digital decoder equipped with this DVD player enables you to obtain the full benefit of 5.1 channel sound tracks when you connect the DVD player to an amplifier equipped with 5.1 channel audio inputs. -
Page 23: Playing A Disc
Basic playback Begin your operation. Playing a Disc Variable Speed Playback Locating a Desired Section... - Page 24 Basic playback Playing a Disc This section shows you the basics on how to play a disc. Do not give an upward force to the disc tray or put an object under. Doing so may damage the disc tray mechanism, causing the DVD player to malfunction. DVD-V DVD-A Basic playback...
- Page 25 To obtain a higher quality picture 2, 4 Occasionally, some picture noise not usually visible during a normal broadcast may appear on the TV screen while playing a DVD video disc because the high TOP MENU resolution pictures on these discs include a lot of information. While the amount of MENU noise depends on the TV you use with this DVD player, you should generally reduce Jog control...
- Page 26 Basic playback Playing a Disc (continued) VIDEO ON indicator Basic playback (continued) Still pictures included on DVD audio discs DVD audio discs may include still pictures, which are classified into two large groups. • Slideshow: Still pictures appear one after another automatically consistent with the disc program.
-
Page 27: Variable Speed Playback
Variable Speed Playback You can play discs at various speeds, and resume playback from the lacation where you stopped playback. DVD-V DVD-A Playing in fast reverse or fast forward directions During normal playback, move the jog control toward : Fast reverse playback : Fast forward playback Each time you move the jog control up or down, the playback speed... -
Page 28: Playing In Slow-Motion
Basic playback Variable Speed Playback (continued) DVD-V DVD-A Playing in slow-motion Press SLOW during playback. Each time you press the SLOW SLOW button, the slow-motion speed changes. If you press the SLOW SLOW during playback, you can view the picture in reverse slow-motion. (Only when using a DVD video disc.) Each time you press the SLOW button, the slow-motion speed... -
Page 29: Locating A Desired Section
Locating a Desired Section Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. DVD audio discs are divided into groups, and the groups are sub-divided into tracks. VIDEO CDs and audio CDs are divided into tracks. You can quickly locate any specific title, chapter, group, or track. -
Page 30: Locating A Desired Section By Entering The Corresponding Number
Basic playback Locating a Desired Section (continued) DVD-V DVD-A Locating a desired section by entering the corresponding number Press T. Skip steps 1 and 2 if you are using a VIDEO CD/ audio CD. The following display appears. SEARCH DVD-V e.g. -
Page 31: Advanced Playback
Advanced playback Customizing the performance of your DVD player. Accessing a Specific Location Directly Playing Repeatedly Playing in a Favorite Order Playing in Random Order Zooming a Picture Selecting DNR Picture Enhancement Selecting the Camera Angle Selecting Subtitles Selecting a Language... -
Page 32: Accessing A Specific Location Directly
Advanced playback Accessing a Specific Location Directly You can access a specific location by entering its corresponding time (hours, minutes, seconds). DVD-V DVD-A Entering the time of the desired location Press T twice. You may have to press further SEARCH depending on the disc. -
Page 33: Playing Repeatedly
Playing Repeatedly You can play a specific title, chapter, group, track, or segment repeatedly. DVD-V DVD-A Repeating a title, chapter, group or track Press REPEAT. Each time you press the REPEAT REPEAT button, the repeat mode changes as follows. Chapter Repeat Chapter Repeat Repeats the current chapter. -
Page 34: Playing In A Favorite Order
Advanced playback Playing in a Favorite Order You can combine your favorite titles, chapters, group, or tracks and play them in the order you determine. You can program up to 30 selections into the memory. (Memory playback) Title: 2 Title: 2 Chapter: 25 Chapter: 12 DVD-V... -
Page 35: Playing In Random Order
Playing in Random Order You can play titles, chapters within a title or tracks in random order. (Random playback) Title: 1 Chapter: 3 Title: 2 Chapter: 2 DVD-V DVD-A Playing titles, chapters or tracks in random order Press RANDOM. Each time you press the RANDOM RANDOM button, the random playback mode changes as follows. -
Page 36: Zooming A Picture
Advanced playback Zooming a Picture You can magnify areas within a picture. DVD-V DVD-A Zooming a picture Press ZOOM during normal, slow or still playback. Zoom playback starts. ZOOM Select the zoom point and magnification level. To increase the magnification level. To reduce the magnification level. -
Page 37: Selecting Dnr Picture Enhancement
Selecting DNR Picture Enhancement You can view a picture with less video noise. DVD-V DVD-A Selecting DNR picture enhancement Press DNR during playback. The current setting is displayed. Each time you press the DNR button, the setting changes as follows. Normal level 3D DNR On Expanded level... -
Page 38: Selecting The Camera Angle
Advanced playback Selecting the Camera Angle If the scene was recorded from multiple angles, you can easily change the camera angle of the scene you are watching. DVD-V DVD-A Changing the camera angle Press ANGLE while playing a scene recorded with multiple angles. While playing a scene recorded with ANGLE multiple angles, the angle icon (... -
Page 39: Selecting Subtitles
Selecting Subtitles You can display subtitles on the TV screen and select a subtitle language from those included on the DVD video disc. Good evening! Bonsoir! ¡Buenas tardes! DVD-V DVD-A Selecting a subtitle language Press SUBTITLE during playback. The current subtitle setting is SUBTITLE displayed. -
Page 40: Selecting A Language
Advanced playback Selecting a Language You can select a preferred language and sound recording system from those included on the DVD video disc. Good morning! Bonjour! DVD-V DVD-A DVD-A Selecting a playback audio setting Press AUDIO during playback. AUDIO The current audio setting is displayed. - Page 41 Output sound conversion table (sampling frequency/quantization bit) Discs Sound recording system “Bitstream” BITSTREAM/PCM jack Dolby Digital Bitstream 48 kHz/16 bit 48 kHz/16 bit 48 kHz/20 bit 48 kHz/16 bit Linear 48 kHz/24 bit 48 kHz/16 bit video discs 96 kHz/16 bit 48 kHz/16 bit 96 kHz/20 bit 48 kHz/16 bit...
-
Page 42: Quick Control
Quick control Simple use of a single button and the cursor control enables you to direct your playback, without manipulating many actual buttons. Using the Graphic Remote Control - V-REMOTE - Selecting the Playback Function - QUICK - Accessing Features - NAVI -... -
Page 43: Using The Graphic Remote Control
Quick control Using the Graphic Remote Control - V-REMOTE - Pressing one button can display a graphics based on-screen remote control that allows you to control playback as if you were doing it from the actual remote control. DVD-V DVD-A Using the graphic remote control During playback, press V-REMOTE. -
Page 44: Selecting The Playback Function - Quick
Selecting the Playback Function - QUICK - Pressing one button can display a list of playback functions which are relevant to your current playback mode. You can check and modify them from the list. DVD-V DVD-A Selecting the playback function During playback, press QUICK. -
Page 45: Accessing Features - Navi
Quick control Accessing Features - NAVI - The NAVI menu provides an icon based display from which you can easily access key playback function. DVD-V DVD-A NAVI menu items Press NAVI. The NAVI menu appears. NAVI Feature icon e.g. DVD-V V-Remote Angle Viewer Title:... - Page 46 Navi menu selections DVD-V V-Remote You can control key playback functions using the graphics based on-screen remote control. Navi Angle Viewer You can display all camera angles simultaneously and select your preferred one from them. Zoom You can magnify areas within a picture. You can divide a desired scene into stop action frames for careful analysis.
- Page 47 Quick control Accessing Features - NAVI - (continued) NAVI menu items Angle Viewer You can display all camera angles simultaneously and select your preferred one from them. After selecting this icon and pressing ENTER, the following on-screen display appears: e.g. Angle Viewer Navi When the scene contains 9 camera angles:...
- Page 48 You can display thumbnail views of the first scenes of titles or chapters and Preview select a preferred one. After selecting this icon and pressing ENTER, the following on-screen display appears: e.g. Title Chapter Interval << >> Preview Navi Exit 1 Move the cursor control to select.
- Page 49 Quick control Accessing Features - NAVI - (continued) NAVI menu items You can sample a scene Capture from a playback picture and transform it into a background picture. After selecting this icon and pressing ENTER, the following on-screen display appears: e.g.
-
Page 50: Function Setup
Function Setup You can change the default settings to customize performance to your preference. Customizing the Function Settings Table of Languages Operating a TV with the remote control... -
Page 51: Customizing The Function Settings
Function setup Customizing the Function Settings You can change the default settings to customize performance to your preference. DVD-V DVD-A Setting procedure Press SETUP during stop. The following on-screen display SETUP appears. Picture TV Shape Blacker than Black Setting : Interlaced Setting : Progressive Progressive 4:3 Output Progressive Conversion... - Page 52 Setting TV Shape DVD-V Blacker than Black DVD-V Setting: Interlaced DVD-V Setting: Progressive DVD-V Progressive 4:3 Output DVD-V Progressive Conversion DVD-V DVD-V Audio Out Select Dynamic Range Control DVD-V Karaoke Vocal DVD-V CD Attenuation On-Screen Language DVD-V Disc Menu Language DVD-V Audio Language DVD-V...
-
Page 53: Setting Details
Function setup Customizing the Function Settings (continued) Setting details Picture TV Shape Blacker than Black Setting : Interlaced Setting : Progressive Progressive 4:3 Output Progressive Conversion TV Shape DVD-V 4:3 Letterbox: Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture. - Page 54 Setting : Progressive DVD-V VCD You can fine adjust picture quality and store up to 3 picture settings in the memory of the DVD player. (Only when connected to a PROGRESSIVE TV.) To select a preset memory setting: 1) Move the cursor control ( / ) to select a memory number (1 to 3), and press the ENTER button.
- Page 55 Function setup Customizing the Function Settings (continued) Setting details Audio Audio Out Select Dynamic Range Control Karaoke Vocal CD Attenuation Audio Out Select DVD-V DVD-A Select the output sound format corresponding to your system connection. For details of sound recording systems, see Bitstream: Select when connected to an amplifier equipped with a Dolby Digital, DTS,...
- Page 56 Adjusting the delay time: When enjoying 5.1ch surround playback, it is ideal to choose a listening position that is the same distance from each speaker. By adjusting the delay time of the center/surround speakers, you can virtually create an ideal listening environment (as if the center/surround speakers were at their ideal locations respectively as below.) Ideal location of a...
- Page 57 Function setup Customizing the Function Settings (continued) Setting details Language On-Screen Language ENG Disc Menu Language Audio Language Subtitle Language On-Screen Language DVD-V English: To view on-screen displays in English. Français: To view on-screen displays in French. Español: To view on-screen displays in Spanish. Disc Menu Language DVD-V English: To display disc menus in English.
- Page 58 3) Move the cursor control ( / ) to shift and select the second character by moving the cursor control ( / ). Language On-Screen Language ENG English Disc Menu Language French Audio Language Spanish Subtitle Language No Subtitle – – – Others Code A A 4) Press the ENTER button.
- Page 59 Function setup Customizing the Function Settings (continued) Setting details Operation Pause/Still Parental Lock Remote Confirmation Title/Group Stop Priority Contents Pause/Still DVD-V Auto: For normal use. Still and fast motion images can be paused. Frame: The resolution of still pictures is improved, so that you can make a motionless picture more clearer when you pause it.
-
Page 60: Pbc Vcd
3) Move the cursor control ( / ) to select the parental lock level, then press the ENTER button. Operation Pause/Still Auto Parental Lock Remote Confirmation Area Code Title/Group Stop Level Priority Contents AUDIO You cannot play DVD video discs rated higher than the level you selected unless you cancel the parental lock function. - Page 61 Function setup Customizing the Function Settings (continued) Setting details Initial Setup On-Screen Language ENG TV Shape Audio Out Select Initial Setup DVD-V DVD-A 1) Move the cursor control ( / ) to select “On- Screen Language,” and press the ENTER button.
-
Page 62: Table Of Languages
Table of Languages Table of languages and their abbreviations Abbreviation Language – – – No alternate language CHI (ZH) Chinese DUT (NL) Dutch ENG (EN) English FRE (FR) French GER (DE) German ITA (IT) Italian JPN (JA) Japanese KOR (KO) Korean MAY (MS) Malay... -
Page 63: Operating A Tv With The Remote Control
The DVD remote control memorizes the selected brand code. Notes • The remote control is programmed at the factory to operate TOSHIBA TVs. • A single brand may use different codes depending on the particular model. Enter the correct number referring to the brand code table. - Page 64 Brand code table Brand name Brand code TOSHIBA 0001 0071 0211 0571 BELL & HOWELL 0471 0651 0071 0281 0441 CARVER 0201 0251 0281 0411 0501 CITIZEN 0201 0251 CURTIS MATHES 0471 0651 0071 0281 0441 0311 0431 0521 0571...
-
Page 65: Before Calling Service Personnel
Others Before Calling Service Personnel Specifications LIMITED WARRANTY DVD PLAYER... -
Page 66: Before Calling Service Personnel
Others Before Calling Service Personnel Check the following guide for the possible cause of a problem before contacting service. Symptoms and correction Symptom Cause No power. • The power plug is disconnected. The DVD player turned off by • The automatic power off function turned itself. -
Page 67: Specifications
Specifications DVD player / outputs / supplied accessories DVD player Power supply Power consumption Mass External dimensions Signal system Laser Frequency range Signal-to-noise ratio Audio dynamic range Harmonic distortion Wow and flutter Operating conditions Outputs Video output S video output Component video output Audio output (BITSTREAM/PCM OPTICAL) -
Page 68: Limited Warranty Dvd Player
Others LIMITED WARRANTY DVD PLAYER Toshiba America Consumer Products, Inc. (“TACP”), Toshiba Hawaii (“THI”) and Toshiba Canada Limited (“TCL”) make the following limited warranties. These limited warranties extend to original purchaser or any person receiving this set as a gift from the original purchaser and to no other purchaser or transferee. - Page 69 Canadian consumers are requested to complete the special Canadian “Warranty Registration Form” enclosed, and forward this completed form with a copy of bill of sale to TOSHIBA OF CANADA to “Register and Validate” their warranty. Product must be purchased from an Authorized Canadian Dealer. Products purchased in the U.S.A. and used in Canada are not covered by these warranties.
