Page 1: Dvd Player
DVD PLAYER SD-890KY OWNER’S MANUAL © 2008 Toshiba Corporation DIGITAL VIDEO Introduction Connections Basic playback Advanced playback Function setup Others... -
Page 2: Introduction
Introduction SAFETY PRECAUTIONS CAUTION: VISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM. AVIS WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquid, such as vases, shall be placed on the apparatus. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 4: Precautions
Introduction Precautions Notes on handling When shipping the DVD player, the original shipping carton and packing materials come in handy. For maximum protection, repack the unit as it was originally packed at the factory. Take care not to give it a shock or shake when carrying. -
Page 5: Notes On Discs
Notes on Discs On handling discs Do not touch the playback side of the disc. Do not attach paper or tape to discs. On cleaning discs Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outwards with a soft cloth. -
Page 6: Playable Discs
Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot assure that this DVD player will successfully play every disc bearing the DVD and CD logos. -
Page 7: Table Of Contents
Table of Contents Introduction SAFETY PRECAUTIONS ... 2 IMPORTANT SAFETY INSTRUCTIONS ... 3 Precautions ... 4 Notes on Discs ... 5 Notes on region numbers ... 6 Table of Contents ... 7 Identification of Controls ... 8 Front panel ... 8 Rear panel ... -
Page 8: Identification Of Controls
Introduction Identification of Controls See the page in for details. Front panel Rear panel Power Cord DVD display The indicators vary depending on the kinds of discs you play. Bad disc Bad disc No disc DVD VIDEO VIDEO CD • During playback: •... -
Page 9: Remote Control
Identification of Controls (continued) The instructions in this manual describe the functions on the remote control. See the page in Remote control DVD button * RETURN button Return to menu display for VCD (2.0) discs with menu. HDMI button USB button * MENU button Use the MENU button to display the menu included on many DVDs. -
Page 10: Loading Batteries
Introduction Loading batteries Open the cover. Insert batteries (R03/AAA size). Make sure to match the + and – on the batteries to the marks inside the battery compartment. Caution • Never throw batteries into a fire. Notes • Be sure to use R03/AAA size batteries. •... -
Page 11: Connections
Connections Connecting to a TV Connect the DVD player to your TV. Connecting to a TV (Using the phono type jacks) Normal TV To audio To video input input (yellow) Notes • Refer to the owner’s manual of the connected TV as well. •... -
Page 12: Connecting To A Tv (Using The Component Video Jacks)
Connections Interlaced outputs Some TVs or monitors are equipped with component video inputs. Connecting to these inputs allows you to enjoy higher quality picture playback. Actual labels for component video inputs may vary depending on the TV manufacturer. (ex. Y, R-Y, B-Y or Y, C In some TVs or monitors, the colour levels of the playback picture may be reduced slightly or the tint may change. -
Page 13: Connecting To A Display
Connections About HDMI HDMI (High Definition Multimedia Interface) supports both video and audio on a single digital connection for use with DVD players, DTV, set-top boxes, and other AV devices. HDMI was developed to provide the technologies of High Bandwidth Digital Content Protection (HDCP) as well as Digital Visual Interface (DVI) in one specification. -
Page 14: Connecting To Optional Equipment
Connections Content of the output for each output jack is shown in the following table and differ depending on the On-Screen Display Setting: On-Screen Display Setting Content of output for each output jack "Video Output" HDMI Output Setting Setting * Component Invalid (Interlaced) -
Page 15: Connecting To An Amplifier Equipped With A Dolby
Connections Connecting to Optional Equipment (Continued) Connecting to an amplifier equipped with a Dolby Dolby Digital Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVDs with this dynamic realistic sound by connecting the DVD player to a 6 channel amplifier equipped with a Dolby Digital decoder or Dolby Digital processor. -
Page 16: Dts Decoder
Connections Connecting to an amplifier equipped with a DTS Digital Theater Systems (DTS) DTS is a high quality surround technology used in theaters and now available for home use, on DVDs or audio CDs. If you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS encoded sound tracks on DVDs or audio CDs. -
Page 17: Playing A Disc
Playing a Disc This section shows you the basics on how to play a disc. Basic playback Preparations • When you want to view a disc, turn on the TV and select the video input connected to the DVD player. •... -
Page 18: Variable Speed Playback
Basic playback Variable Speed Playback You can play discs at various speeds, and resume playback from the location where you stopped playback. Playing in fast reverse or fast forward directions Press REV or FWD during playback. REV: Fast reverse playback FWD: Fast forward playback Each time you press the REV or FWD button, the playback speed changes. -
Page 19: Locating A Desired Section
To start playback from the beginning regardless of the location where you stopped playback. 1 Press STOP twice. The DVD player deletes the memory of the location. 2 Press PLAY. Playback starts from the beginning of the current title. Playback starts from the beginning of the disc. Playback starts from the beginning of the current track. -
Page 20: Advanced Playback
Advanced playback Accessing a Specific Location Directly Locating a specific title/chapter/time Press T. Press to highlight the Title/Chapter/ Track/Time. e.g. SEARCH Track Time Disc Time Press to select a section you want to locate. e.g. When you want to locate a chapter. Press the number buttons to enter title, chapter (track) number or time. -
Page 21: Repeating A Specific Segment
Repeating a Specific Segment You can specify a desired segment and repeat it. Repeating a specific segment Press A-B RPT at the beginning of the segment (point A) you want to play repeatedly. A-B RPT Rep A- Press A-B RPT again at the end of the segment (point B). -
Page 22: Playing In A Favourite Order
Advanced playback Playing in a Favourite Order You can combine your favourite titles, chapters, or tracks and play them in the order you determine. You can program up to 12 selections into the memory. (Memory playback) Setting titles, chapters or tracks in a favourite order Insert a disc and press MEMORY during stop. -
Page 23: Zooming A Picture
Zooming a Picture You can magnify areas within a picture. Zooming a picture Press ZOOM during normal, slow or still playback. The centre part of the image will be ZOOM zoomed in. e.g. Each time you press the ZOOM button, the magnification level changes as follows: Press the ZOOM button to select the magnification level. -
Page 24: Selecting The Picture Enhancement (E
Advanced playback Selecting the Picture Enhancement (E.P.M.*) You can easily select a preferred picture enhancement. *E.P.M.: Enhanced Picture Mode Selecting the picture enhancement Press E.P.M. E.P.M The picture enhancement menu appears. Contrast Select the picture enhancement by pressing / , then press your selections. -
Page 25: Selecting The Camera Angle
Selecting the Camera Angle If the scene was recorded from multiple angles, you can easily change the camera angle of the scene you are watching. Changing the camera angle Press ANGLE while playing a scene recorded with multiple angles. ANGLE While playing a scene recorded with multiple angles, press the ANGLE button. -
Page 26: On-Screen Display Operation
Advanced playback On-screen Display Operation When you turn on the on-screen display, you can view information on operational status and access features and settings. On-screen display operation Press NAVI. NAVI The following display appears. e.g. When playing a DVD. Chapter number Elapsed time Remaining time Title number... -
Page 27: Playing Mp3 Files
Please be advised that you must obtain permission from the applicable copyright owners to download copyrighted content, including music files, in any format, including the MP3 formats, prior to the downloading thereof. Toshiba has no right to grant and does not grant permission to download any copyrighted content. “... -
Page 28: Viewing Jpeg Files
Advanced playback Viewing JPEG Files You can play JPEG files that have been recorded on a CD-R or CD-RW on the DVD player. You can select a preferred view: a page of 9 thumbnail images or a single image view. Also, rotating, enlarging and shifting of each image can be possible. -
Page 29: Playing Divx /Mpeg-4 Files
Press STOP to display a folder list. JPEG files compatibility Discs whose compatibility with this DVD player has been confirmed by TOSHIBA are as follows. CANON QuickCD Kodak Picture CD JPEG disc compatibility with this DVD player is limited as follows: •... -
Page 30: Playing Usb Device
USB flash drives that this player supports The connection of the following types of USB flash drives is confirmed on this player. • Toshiba USB Flash Drive (1GB) • PNY USB Flash Drive (2GB/4GB) (This player supports Full-Speed USB flash drives only.) To resume normal playback, press PLAY. -
Page 31: Customizing The Function Settings
Customizing the Function Settings You can change the default settings to customize performance to your preference. Setting procedure Press SETUP during stop. The following on-screen display appears. OSD language DivX subtitle DVD menu Press to select an option for the setting you want to change, then press . -
Page 32: Setting Details
Function setup Customizing the Function Settings (continued) Setting details Notes • Some DVDs may be set to display subtitles in a different language other than you selected. A prior subtitle language may be programmed on the disc. • Some DVDs allow you to change subtitle selections only via the disc menu. - Page 33 Aspect Ratio 1) Press SETUP button. 2) Press button to select Video. 3) Press button, then use the Aspect Ratio. 4) Press ENTER button, then use the and change the TV type. 5) Press ENTER button. 6) Press SETUP button to exit the menu. Aspect Ratio TV System Video out...
-
Page 34: Video Output
Function setup Customizing the Function Settings (continued) Setting details Video Output 1) Press SETUP button. 2) Press button to select Video. 3) Press button, then use the Video out. 4) Press ENTER button, then use the select the output mode (Component, P-Scan or HDMI). 5) Press ENTER button. -
Page 35: Parental Control Dvd
Bitstream: Disc audio raw data will be output. Select “Bitstream” if your amplifier supports “DTS”. Off: To disable Digital Output. Notes • When you make a connection to a TV, Dolby Surround Pro Logic or stereo system via the analogue audio jacks, select “PCM”... -
Page 36: Divx Registration
Function setup Customizing the Function Settings (continued) Setting details Set Password New Password can be set to replace the default password. 1) Press SETUP button. 2) Press button to select Rating. 3) Press button, then use the Password. 4) Press ENTER button. “Enter Password” screen will appear. -
Page 37: Hdmi Control
HDMI Control You can control this DVD unit from TV’s remote which is connected via HDMI cable. 1) Press SETUP button. 2) Press button to select Misc. 3) Press button, then use the HDMI Control. 4) Press ENTER button, then use the select the On or Off mode. -
Page 38: Others
Others Table of Languages Table of languages and their abbreviations Abbreviation Language – – – No alternate language CHI (ZH) Chinese DUT (NL) Dutch ENG (EN) English FRE (FR) French GER (DE) German ITA (IT) Italian JPN (JA) Japanese KOR (KO) Korean MAY (MS) Malay... -
Page 39: Before Calling Service Personnel
Others Before Calling Service Personnel Check the following guide for the possible cause of a problem before contacting service. Symptoms and correction Symptom Cause No power. • The power plug is disconnected. The DVD player turned off by • The automatic power off function turned the itself. -
Page 40: Specifications
Others Specifications DVD player / outputs / supplied accessories DVD Player Power supply Power consumption Mass External dimensions Signal system Laser Frequency range Signal-to-noise ratio Audio dynamic range Harmonic distortion Wow and flutter Operating conditions Outputs Video output Component video output Audio output (COAXIAL DIGITAL) Audio output (ANALOG) HDMI output...
