Changing Setup Menu
HDMI
Ø
This setting can only be used when the unit is
connected by HDMI to Display devices (TV,
Projector, etc.), otherwise the HDMI setting
cannot be selected.
- Resolution setting
• Auto : Resolution setting automatically
• Manual : Resolution setting manually
- Resolution
• 480p/576p : 720X480, 720X576
• 720p : 1280 x 720
• 1080i : 1920 x 1080
- Format
You can use this function to set HDMI
output's digital data RGB range.
• RGB-Normal : HDMI Limited range RGB
• RGB-Expand : HDMI Full range RGB data
• YCbCr-(4:4:4) : HDMI Limited range
• YCbCr-(4:2:2) : HDMI Limited range
Limited range - Black/White and colour level
displayed within Limited data range.
When the bit depth is 8 bits
- Y : 16~235 - levels of brightness
- CbCr : 16~240 - levels of colour
Full range - Black/White and colour level are
expressed within full data range.
When the bit depth is 8 bits
- Y : 0~255 - levels of brightness
- CbCr : 0~255 - levels of colour
- HD-JPEG
• HD : High Definition image source
- Available when resolution is 720p or
1080i in HDMI enabled.
• SD : Standard Definition image source
Resolution Setting
Resolution
Format
HD-JPEG
Page 66
data output.
output.
YCbCr-(4:4:4) output.
YCbCr-(4:2:2) output.
HDMI SETUP
: Auto
: 1080i
: RGB-Normal
: SD
• Consult your TV User's Manual to find
out if your TV supports Progressive Scan.
If Progressive Scan is supported, follow
the TV User's Manual regarding
Progressive Scan settings in the TV's
menu system.
• If Video Output is set incorrectly, the
screen may be blocked.
• The resolutions available for HDMI output
depend on the connected TV or projector.
For details, see the user's manual of your
TV or projector.
• When the resolution is changed during
playback, it may take a few seconds for a
normal image to appear.
• If you set the HDMI output resolution 720p
or 1080i, HDMI output provides better
picture quality.
• No sound will be output from the HDMI
cable if the Dolby/DTS Digital Out is not
set to PCM.
ENG-66
