- Page 1 DVD VIDEO PLAYER SD-240ESE SD-240ESB OWNER’S MANUAL © 2004 Toshiba Corporation DIGITAL VIDEO Introduction Connections Basic playback Advanced playback Function setup Others...
-
Page 2: Introduction
Introduction SAFETY PRECAUTIONS WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. CAUTION: This Digital Video Disc Player employs a Laser System. - Page 3 Location of the required label The rating plate and the safety caution are on the rear of the unit.
-
Page 4: Important Safety Instructions
Introduction IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. - Page 5 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
-
Page 6: Additional Safety Instructions
Introduction IMPORTANT SAFETY INSTRUCTIONS 13.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. - Page 7 18. Do not place a heavy object on or step on the apparatus. The object may fall, causing serious personal injury and serious damage to the apparatus. 19. Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and apparatus malfunction.
-
Page 8: Precautions
Introduction Precautions Notes on handling When shipping the DVD video player, the original shipping carton and packing materials come in handy. For maximum protection, repack the unit as it was originally packed at the factory. Take care not to give it a shock or shake when carrying. -
Page 9: Notes On Discs
Notes on Discs On handling discs Do not touch the playback side of the disc. Do not attach paper or tape to discs. On cleaning discs Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outwards with a soft cloth. -
Page 10: Playable Discs
Introduction Notes on Discs (continued) About this owner’s manual This owner’s manual explains the basic instructions of this DVD video player. Some DVD video discs are produced in a manner that allows specific or limited operation during playback. As such, the DVD video player may not respond to all operating commands. -
Page 11: Table Of Contents
Table of Contents Introduction SAFETY PRECAUTIONS ... 2 IMPORTANT SAFETY INSTRUCTIONS ... 4 Precautions ... 8 Notes on Discs ... 9 Notes on region numbers ... 10 Table of Contents ... 11 Identification of Controls ... 12 Front panel ... 12 Rear panel ... -
Page 12: Identification Of Controls
Introduction Identification of Controls See the page in for details. Front panel... -
Page 13: Rear Panel
Rear panel... -
Page 14: Remote Control
Introduction Identification of Controls (continued) The instructions in this manual describe the functions on the remote control. See the page in for details. Remote control * MENU button Use the MENU button to display the menu included on many DVD video discs. To operate a menu, follow the instructions in “Locating a title using the top menu.”... -
Page 15: Loading Batteries
Loading batteries Open the cover. Insert batteries (R03 size). Make sure to match the + and – on the batteries to the marks inside the battery compartment. Notes on batteries Improper use of batteries may cause battery leakage and corrosion. To operate the remote control correctly, follow the instructions below. -
Page 16: Connections
Connections Read this chapter first to make all necessary preparations. Connecting to a TV (Using the SCART socket) Connecting to a TV (Using the phone type jacks) Connecting to a TV (Using the component video jacks) Connecting to an amplifier equipped with a Dolby Digital decoder Connecting to an amplifier... -
Page 17: Connecting To A Tv
Connections Connecting to a TV Connect the DVD video player to your TV. For details of output sound, see 43 . Connecting to a TV (Using the SCART socket) Normal TV To SCART input SCART cable Connecting to a TV (Using the phono type jacks) Normal TV To VIDEO To audio... -
Page 18: Connecting To A Tv (Using The Component Video Jacks)
Interlaced outputs/inputs Some TVs or monitors are equipped with component video inputs. Connecting to these inputs allows you to enjoy higher quality picture playback. Actual labels for component video inputs may vary depending on the TV manufacturer. (ex. Y, R-Y, B-Y or Y, In some TVs or monitors, the color levels of the playback picture may be reduced slightly or the tint may change. -
Page 19: Connecting To Optional Equipment
Connections Connecting to Optional Equipment You can enjoy high quality dynamic sounds by connecting the DVD video player to optional audio equipment. • For connection to your TV, see “Connecting to a TV” 18 19 . • For details of output sound, see 43 . •... -
Page 20: Connecting To An Amplifier Equipped With A Dolby Digital Decoder
Connecting to an amplifier equipped with a Dolby Digital decoder Dolby Digital Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by connecting the DVD video player to a 6 channel amplifier equipped with a Dolby Digital decoder or Dolby Digital processor. -
Page 21: Connecting To An Amplifier Equipped With A Dts Decoder
Connections Connecting to Optional Equipment (Continued) Connecting to an amplifier equipped with a DTS decoder Digital Theater Systems (DTS) DTS is a high quality surround technology used in theaters and now available for home use, on DVD video discs or audio CDs. If you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS encoded sound tracks on DVD video discs or audio CDs. -
Page 22: Connecting To An Amplifier Equipped With A Digital Audio Input
Connecting to an amplifier equipped with a digital audio input 2 channel digital stereo You can enjoy the dynamic sound of 2 channel digital stereo by connecting an amplifier equipped with a digital audio input and speaker system (right and left front speakers). -
Page 23: Playing A Disc
Basic playback Begin your operation. Playing a Disc Variable Speed Playback Locating a Desired Section... - Page 24 Basic playback Playing a Disc This section shows you the basics on how to play a disc. Basic playback Preparations • When you want to view a disc, turn on the TV and select the video input connected to the DVD video player. •...
- Page 25 2, 4 STOP PLAY PAUSE MENU ENTER TOP MENU To pause playback (still mode) Press PAUSE/STEP during playback. To resume normal playback, press the PLAY button. • The sound is muted during still mode. To stop playback Press STOP. To remove the disc Press OPEN/CLOSE.
-
Page 26: Variable Speed Playback
Basic playback Variable Speed Playback You can play discs at various speeds, and resume playback from the location where you stopped playback. Playing in fast reverse or fast forward directions Press REV or FWD during playback. REV: Fast reverse playback FWD: Fast forward playback Each time you press the REV or FWD button, the playback speed... -
Page 27: Playing In Slow-Motion
Playing in slow-motion Press SLOW during playback. Each time you press the SLOW button, the slow-motion speed changes in the following sequence: Resuming playback from the same location Press STOP at the location where you want to interrupt playback. The DVD video player memorizes the location where playback is stopped. -
Page 28: Locating A Desired Section
Basic playback Locating a Desired Section Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. VIDEO CDs and audio CDs are divided into tracks. You can quickly locate any specific title, chapter, or track. DVD video disc Title 1 Chapter 1... -
Page 29: Locating A Desired Section By Entering The Corresponding Number
Locating a desired section by entering the corresponding number Press T. If you are using a VIDEO CD/audio CD, skip step 2. Then at step 3, enter the number for the track you want using the number buttons. e.g. Press to select a section you want to locate. - Page 30 Basic playback...
-
Page 31: Advanced Playback
Advanced playback Customizing the performance of your DVD video player. Accessing a Specific Location Directly Repeating a Specific Segment Playing in a Varied Order Playing in a Favorite Order Zooming a Picture Selecting the Picture Enhancement (E.P.M.) Selecting the Sound Enhancement (E.A.M.) Selecting the Camera Angle Selecting Subtitles... -
Page 32: Advanced Playback
Advanced playback Accessing a Specific Location Directly You can access a specific location by entering its corresponding time (hours, minutes, seconds). Entering the time counter of the desired location Press T several times. You may have to press further depending on the disc. Press the button repeatedly until the time counter is highlighted. -
Page 33: Playing In A Varied Order
Playing in a Varied Order You can play titles, chapters within a title, or tracks in a varied order. Playing titles, chapters or tracks in a varied order Press PLAY MODE. Press button to select desired features and then press ENTER button to toggle desired mode. -
Page 34: Playing In A Favourite Order
Advanced playback Playing in a Favourite Order You can combine your favorite titles, chapters, or tracks and play them in the order you determine. You can program up to 30 selections into the memory. (Memory playback) Setting titles, chapters, or tracks in a favourite order Insert a disc and press MEMORY during stop. -
Page 35: Zooming A Picture
Zooming a Picture You can magnify areas within a picture. Zooming a picture Press ZOOM during normal, slow or still playback. The DVD video player enters the zoom playback mode and displays the icon. e.g. Each time you press the ZOOM button, the magnification level changes as follows: Press the ZOOM button to select the... -
Page 36: Selecting The Picture Enhancement (E
Advanced playback Selecting the Picture Enhancement (E.P.M.*) You can easily select a preferred picture enhancement. *E.P.M.: Enhanced Picture Mode Selecting the picture enhancement Press E.P.M. The picture enhancement menu appears. Select the picture enhancement by pressing / , then press your selections. -
Page 37: Selecting The Sound Enhancement (E.a.m.)
Selecting the Sound Enhancement (E.A.M.*) You can easily switch a preferred audio enhancement. *E.A.M.: Enhanced Audio Mode Selecting the sound enhancement Press E.A.M. The sound enhancement will appear: 3D On Press the E.A.M. button again, the sound enhancement change to OFF. 3D*: To obtain expansive virtual surround sound effects from two speakers. -
Page 38: Selecting The Camera Angle
Advanced playback Selecting the Camera Angle If the scene was recorded from multiple angles, you can easily change the camera angle of the scene you are watching. Changing the camera angle Press ANGLE while playing a scene recorded with multiple angles. While playing a scene recorded with multiple angles, press the ANGLE button. -
Page 39: Selecting Subtitles
Selecting Subtitles You can display subtitles on the TV screen and select a subtitle language from those included on the DVD video disc. Selecting a subtitle language Press SUBTITLE during playback. The current subtitle setting is displayed. e.g. Press SUBTITLE while the subtitle setting is displayed on the TV screen. -
Page 40: Selecting A Language
Advanced playback Selecting a Language You can select a preferred language and sound recording system from those included on the DVD video disc. Selecting a playback audio setting Press AUDIO during playback. The current audio setting is displayed. e.g. Recorded audio format number changes sequentially. - Page 41 Output sound conversion table • Signals of 96kHz from the COAXIAL DIGITAL AUDIO OUT jack are depressed to 48 kHz by down sampling process when: – “3D On” is selected. 39 – a copyright protected disc is played. • Quantization bit of signals of 20 bit or higher which is output from the COAXIAL DIGITAL AUDIO OUT jack is 16 bit if they are in a copyright protected disc.
-
Page 42: On-Screen Display Operation
Advanced playback On-screen Display Operation When you turn on the on-screen display, you can view information on operational status and access features and settings. On-screen display operation Press NAVI. The following display appears. Each time you press the NAVI button, the on-screen display as follows. See the pages in e.g. - Page 43 On-screen Display Operation (Continued) On-screen display operation Viewing the operational status 1 Press DISPLAY. The following display appears. Title number Subtitle Setting 2 To turn off the display, press DISPLAY again. Bit rate (Mbit/s) Amount of picture, sound and subtitle data in the DVD video disc transferred per second.
-
Page 44: Playing Mp3/Wma Files
Advanced playback Playing MP3/WMA Files You can play MP3/WMA files that have been recorded on a CD-R or CD-ROM on the DVD video player. Playing MP3/WMA files Preparations • Make sure that a disc you want to play is compatible with this DVD video player. Place a CD that contains MP3/WMA files on the disc tray. - Page 45 (including CD-R containing MP3/WMA files). Given the fact that technology in this area is still maturing, Toshiba cannot guarantee that all genre of recordable discs will produce optimal playback quality. The technical criteria set out in this owner’s manual are meant as a guide only.
-
Page 46: Viewing Jpeg Files
Advanced playback Viewing JPEG Files You can play JPEG files that have been recorded on a CD-R or CD-ROM on the DVD video player. You can select a preferred view: a page of 9 thumbnail images or a single image view. -
Page 47: Viewing A Thumbnail View
Viewing a thumbnail view Press TOP MENU in full-screen review. To view the previous 9 images. Press the image, press PLAY to view one image in full-screen and automatically images will be displayed one by one again in a few seconds. Turn the page if necessary Press to highlight the PREV... - Page 48 Advanced playback JPEG files compatibility Discs whose compatibility with this DVD video player has been confirmed by TOSHIBA are as follows. Many of these discs, when loaded, will make the DVD video player enter the automatic mode folder in the disc. To play other folders, display a folder list and select a folder.
-
Page 49: Function Setup
Function setup You can change the default settings to customize performance to your preference. Customizing the Function Settings Table of Languages... -
Page 50: Customizing The Function Settings
Function setup Customizing the Function Settings You can change the default settings to customize performance to your preference. Setting procedure Press SETUP during stop. The following on-screen display appears. Press to select a symbol for the setting you want to change, then press ENTER. - Page 51 Setting Language OSD Menu Subtitle Audio DVD Menu Video TV Shape TV System Video Output Digital Output Audio Password Rating Rating Load Factory Details To select a preferred language for on-screen display. To select a preferred language for subtitles. To select a preferred language for the sound track.
-
Page 52: Setting Details
Function setup Customizing the Function Settings (continued) Setting details Language OSD Menu English: To view on-screen displays in English. Deutsch: To view on-screen displays in German. Français: To view on-screen displays in French. Español: To view on-screen displays in Spanish. Italiano: To view on-screen displays in Italian. - Page 53 Audio English: To play sound tracks in English. Deutsch: To play sound tracks in German. Français: To play sound tracks in French. Español: To play sound tracks in Spanish. Italiano: To play sound tracks in Italian. 1) Press ENTER. 2) Press to select the AUDIO.
-
Page 54: Video Output
Function setup Customizing the Function Settings (continued) Setting details Video TV Shape 1) Press to select the Video. 2) Press ENTER. 3) Press ENTER button, then press the shift and change the TV type 4) Press ENTER. 5) Press RETURN. 4:3 Pan Scan: Select when a standard 4:3 TV is connected. -
Page 55: Digital Out
Audio Digital Out Selected the output sound format corresponding to your system connection. 1) Press to select Audio. 2) Press ENTER. 3) Press ENTER button, then press and change the output sound format. PCM: Select when connected to a 2 channel digital stereo amplifier. - Page 56 Function setup Customizing the Function Settings (continued) Setting details (continued) The parental lock level is equivalent to the following ratings: Level 1: Kid Safe Level 2: G Level 3: PG Level 4: PG-13 Level 5: PG-R Level 6: R Level 7: NC-17 Level 8: Adult Indicates Parental lock is not active.
-
Page 57: Table Of Languages
Table of Languages Table of languages and their abbreviations Abbreviation Language – – – No alternate language CHI (ZH) Chinese DUT (NL) Dutch ENG (EN) English FRE (FR) French GER (DE) German ITA (IT) Italian JPN (JA) Japanese KOR (KO) Korean MAY (MS) Malay... -
Page 58: Others
Others Before Calling Service Personnel Specifications... -
Page 59: Before Calling Service Personnel
Others Before Calling Service Personnel Check the following guide for the possible cause of a problem before contacting service. Symptoms and correction Symptom Cause No power. • The power plug is disconnected. The DVD video player turned • The automatic power off function turned off by itself. -
Page 60: Specifications
Specifications DVD video player / outputs / supplied accessories DVD Video Player Power supply Power consumption Mass External dimensions Signal system Laser Frequency range Signal-to-noise ratio Audio dynamic range Harmonic distortion Wow and flutter Operating conditions Outputs Video output (SCART) Video output (Phone type) Component video output Audio output (COAXIAL DIGITAL) - Page 61 Printed in China 811-SD39A1-050...
