Summary of Contents for Topcom DIABLO 150
-
Page 3: Installation
Installation • Plug one end of the phone cable into the phone unit and the other end into the telephone line wall socket. Connect the small plug of the AC adaptor to the phone and the other end of the adapter cable to the electric socket. -
Page 4: Battery Low Indication
5.1.2 Call setup with dial preparation Enter the desired telephone number. An incorrect number can be corrected by means of the Mute button. Press the Off-hook button hook button when you want to terminate the call. - Page 5 When you press the R button, also called flash or recall, the unit generates a line interruption (of 100 ms or 250 ms). It gives you the possibility to use the special services of your telephone provider and/or to transfer calls when you have a telephone exchange. You can change the flash time if needed (See “Setting the Flash time”...
-
Page 6: Caller-Id Function (Clip)
Caller-ID function (CLIP) The Topcom Diablo displays the telephone numbers of incoming calls. This function is only possible if you are subscribed to a telephone operator that provides this service. Contact your telephone provider for more information. -
Page 7: Register A Handset
You want to subscribe a different handset to this base unit. The below procedure is only applicable to a Topcom Diablo handset and base unit!! Keep the Paging key on the base unit pressed for 10 seconds until the Line/Charge indicator on the base unit begins to blink rapidly. -
Page 8: Internal Call (Intercom)
Topcom Diablo 150/Twin/Triple/Quattro Internal call (intercom) In standby press and hold the INT key until INT appears . Enter the number (1-5) of the other handset. The other handset will start to ring. hook button you can talk internally. Answering machine The Diablo has a built-in digital answering machine with a recording capacity of 11 min. - Page 9 To record OGM 1 ‘4’ To record OGM 2 ‘5’ To select OGM 1 ‘6’ To select OGM2 ‘8’ To hear OGM menu again Topcom Diablo 150/Twin/Triple/Quattro Topcom Diablo 150/Twin/Triple/Quattro -Icon appear on the display in standby (or blink when there are...
-
Page 10: Operation
Topcom Diablo 150/Twin/Triple/Quattro Operation If a call is received and the answering machine is turned ON, the answering machine will automatically answer the call after the set number of rings. If outgoing message 1 has been selected, the message will be played, a beep will be heard and the caller can leave a message (max. -
Page 11: Troubleshooting
Max. talk time: Ambient temperature: Permitted relative air humidity: Power supply base adapter: Memories www.topcom.net U8006635 Topcom Diablo 150/Twin/Triple/Quattro Possible cause Batteries not charged Telephone cable not properly connected Wrong dial mode up to 300 m in open space up to 50 m in buildings DTMF (tone) and Pulse 2 x 1.2V, 550 mAh AAA Type NiMH rechargeable...
