Tokina TM22Z1022AI Specification Sheet

Motorized Zoom Lens
TM22Z1022AI
TM22Z1022GAIDC
TM22Z1022AIPN

■SPECIFICATION

Image Format
Focal length
Maximum Aperture
Aperture Range
Back Focal Length
M.O.D
Angle Diagonal
of View Horizontal
( )=1/3" Vertical
Filter Size
Dimensions
Weight
Temperature Range
Humidity Range
Mount
●AUTO IRIS (AI/AIPN)
Input Voltage
Current Consumption 30mA or Less
Input Signal
Iris Accuracy
Sensitivity
Response Speed
●Focus/Zoom
Input Voltage
Current Consumption 60mA or less
Response Speed
■Apperance
*Design and specifications are subject to change without notice
f=10-220mm F1:2.2-360 AUTO IRIS
f=10-220mm F1:2.2-360 DC IRIS
f=10-220mm F1:2.2-360 AUTO IRIS with Preset
1/2 inch (1/3 inch)
10-220mm
F:2.2-3.5
F:2.2 - 360
11.00mm
1.8m
W41.99°(32.11°) T2.17°(1.64°)
W34.14°(25.90°) T1.74°(1.31°)
W25.90°(19.53°) T1.31°(0.99°)
M67mm P=0.75
W80.0XH101.0XL158.7
800g
-10°C ~ +45°C
30% - 70%
C Mount
DC+8-16V
VS or V signal
±15% at Video Signal Level
0.5-1.0V-p-p at Video Signal Level
Approx. 1.5 Seconds
DC+6 - 12V
Approx. 4.5 Seconds
TOKINA Co.,Ltd.
Security Products Division
120-4 NOZUTA-MACHI,MACHIDA-SHI,
TOKYO, 195-0063 JAPAN
TEL:+81-42-734-8912 FAX:+81-42-735-1463
E-mail:cctv@tokina.co.jp
■Cable Conection
●DC IRIS (GAIDC)
Cable Color
White
Green
Black
Red
●AUTO IRIS (AI/AIPN)
Cable Color Connection
Red Power(DC+8-16V)
White VS or V signal
Green Not Used
Black GND
●Focus/Zoom
Cable Color Polarity
Black
Focus Red
Black
Red
Green
Zoom White
Green
White
●Preset Potentiometers(AIPN)
Cable Coler Connection
Purple POT. Return
Gray Zoom POT. Wire
Orange POT. Supply
Blue Focus POT.Wire
#Resistance : 5kΩ ±20% 0.19W
Pole Connection
3 Driving Coil +
4 Driving Coil -
2 Damping Coil +
1 Damping Coil -
Direction
+
INF.
-
-
Near
+
+
Wide
-
-
Tele
+
2003.09 TM22Z10
