Tokina VARIFOCAL LENS TVR2314DC Specifications

VARIFOCAL LENS
W/Asferical Glass
TVR2314DC
SPECIFICATION
MODEL NUMBER
MAXIMUM APERTURE
APERTURE RATIO
BACK FOCAL LENGTH
ANGLE
OF
VIEW
OPERATING TEMPERATURE RANGE
OPERATING HUMIDITY RANGE
CABLE COLOR CONNECTION
WHITE DRIVING COIL+
GREEN DRIVING COIL
BLACK DAMPING COIL+
RED DAMPING COIL
f = 2.3 - 6mm F 1.4 DC IRIS
IMAGE FORMAT
FOCAL LENGTH
M.O.D.
DIAGONAL
HORIZONTAL
VERTICAL
DIMENSIONS
WEIGHT
TOKINA Co.,Ltd.
Security Products Division
120-4 NOZUTA-MACHI,MACHIDA-SHI,
TOKYO, 195-0063 JAPAN
TEL:+81-42-734-8912 FAX:+81-42-735-1463
E-mail:cctv@tokina.co.jp
TVR2314DC
1/3inch
2.3 6mm
F1:1.4
F1:1.4 400
10.20mm
0.2m
W141.98° T60.16°
W114.75° T48.15°
W86.25° T36.09°
W56.3×H54.9×D43.0mm
100g/90g
10 45
30 70
