Tokina MONOFOCAL LENS TC0812AI Specification

MONOFOCAL LENS
TC0 12AI f= mm F1:1.2 VIDEO IRIS
SPECIFICATION
MODEL NUMBER
IMAGE FORMAT
FOCAL LENGTH
MAXIMUM APERTURE
APERTURE RATIO
BACK FOCAL LENGTH
ANGLE
OF
VIEW
FILTER SIZE
DIMENSIONS
OPERATING TEMPERATURE RANGE
OPERATING HUMIDITY RANGE
INPUT VOLTAGE
CURRENT CONSUMPTION
INPUT SIGNAL
IRIS ACCURACY
SENSITIVITY
RESPONSE SPEED
CABLE COLOR CONNECTION
RED POWER(DC+8V 16V)
WHITE VS OR V SIGNAL
GREEN REMOTE
BLACK GND
M.O.D.
DIAGONAL
HORIZONTAL
VERTICAL
WEIGHT
MOUNT
TOKINA Co.,Ltd.
Security Products Division
120-4 NOZUTA-MACHI,MACHIDA-SHI,
TOKYO, 195-0063 JAPAN
TEL:+81-42-734-8912 FAX:+81-42-735-1463
E-mail:cctv@tokina.co.jp
TC0812AI
1/3inch
8mm
F1.2
F1.2 360
8.38
0.3m
42.1°
33.5°
25.2°
W46.7×H32.5×D34.5mm
75g
10
30 70
CS
DC+8V 16V
35mA OR LESS
VS OR V SIGNAL
±15% AT VIDEO SIGNAL LEVEL
0.5 1.0Vp p
APPROX.1.5 SECONDS
45
AT VIDEO SIGNAL LEVEL
