Tokina Monofocal Lens TC0412AI Specification

MONOFOCAL LENS
TC0412AI
SPECIFICATION
MODEL NUMBER
IMAGE FORMAT
FOCAL LENGTH
MAXIMUM APERTURE
APERTURE RATIO
BACK FOCAL LENGTH
ANGLE
OF
VIEW
OPERATING TEMPERATURE RANGE
OPERATING HUMIDITY RANGE
INPUT VOLTAGE
CURRENT CONSUMPTION
INPUT SIGNAL
IRIS ACCURACY
RESPONSE SPEED
CABLE COLOR
RED
WHITE
GREEN
BLACK
f=4mm F1:1.2 VIDEO IRIS
M.O.D.
DIAGONAL
HORIZONTAL
VERTICAL
FILTER SIZE
DIMENSIONS
WEIGHT
MOUNT
SENSITIVITY
CONNECTION
POWER (DC+8V 16V)
VS OR V SIGNAL
REMOTE
GND
TOKINA Co.,Ltd.
Security Products Division
120-4 NOZUTA-MACHI,MACHIDA-SHI,
TOKYO, 195-0063 JAPAN
TEL:+81-42-734-8912 FAX:+81-42-735-1463
E-mail:cctv@tokina.co.jp
TC0412AI
1/3inch
4mm
F1.2
F1.2 360
8.49
0.3m
76.2°
63.8°
48.9°
W46.7×H32.5×D34.5mm
75g
10
30 70
CS
DC+8V 16V
35mA OR LESS
VS OR V SIGNAL
±15% AT VIDEO SIGNAL LEVEL
0.5 1.0Vp p AT VIDEO SIGNAL LEVEL
APPROX.1.5 SECONDS
45
