Nighthawk Packaging List
Congratulations on your purchase of a DSLRPros Nighthawk Aerial Kit. Inside your
Special Edition tough case you will find the following items with numbers that
correspond to the kit image on the following page.
1. DSLRPros LiPo Battery Guard Bag
2. DJI Phantom 1 With 2-Axis Tarot Gimbal Pre-Installed
3. Set Of 4 Self-Tightening Propeller Blades
4. DJI Remote Transmitter
5. Set Of 4 Propeller Guards
6. DSLRPros Lanyard For DJI Remote
7. USB Cable For Phantom 1
8. DSLRPros LiPo Battery Capacity Checker
9. Upgraded Transmitter
10. DSLRPros TXS-8 LiPo Charger With Power Cables and Balance Board
11. DSLRPros 7" FPV Field Monitor
12. Set Of Antennas For FPV Field Monitor
13. Field Monitor Cables
14. Set of 4 LiPo Batteries
15. FPV Field Monitor Charger
16. Sun Shade For FPV Field Monitor
17. String For Propeller Guards
18. Assorted Fasteners
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for dji DSLRPros Nighthawk Aerial Kit
Summary of Contents for dji DSLRPros Nighthawk Aerial Kit
- Page 1 Nighthawk Packaging List Congratulations on your purchase of a DSLRPros Nighthawk Aerial Kit. Inside your Special Edition tough case you will find the following items with numbers that correspond to the kit image on the following page. 1. DSLRPros LiPo Battery Guard Bag 2.
- Page 3 READ ALL TOPICS BEFORE USING YOUR CRAFT FOR THE FIRST TIME New pilots should NOT fly the Phantom 1 with the Gimbal attached until they have had at least 10 hours of flight practice. Please read through the DJI Manual for the Phantom 1 before using your craft.
- Page 4 Turning On Your Transmitter and Phantom 1 • Always turn on your transmitter before turning on your craft. To turn on our transmitter press the power switch to the "on" position. Make sure your throttle is all the way down and the toggle switches are in the uppermost position before turning on your transmitter.
- Page 5 This list will help users understand the different LED light combinations on the Phantom 1. • Initialization: 3 steady flashing yellow lights (1,2,3, pause, 1,2,3, pause, 1,2,3, pause). • Satellite Searching: 3 green blinks with 1-3 red blinks. This process will go down from 3 to 2 to 1 red blinks as the craft establishes a GPS lock.
- Page 6 The Phantom 1 supports multiple flight modes that allow users to control their craft in different ways. These modes can be switched while in flight by using the toggles on the DJI transmitter. • Attitude Mode: Maintains altitude but the craft will keep moving in one direction when influenced by wind or inertia.
- Page 7 • For added security, thread the white string included with your purchase through the eyes of the propeller guards. Updating Your Software It is recommended that you periodically check for software updates using the DJI assistant software application. • Plug the Phantom 1 into your PC or Mac using the USB cable provided.
- Page 8 • Go to the “Upgrade” tab. • If upgrades are available, check with DSLRPros to ensure that the upgrade is necessary before installing. Battery Safety It is vital to the safety of your aerial craft, yourself, and others that you practice proper battery safety when using, charging, and storing all batteries used with your Phantom 1.
- Page 9 2) Unplug the power connector. 3) Remove the Tarot board by unscrewing the screws in the four corners of the board. Return the screws to their holes after removing the board. 4) Unplug the two connectors while paying close attention to their original location into T (tilt) or - (ground).
- Page 10 5) Remove the front mounting screw with a screwdriver. To remove the rear mounting screw you will need to open the battery compartment door and grip the black nut on the inside bottom of the craft. While holding the nut with the pliers, unscrew the rear mounting screw. Your Tarot gimbal can now be removed from the Phantom.
