Toastmaster A720PA Specification Sheet

Double Sandwich Grills
Models and plate configuration:
A720PA - Grooved upper and lower
A720SA - Smooth upper and lower
A720S/PA - Left side upper and lower smooth
and right side upper and lower grooved
Standard Features:
• Heavy duty cast iron griddle plate
• Stainless steel construction
O O
• 150 F - 450 F thermostat
• Dual handle control
• Heavy duty hinge system
• ABS control dial
• Adjustable feet
• Easy to remove and
clean waste tray
Model Shown: May ship UPS
Application:
Toastmaster A720 Series Sandwich
grills are designed to uniformly grill
both sides of a sandwich at the
same time. To add to the grills
versatility, the left and the right side
have separate heat controls.
General Information:
With a grilling surface of 17-
wide and 9 inches deep, this grill has
the ability to grill sandwiches that are
1
up to 2- / thick!! Because the top
4
opens to a 90 degree angle, you
have the ability to just use the bottom
cooking plates.
Construction:
Heavy-duty in construction, the
double sandwich grill is manufactured
with heavy-duty cast iron plates.
This unit has some of the thickest
cast steel plates available for this
machine and allows for greater heat
retention once the unit is heated.
This unit also comes with a
removable grease tray.
Toastmaster ®
5600 13th Street, Menominee, MI 49858 • www.toastmastercorp.com
Toll Free: 1-800-338-9886 • Telephone: 1-906-863-4401 • Fax: 1-906-863-5889
Capacity:
Grills up to 4 sandwiches at one time.
Heating:
Heavy-duty elements are located
close to the castings so that the
heat build up is quicker than most
of our competitors and creates
greater electrical efficiency.
1 / inches
Grill will heat to temperature in
2
five minutes.
Controls:
Both the left and right side are
controlled by an adjustable
thermostat with a range of
150 O F to 450
Electrical:
Total rated input is 2.9KW for the
208V and 3.2KK for the 240V unit.
All unit are equipped with a factory
installed cord and NEMA 6-15P Plug.
Foodservice Equipment
Job
A720PA663
Cooking Surface:
All models come with
heavy-duty cast iron plates.
The A720PA has a grooved
grilling surface.
The A720SA has a smooth
grilling surface.
The A720S/PA has on the left
upper and lower plates smooth
and the right upper and lower
plates grooved for the most
versatile grilling surface
available.
Warranty:
O F with an off position.
One year parts and labor
warranty. Call factory for
warranty authorization.
Item#
