Superior P0055-DRG Homeowner's Care And Operation Instructions Manual

B-vent ghc/grd-5500 series gas fireplaces
Hide thumbs
Table of Contents

Advertisement

Quick Links

RETAIN THESE INSTRUCTIONS
WARNING: IF THE INFORMATION IN THIS MANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone.
Follow your gas suppliers instructions.
• If your gas supplier cannot be reached, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
GRD-5500 SHOWN
FOR FUTURE REFERENCE
WH Report No. J20046562
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
HOMEOWNER'S CARE AND

OPERATION INSTRUCTIONS

B-VENT
GHC/GRD-5500 SERIES
B-VENTED GAS FIREPLACES
P/N 725,029M REV. C 07/2004
MODELS
M
l i
v i l
t l o
M
o
e d
s l
G
H
- C
5 5
0 0
G
H
- C
5 5
0 0
G
R
- D
5 5
0 0
G
R
- D
5 5
0 0
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE POUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser
d'essence ni d'autre vaperurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appeflez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un qualifié
installer, agence de service ou le fournisseur de gaz.
E
e l
r t c
n o
c i
M
o
e d
s l
N
G
H
- C
5 5
0 0
N
E
2 -
P
G
H
- C
5 5
0 0
P
E
2 -
N
G
R
- D
5 5
0 0
N
E
2 -
P
G
R
- D
5 5
0 0
P
E
2 -
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P0055-DRG and is the answer not in the manual?

Questions and answers

Related Manuals for Superior P0055-DRG

Summary of Contents for Superior P0055-DRG

  • Page 1: Operation Instructions

    GRD-5500 SHOWN RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE WH Report No. J20046562 WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO- SION MAY RESULT CAUSING PROPERTY DAM- AGE, PERSONAL INJURY OR LOSS OF LIFE. FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids in the vicin- ity of this or any other appliance.

  • Page 2: Table Of Contents

    CONGRATULATIONS! In selecting this Superior B-vented gas appliance you have chosen the finest and most dependable fireplace to be found anywhere. A beautiful, prestigious, alternative to a wood burning fireplace. Welcome to a Family of tens of thousands of satisfied Superior Fireplace Owners.

  • Page 3: Operation/Care Of Your Appliance

    Millivolt appliances may be fitted at time of manufacture with either a Robertshaw millivolt gas control valve or Robertshaw electronic gas control valve. Both valves have been tested with and approved for use with these appli- ances and are listed accordingly. "...

  • Page 4: Control Knob

    CONTROL KNOB MILLIVOLT GAS CONTROL VALVE Figure 3 Operation of millivolt and electronic gas con- trol systems are different. Before lighting and operating your appliance determine if you have a millivolt or electronic appliance. Millivolt appliances will be fitted with the gas control valve shown in Figure 3.

  • Page 5: Maintenance

    Maintenance The appliance and venting system should be thoroughly inspected before initial use and at least annually by a qualified service techni- cian. Proper maintenance and use will require more frequent, less extensive inspections and servicing by the homeowner. Generally, annual inspections should be per- formed by a qualified service technician.

  • Page 6: Maintenance Schedule

    Maintenance Schedule Annually (Before the onset of the Burning Season) Maintenance Task Inspecting/Cleaning Burner, Logs and Controls Check Flame Patterns and Flame Height Inspecting/Cleaning Pilot and Burner Checking Vent System Appliance Checkout Replacing Rockwool Ember Materials Periodically (After the Burning Season) Maintenance Task Cleaning Firebox Interior Check Flame Patterns and Flame Height...

  • Page 7: Millivolt Appliance Checkout

    Logs and Rockwool (Glowing Embers) Placement WARNING: LOGS GET VERY HOT AND WILL REMAIN HOT UP TO ONE HOUR AFTER GAS SUPPLY IS TURNED OFF. HANDLE ONLY WHEN LOGS ARE COOL. TURN OFF ALL ELECTRICITY TO THE APPLIANCE BEFORE YOU INSTALL GRATE AND LOGS.
  • Page 8 Figure 12 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. Carefully position and center the fiber logs onto the burner grate with the longer log in front and the shorter log all the way to the back of the fireplace. Place the two (2) smaller fiber logs across the two (2) lower logs in the manner illustrated (Figures 12 ) .

  • Page 9: Wiring Diagrams

    WIRING DIAGRAMS Wiring diagrams are provided here for refer- ence purposes only. This information is also provided on schematics attached directly to the appliance on a pullout panel located within the control compartment. CAUTION: LABEL ALL WIRES PRIOR TO DIS- CONNECTION WHEN SERVICING CONTROLS.

  • Page 10: Lighting Instructions - Millivolt

    WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. This appliance has a pilot which must be lighted with a piezo ignitor. When lighting the pilot, follow these instructions exactly.

  • Page 11: Instructions D'allumage

    INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.

  • Page 12: Lighting Instructions - Electronic

    WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. When lighting the appliance, follow these instructions exactly. B. BEFORE OPERATING smell all around the appliance area for gas.
  • Page 13 INSTRUCTIONS D’ALLUMAGE — ELECTRONIC POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.

  • Page 14: Troubleshooting The Millivolt Gas Control System

    TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM Note: Before troubleshooting the gas control system, be sure external gas shut off valve (located at gas supply inlet) is in the “ON” position. Important: Valve system troubleshooting should only be accomplished by a qualified service technician. SYMPTOM 1.

  • Page 15: Troubleshooting The Electronic Ignition System

    TROUBLESHOOTING THE ELECTRONIC IGNITION SYSTEM ote: Before troubleshooting, be sure that the appliance main line gas shut-off valve, the gas control valve and the wall switch are in the “ON” position. Important: “ON/OFF” switch must be “OFF” before performing continuity test. Adjust multimeter to the ohm setting when performing continuity tests. Important: Valve system troubleshooting should only be accomplished by a qualified service technician.

  • Page 16: Accessory Components

    ACCESSORY COMPONENTS Remote Control System (Standard) H0249 Standard Remote Control System (Model RCL) The Model RCL (Standard) Remote Control System, features a simplistic on/off control function for the fireplace. This model includes a hand-held transmitter, a remote receiver with wall-mount coverplate and all hardware required to install the unit.

  • Page 17: Replacement Parts List

    REPLACEMENT PARTS LIST MILLIVOLT SYSTEM , r a , r a , l e l l u , y r t e l , r a , t n t f e c t i l l a l l o , r a GAS CONTROLS—...
  • Page 18 REPLACEMENT PARTS — MILLIVOLT At Rear of FireBox At Rear of FireBox NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
  • Page 19 REPLACEMENT PARTS LIST ELECTRONIC SYSTEM , l e l l u , y r t e l , r a , t n t f e c t i l l a l l o , r a GAS CONTROLS— ROBERTSHAW ELECTRONIC t o l i t i i t i...
  • Page 20 REPLACEMENT PARTS — ELECTRONIC The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information. Printed in U.S.A. © 2001 by Lennox Hearth Products P/N 725,029M REV.
