Changing The Reversible Door - Daewoo FR-045DDRWE Manual

Changing the Reversible Door

Before reversing the door swing, ensure the appliance is unplugged and empty. Provide
additional support for the doors while hinges are being removed. Do not depend on the door
magnets to hold the door in place. It is recommended that two people perform this task. DO
NOT lay the appliance completely flat as this may damage the coolant system.
Door parts
Top hinge
Top hinge washer
Middle hinge washer
Middle hinge
Step 1
Remove top hinge cover. Unscrew
and remove the top hinge and top
Step 3
Remove the screws from the
middle hinge. Lift refrigerator door
up and away from the appliance
Bottom right hinge
Right pin assembly (2)
Screw
Step 2
Lift the freezer door up and away
from the appliance.
Step 4
Remove the bottom hinge by removing the leveling.
leg and screw on the bottom of the refrigerator cabinet.
To reattach the hinge on the opposite side of cabinet,
first remove the leveling leg. Reattach the hinge using
the screws that were previously removed. Reattache
both leveling legs
8
Included parts
Left pin assembly (2)
Bottom left hinge
