Kanomax 6332 Operation Manual

Air flow transducer
Hide thumbs Also See for 6332:
Table of Contents

Advertisement

Quick Links

Download this manual
netzerotools.com
netzerotools.com
Kanomax 6332 Airflow Transducer Air Velocity Sensor Anemometer
Kanomax 6332D Airflow Transducer Air Velocity Sensor Anemometer
AIR FLOW TRANSDUCER
MODEL 6332/6332D
Oper ation Manual
Please read this manual carefully and understand the warnings
described in this manual before operating the product.
Keep this manual handy for ready reference
netzerotools.com
02001
0809

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6332 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kanomax 6332

Summary of Contents for Kanomax 6332

  • Page 1 Kanomax 6332 Airflow Transducer Air Velocity Sensor Anemometer Kanomax 6332D Airflow Transducer Air Velocity Sensor Anemometer AIR FLOW TRANSDUCER MODEL 6332/6332D Oper ation Manual Please read this manual carefully and understand the warnings described in this manual before operating the product.
  • Page 2 Thank you for purchasing a product of Kanomax, Inc. Please read this operation manual carefully and operate the instrument appropriately by following the instructions given in this manual. netzerotools.com...
  • Page 3 Component List ■ Standar d Item Model Remarks Airflow Transducer 6332 － Main Unit (Without Display) Airflow Transducer 6332D － Main Unit (With Display) ■ Pr obe & Cable (Sold Separ ately) Item Model Remarks 0962-00 Uni-directional 0963-00 0964-01...
  • Page 4 netzerotools.com Impor tant Safety Infor mation In this operation manual, warning types and classifications are defined as follows. [Classifications] Danger : To Pr event Ser ious Injur y or Death Warnings in this classification indicate danger that may result in serious injury or death if not observed.
  • Page 5 netzerotools.com Danger ○ Never br ing the pr obe close to a flammable gas atmospher e. --- The heated sensor may cause fire or explosion. Do not use near flammable gas ○ Never disassemble, modify or r epair the instr ument. --- Failure to observe the above may cause short circuit and malfunction.
  • Page 6 netzerotools.com Caution ○ Do not use or leave the instr ument in a high temper atur e/humidity envir onment, or in a dusty envir onment. The instr ument must also not be left under dir ect sunlight for a pr olonged per iod. Prohibited --- The instrument may not function properly outside Installation...

  • Page 7: Table Of Contents

    netzerotools.com Table of Contents Names and Dimensions of Components............1 System Configuration Example..............5 Connecting the Probe Cable to the Main Unit ..........6 Connecting the Probe Cable to the Probe............. 6 Installing the Data ROM................7 Switching Output (Setting Current/Voltage and Output Range)....8 Connecting Output and Power Supply............

  • Page 8: Names And Dimensions Of Components

    Names and Dimensions of Components (1) Model 6332 View inside the Case Probe Cable Connector Output Changeover Range Changeover Switch Switch ROM Socket Output and Power Terminal Blocks netzerotools.com...
  • Page 9 netzerotools.com (2) Model 6332D View inside the Case Probe Cable Connector Display Substrate Output Changeover Range Changeover Switch Switch ROM Socket Output and Power Terminal Blocks netzerotools.com...
  • Page 10 (3) Model 6332 View with the Case 4-φ4.5 Hole netzerotools.com...
  • Page 11 netzerotools.com (4) Model 6332D View with the Case 4-φ4.5 Hole netzerotools.com...

  • Page 12: System Configuration Example

    netzerotools.com System Configuration Example Probe (Sold Separately) Probe Cable (Sold Separately) Display (Only for 6332D) AC Adapter (Optional) Output Cable (Not Provided) netzerotools.com...

  • Page 13: Connecting The Probe Cable To The Main Unit

    netzerotools.com Connecting the Probe Cable to the Main Unit <Caution> Make sure to cut the power supply to the main unit before connecting the probe cable (sold separately). The probe cable must be wired separately from the power line. Match the concave part of the main unit connector with the convex part of the cable connector (4-pin), and click them in (not a screw type).

  • Page 14: Installing The Data Rom

    netzerotools.com Installing the Data ROM <Caution> Make sure to cut the power supply to the main unit before installing the Data ROM. Install the correct Data ROM that corresponds to the probe number. Position the Data ROM in the correct orientation. After confirming that the Data ROM is properly set, use the flat-blade screwdriver to rotate the cam 90 degrees clockwise to lock it in.

  • Page 15: Switching Output (Setting Current/Voltage And Output Range)

    netzerotools.com Switching Output (Setting Current/Voltage and Output Range) <Caution> Make sure to cut the power supply to the main unit before switching the current/voltage output. Output can be set by either voltage output (0 to 5V) or current output (4 to 20mA). (The factory default setting is provided with current output.) 1.
  • Page 16 netzerotools.com Output Changeover DIP Switch Range Changeover Rotary Switch netzerotools.com...

  • Page 17: Connecting Output And Power Supply

    netzerotools.com Connecting Output and Power Supply <Caution> Pay attention to the polarity of power supply when connecting. Power supply voltage must be DC 12 to 24V. FG Terminal DC-IN Term. FG (*1) Power Supply Input (-) DC-IN Term. Power Supply Input (+) Signal Output (-) OUT Term.

  • Page 18: Measurement Method

    netzerotools.com Measurement Method 1. Using the Uni-directional Probe (Model 0962-00, 0963-00) These probes have directivity characteristics which require the direction mark to be faced against the airflow for measurement. When you are not sure of the airflow direction, slowly rotate the probe in the horizontal direction, and select the point where the air velocity reading is maximum.

  • Page 19: Optional Accessory

    0 ~ 50.0 0.0 ~ 50.0 To add the display substrate to a unit without a display (Model 6332): Position the substrate in the correct orientation, and fix the substrate with the supplied two screws carefully not to bend the connection pins.

  • Page 20: Ac Adapter

    2. AC Adapter (Model 6332-02) <Caution> Do not connect the AC plug to the power receptacle before connecting the DC plug to the main unit. Failure to observe the above may cause short circuit and damage to the AC adapter.

  • Page 21: Cleaning The Probe

    netzerotools.com Cleaning the Probe If any impurities such as dust, soot and oil are attached to the sensor, the amount of heat that the airflow draws from the sensor surface (heat dissipation rate) will change, thus the air velocity reading will be affected.

  • Page 22: Specification Of Main Unit

    Specification of Main Unit Product Name Airflow Transducer (with / without Display) Model 6332 / 6332D Measuring Object Clean Airflow Measuring Range Maximum range 0.1 ~ 50 m/s (Depending on the measurement range of the probe*) Measuring Accuracy ± (3% of reading + 0.1) m/s 0.1-4.99m/s...

  • Page 23: Specification Of Probes (Sold Separately)

    netzerotools.com Specification of Probes (Sold Separately) MODEL Measuring Range Sensor Type 0962-00 Uni-directional 0963-00 0.1~50.0m/s 0964-01 Omni-directional (Needle) 0964-02 0965-00 0.1~25.0m/s Omni-directional (Spherical) 0965-01 Mini-temperature-compensation-sensor 0965-03 integrated type 0965-04 Omni-directional (Spherical) 0.1~25.0m/s Mini-temperature-compensation-sensor 0965-07 independent type 0965-08 Omni-directional (Spherical) Air Velocity Sensor Air Velocity Sensor Air Velocity Sensor Temp.
  • Page 24 netzerotools.com Air Velocity Sensor Temp. Compensation Sensor Air Velocity Sensor Temp. Compensation Sensor Shielded Cable I-type L-type 00: protruding tip 01: no protrusion Air Velocity Sensor Temp. Compensation Sensor seSensor Shielded Cable I-type L-type netzerotools.com...

  • Page 25: Troubleshooting

    netzerotools.com Troubleshooting Please check the following list before requesting a repair: Symptom Possible Cause Solution (& Reference Page) No Output The main unit is not turned on. Supply power to the main unit. (Page 10) Wrong wiring of the output terminal. Provide proper wiring.

  • Page 26: Product Warranty And After Service

    For further information, please contact our service center. When making an inquiry, please provide the following information. Please inform us: Product Name: Air Transducer Model Number: 6332 or 6332D Serial Number: xxxxxx Probe Model: Your Probe Model Description of Symptom in detail.

  • Page 27: Contact Information

    netzerotools.com Contact Information netzerotools.com...
