- Page 1 INSTRUCTION MANUAL Electric Pressure Washer SKY4100 Ver. 1...
- Page 2 NOTICE Please retain these instructions for future reference. • Machine is not a toy. Keep out of reach of children. • Do not allow children to operate this item. • Machine is intended for household use. • Use machine on a flat and stable surface. •...
-
Page 3: Specifications
SPECIFICATIONS Rated Pressure 1015 psi Max Pressure 1500 psi Max Inlet Pressure 44 psi Rated Flow 5.0 l/min Max. Flow 7.2 l/min Rate Voltage 120V Rated Frequency 50~60Hz Rated Power Input 1400 W Degree Of Protection IPX5 Sound Power Level 98 dB(A) Sound Pressure Level 80 ±3 dB(A) - Page 4 PARTS HANDLE HOSE WRAP SPRAY GUN HOLDER 1 PC 1 PC 1 PC SPRAY GUN LANCE NOZZLE 1 PC 1 PC 1 PC SOAP BOTTLE CLEANING PIN HIGH PRESSURE HOSE 1 PC 1 PC 1 PC INLET CONNECTOR 1 PC...
- Page 5 DIAGRAM HANDLE ON/OFF SAFETY LATCH SWITCH OUTLET HIGH PRESSURE HOSE NOZZLE SPRAY GUN LANCE HOSE WRAP SPRAY GUN HOLDER POWER CORD INLET...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the part A handle with two part 1 screws. Attach the part B hose wrap with four part 2 screws. - Page 7 PRODUCT ASSEMBLY Slide the part C spray gun holder onto the machine. Screw the part J inlet connector onto the inlet. Insert the narrow end of the part I high pressure hose into the part D spray gun. Insert the part E lance into the spray gun and turn it clockwise to lock it in place. Insert the part F nozzle into the lance.
- Page 8 PRODUCT ASSEMBLY Screw the high pressure hose onto the outlet. Screw a water supply hose (not included) onto the inlet connector and attach the other side to a water supply tap.
-
Page 9: Usage Tips
USAGE TIPS • Operating area must be clear of all persons. • Machine is not intended to connect to a potable water main. • Hold nozzle tightly during operation as there may be sudden kickback force. • Only use specific cleaning agents designed for use with a pressure washer. •... -
Page 10: Switching Off
SOAP BOTTLE ATTACHMENT To remove dirt more e ectively, add detergent to the spray with the soap bottle attachment. Only use specific cleaning agents designed for use with a pressure washer. Add a diluted mixture of detergent and water to the part G soap bottle. -
Page 11: Troubleshooting
STORAGE • Do the following to completely drain machine of water prior to storage: - Turn o machine and detach water hose/accessories. - Turn on machine and press the trigger to expel all remaining water from the machine and spray gun. - Turn o machine and unplug. -
Page 12: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
