MAINTENANCE INSTRUCTIONS
CLEANING
High pressure water jet cleaning should not used on this cabinet.
The use of bleach, caustic solutions and abrasive materials is not recommended.
The cabinet should be cleaned (inside and out) with a damp cloth using a mild detergent
solution.
Dust will collect on top of the cabinet therefore it should be cleaned at least once a year or
more frequently depending on the location of the unit and it's application.
A lint filter, situated inside the cabinet and above the hanging rail assembly, should be
periodically removed and cleaned with a soft brush.

TECHNICAL DATA

Capacity:
8kg (approx. weight)
general laundry textiles.
Evaporation rate:
81 g/min.
Electrical supply:
230v, 50Hz, a.c.
400v , 50Hz, a.c.
Motor:
2 x 85 W.
Heating element:
6kW
Overheat cut-out:
Yes.
Timer:
Automatic sensor
Dimensions:
Height. 1845mm.
(Overall)
Depth. 610mm.
Width. 1195mm.
Net Weight:
134kg.
Colour:
White/Grey.
PERFORMANCE SPECIFICATION
SETTING
WHITES / COLOURS
SYNTHETICS
*Values quoted above are approximations and will vary with type of load and ambient conditions
Installation and Operating Manual
Or
TEMPERATURE
70 - 80 deg. C
60 - 70 deg. C
MANUFACTURING
APPROVALS
Protection class IP X4
Page 9
