OPERATING INSTRUCTIONS

USER GUIDE
WARNING
To reduce the risk of fire, electric shock, or
injury to the person, read the IMPORTANT
SAFETY INSTRUCTIONS before operating
this appliance.
Model TS-5121
The cabinet is fitted with a stainless steel
hanging rail mounted on a spindle. The
assembly can be moved outwards to assist
the loading process. The assembly is
comprised of either four or five horizontal
rails at alternate
levels as shown below
Option
The cabinet can be fitted with a single
stainless steel hanging rail (not shown)
instead of the standard assembly. This
arrangement may suit longer garments.
Loading the cabinet
It is recommended that longer items of
laundry are located to the top section of
rails with shorter items towards the lower
set of rails.
Shoes, trainers and other
items can be placed in the base of the unit.
Laundry items should be spread evenly
over the rails to ensure consistent drying.
This method of loading will assist the
drying process by allowing
flow of warm air through the cabinet. Do
not block the warm air ducts on the inside
panels.
Page 8
CONTROLS
The cabinet is supplied with a simple to
use touch pad with two heat settings for
ease
Synthetics. Both options are controlled by
moisture sensors and will automatically
switch the power off when then the laundry
has reached the correct level of dryness.
An automatic
approximately 8 minutes is built into each
cycle.
To operate the drying cabinet sort the
laundry in cottons or synthetic loads, select
the appropriate setting, then press start.
The buttons are also written in Braille to
assist those with poor sight.
The control panel also has two warning
lamps to alert users that the lint filter
requires cleaning requires cleaning. The
right hand lamp will indicate that
problem
illuminated.
TROUBLESHOOTING
In case of overheating the drying process will
stop and three lamps on the control panel will
flash.
inside the top panel
necessary.
cooled down to its operating level, only the
overheat warning lamp will flash. It is now
possible to re-set by pushing and holding the
Stop button for 10 seconds.
The cabinet will stop automatically if the filter
is blocked and the Clean Filter warning
symbol will flash. To remedy, clean the filter
and re-set by pressing and holding the stop
button as above
WARNING:
the efficient
Do not place laundry or any other items on top
of the cabinet.
of
use,
Whites/colours
cool down period of
exists
with
heating
Check and
clean the filter located
of the cabinet if
When the temperature has
Installation and Operating Manual
and
a
when
