DISHWASHER INSTALLATION INSTRUCTIONS
IMPORTANT INSTRUCTIONS ....................... 1
Tools Needed ..................................................... 2
Materials Needed ............................................... 2
Materials Supplied .............................................. 3
Enclosure Preparation ....................................... 4
Electrical Preparation ........................................ 5
Plumbing Preparation ..................................... 6-7
Dishwasher Preparation ................................. 7-8
Door Panel Installation ....................................... 9
WARNING - OBSERVE ALL WARNINGS AND CAUTIONS
These instructions are intended for use by qualified installers only.
In addition to these instructions, the dishwasher
shall be installed:
• In accordance with all local codes or, in the
absence of a local code,
• In the United States, with the National Electric
Code.
• In Canada, with the Canadian Electric Code
C22.1 -latest edition/Provincial and Municipal
codes and/or local codes.
Read these installation instructions completely
and follow them carefully. They will save you
time and effort and help to ensure safety and
optimum dishwasher performance.
CAUTION
If the dishwasher is installed in a
:
location that experiences freezing temperatures
(e.g., in a holiday home), you must drain all the
water from the dishwasher's interior. Water system
ruptures that occur as a result of freezing are not
covered by warranty.
P/N 9000039271 (8408)
Table of Contents
Placing the Dishwasher ................................... 10
Securing the Dishwasher ................................ 10
Drain Hose Connection .................................... 11
Hot Water Connection ..................................... 12
Electrical Connection .................................. 13-14
Door Tension Adjustment ................................. 14
Base and Toe Panel .................................... 14-15
Final Instructions .............................................. 15
Customer Service ............................................ 16
IMPORTANT INSTRUCTIONS
IMPORTANT
• The dishwasher drain hose must be installed
with a portion of it at least 20" (508mm) off the
cabinet floor; otherwise the dishwasher may not
drain properly.
• This dishwasher is intended for residential use
only, and should not be used in commercial food
service establishments.
• NEW INSTALLATION - If the dishwasher is a
new installation, most of the work must be done
before the dishwasher is moved into place.
• REPLACEMENT - If the dishwasher is replacing
another dishwasher, check the existing
dishwasher connections for compatibility with
the new dishwasher, and replace parts as nec-
essary.
Inspect the Dishwasher
After unpacking the dishwasher and prior to instal-
lation, thoroughly inspect the dishwasher for
possible freight or cosmetic damage. Report any
damage immediately. Cosmetic defects must be
reported within 5 days of installation.
NOTE: Do not discard any bags or items that
come with the original package until after the entire
installation has been completed.
1
Advertisement
Table of Contents
Related Manuals for Thermador 9000039271
Summary of Contents for Thermador 9000039271
-
Page 1: Table Of Contents
(e.g., in a holiday home), you must drain all the water from the dishwasher’s interior. Water system ruptures that occur as a result of freezing are not covered by warranty. P/N 9000039271 (8408) Table of Contents Placing the Dishwasher ... 10 Securing the Dishwasher ... 10 Drain Hose Connection ... -
Page 2: Tools Needed
TOOLS NEEDED Hammer Tape Measure Wire Cutter MATERIALS NEEDED (Additional materials may be required to comply with local codes.) Electrical Supply Cable - Minimum #14 AWG, 2 conductor, 1 ground, insu- lated copper conductors. Hot Water Supply Line - Minimum 3/8” O.D. copper tubing or metal braided dishwasher supply line. -
Page 3: Materials Supplied
MATERIALS SUPPLIED Figure 1 Accessory Parts Supplied Accessory Parts for your dishwasher will come in one or more plastic bags. Check to make sure that the parts shown in Figure 1 are included with your model. If any parts are missing, contact your dealer immediately. -
Page 4: Enclosure Preparation
ENCLOSURE PREPARATION 90° 34" (864mm) minimum 23-5/8" – 24-1/4" (600–616 mm) Figure 2 Figure 3 23-5/8" – 24-1/8" (600mm – 613mm) 3-1/2" (89mm) Figure 4 NOTE: This dishwasher is designed to be enclosed 23-9/16" on the top and both sides by standard residential (598mm) kitchen cabinetry. -
Page 5: Electrical Preparation
ELECTRICAL PREPARATION 30" (762mm) 21" (533mm) Figure 5 3" - 4" ( 75mm - 100mm) 3/8" - 1/2" ( 8mm - 13mm) Figure 6 WARNING: ELECTRICAL SHOCK HAZARD - Working on an energized circuit could result in serious injury or death. Only qualified electricians should perform electri- cal work. -
Page 6: Plumbing Preparation
PLUMBING PREPARATION WARNING: SCALD HAZARD - Serious injury could result if work is performed on a charged hot water line. Only qualified plumbers should perform plumbing work. Do not attempt any work on the dishwasher hot water supply plumb- 14" ing until you are certain the hot water (355mm) supply is shut off. -
Page 7: Plumbing Preparation
PLUMBING PREPARATION (continued) Figure 8 Figure 10 Figure 11 Drain Plumbing Dishwasher Connection Piece If the dishwasher is to drain either directly into the household drain plumbing or through an air gap, install a dishwasher connection piece under the sink, as shown in Figure 8, letter A. - Page 8 DISHWASHER PREPARATION (continued) Figure 12 Junction Box Cover Figure 13 Junction Box Figure 14 Removing the Toe Panel DWHD94BF Regular Toe Panel The toe panel is loosely attached with tape. Remove the tape and pull the toe panel away from the dishwasher.
-
Page 9: Door Panel Installation
DOOR PANEL INSTALLATION Figure 15 DWHD94BF - Panel Installation DWHD94BF models come with additional mounting hardware and a template sheet that will show you how to mount the panel. One side of the template shows how to mount a one piece panel; the other side shows how to mount a two piece panel. -
Page 10: Placing The Dishwasher
PLACING THE DISHWASHER 14" (355mm) 21" (533mm) Figure 16 Figure 17 Figure 18 Figure 19 1. Straighten and position the hot water supply line and the electrical supply cable as shown in Figure 16 so that they will align with their channels under the dishwasher base. -
Page 11: Drain Hose Connection
DRAIN HOSE CONNECTION Figure 20 Figure 22 The dishwasher drain hose may be connected to the drain plumbing in one of four ways: 1. Directly to the undersink dishwasher drain connection, as shown in Figure 20. 2. Directly to a disposer dishwasher drain connec- tion, as shown in Figure 21. -
Page 12: Hot Water Connection
HOT WATER CONNECTION WARNING: SCALD HAZARD - Working on a charged hot water line could result in serious injury or death. Do not attempt any work on the dishwasher hot water supply plumbing until you are certain the hot water supply is shut off. -
Page 13: Electrical Connection
ELECTRICAL CONNECTION Strain Relief (not supplied) Figure 24 Strain Relief Plate Figure 25 WARNING: ELECTRICAL SHOCK Strain HAZARD - Working on an energized circuit Relief could result in serious injury or death. Only Plate qualified electricians should perform electrical work. Do not attempt any work on the dishwasher electric supply circuit until you are certain the circuit is de-energized. -
Page 14: Electrical Connection
ELECTRICAL CONNECTION (continued) Figure 26 Figure 27 Figure 28 WARNING: FIRE HAZARD - loose or improper electrical connections can cause fire. Make certain that all electrical connections are properly made. • Do not pre-twist the wires before connecting them with wire nuts. 1/8”... -
Page 15: Final Instructions
BASE AND TOE PANEL (Continued) Figure 29 DWHD94BP and DWHD94BS Base and Toe Panel Installation 1. Place the Base Part under and up the front bottom panel of the dishwasher, as shown in Figure 29. 2. Insert the Base Part screws (Figure 1, letter O) into the Base Part, as shown in Figure 29, letter B. -
Page 16: Customer Service
