Therma-Tru Double-door Specifications

Door Panels
OPTIONAL
FACTORY-GLAZED
GLASS OR GLASS
INSERTS
OPTIONAL
DECORATIVE PANELS
Gasketing,
WEATHERSTRIPPING
HINGES, STRIKES
FRAMES
SILL, SWING-IN, SWING
OUT, SIDELITE OPTIONS
TRANSOM OPTIONS
⎠
Classic-Craft Door System Specifications
Faces: 3/32-inch minimum thickness, molded from proprietary thermoset composite,
wood-grained to duplicate hand-crafted red oak master, stainable and paintable. Door
edges: machinable kiln-dried clear northern red oak, flush and square with door faces,
lock edge reinforced with full-length 3-1/2-inch wide engineered lumber core. Door
bottom edge: moisture-proof and decay-proof composite. Core: foamed-in-place
polyurethane, CFC-free, density 2.0 pcf minimum, K-factor of 0.15 for minimum
thermal transmittance. Standard factory sizes may be edge trimmed or end trimmed in
shop or field to suit replacement door size requirements.
Factory-glazed (available in sidelites):
integral part of skin, molding details match door panel moldings. Glass: minimum 1/8-
inch tempered, two thicknesses with sealed airspace between, air-space typically 1/2-
inch. Options for leaded decorative glass triple-glazed in airspace between tempered
glass faces with solid brass or zinc caming. Etched glass options. Optional removable
red oak wood grilles.
Inserts (lites): perimeter frames in raised-molding patterns, composite frame moldings
wood grained to match door faces, with molding patterns complementing raised panel
moldings, stainable or paintable, screw-fastened to doors, screw holes concealed with
grain-matched plugs in matching material and finish.
tempered, two thicknesses with sealed airspace between, airspace typically 1/2-inch.
Options for leaded decorative glass triple-glazed in air space between tempered glass
faces with solid brass caming. Options for etched glass. Optional removable red oak
wood grilles.
Molded from fiberglass-reinforced thermoset composite, wood grained to match door
faces, stainable or paintable, fastened with very high bond tape.
Swing-in models: jacketed thermoset closed-cell foam
frames. Extruded thermoplastic elastomer, finned and chambered design, press-fit into
bottom edge of doors. Corner pads at bottom margin corners from jacketed thermoset
closed-cell foam.
Steel, zinc-plated, brass finish. Optional solid brass hinges. Screws plated and finished
to match hardware. Minimum hinge size 4 x 4 x .098 inches. Strikes are proprietary
adjustable type, permitting in-out adjustment of door in frame, up to 3/16 inch.
Milled from 5/4 kiln-dried pine, profiled with 1/2-inch stop, minimum depth 4-9/16
inches. Other frame depths available to match wall constructions. Exterior casing
brickmould in WM180 pattern available. Optional frames in clear northern red oak or
exterior grade red oak wrap over pine with matching brickmould. Optional maintenance-
free clad frames and brickmoulds in prefinished white color.
Wide range of sill options:
"monumental" grade with decay proof composite substrate, available bronze and brass
finishes, other sills available in swing-in, swing-out, aluminum, brass or bronze anodized
finish.
Double-door models: double door in 6/8 height available with both leaves active and
locking astragal available, astragal faces in clear northern red oak to match door.
Sidelite options: flush-glazed lite models, raised molding models and raised panel
models with glass moldings to match door panel moldings, in 12-inch and 14-inch
widths. Sidelite systems available with mullions separating doors from sidelites, and
continuous sills and frame head, or as separately framed and cased units joined together.
Transom frames, either rectangular or elliptical, match door frames and have matching
exterior brickmould. Transom frames in primed pine or clear northern red oak to match
door frame option. Clear insulated glass, etched glass or with decorative leaded glass,
detailed with solid brass or zinc caming.
Issued: Oct 2008
perimeter moldings flush with skin and made as
, press-fit in kerfs at jamb stops in
thermally-broken fixed, adjustable with oak threshold, in
SPEC
Door System
Specifications
Glass: minimum 1/8-inch
