- Page 1 KITCHEN SINK Model No. KSEU-3020 OWNER’S MANUAL MODEL NO. KSEU-3020 Installation CAUTION: Read Care and Cleaning Save this manual for future reference. instructions carefully starting your installation. Patent Pending...
-
Page 2: Tools Required
KITCHEN SINK Model No. KSEU-3020 Step-By-Step Installation Instruction Model KSEU-3020 20 x 39-3/8 Tools Required • Ruler • Drill • Caulk • Saber Saw (if counter top cutout is required) • Screw Driver TRACE COMPLETELY AROUND EDGE OF SINK 1. If it is necessary to cut out the counter top, invert sink and position onto the counter top. - Page 3 DRILL STARTER HOLE INSIDE OF CUTOUT LINE 3. Drill starter hole inside of cutout line. NOTE Drill Starter Hole From Bottom Finish Drilling Hole From Top 5. Fixture hole locations are identified with a gray label indicating the most desired placement. Drill starter hole from reverse side. Working from the top side as illustrated, position a hole saw on the starter hole and drill to complete the fixture hole.
- Page 4 KITCHEN SINK Model No. KSEU-3020 7. Apply a bead of caulk (not included) to the underside of the sink flange and position sink into counter top opening. First, tighten screws in front, then tighten rear screws. CLEANING Clean your Swanstone kitchen sink as you would any other fine bath fixture, using normal household detergents and cleansers.
