Manual De Instrucción Manuel D'instruction THE LEADER IN HOME KARAOKE AND BEYOND STVD-1001 DVD / CD+GRAPHICS KARAOKE SYSTEM SISTEMA DE KARAOKÊ COM CD + IMAGEM / DVD SYSTÈME DE KARAOKE DE DVD/CD + GRAPHICS Please read before using this unit.
Page 2
WARNINGS WARNING : TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN C A U T I O N : T O P R E V E N T T H E R I S K O F ELECTRIC SHOCK, DO NOT REMOVE COVER O R B A C K .
IMPORTANT SAFETY INSTRUCTIONS Read Instructions - All the safety and operating instructions should be read before the product is operated. Retain Instructions - The safety and operating instructions should be retained for future reference. Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.
ZOOM WATCHING A MOVIE IN DIFFERENT ANGLES SLOW MOTION MUTE CURSOR AND ENTER GOTO PROGRAM PLAYBACK CONTROL (PBC) TITLE PUBLIC ADDRESS - CONNECT GUITAR AND KEYBOARD CARE AND MAINTENANCE TROUBLE SHOOTING GUIDE SPECIFICATIONS THE SINGING MACHINE KARAOKE GLOSSARY OF TERMS...
FEATURES Still/Fast/Slow/Step Playback Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames. Program Playback for DVD and Audio CD You can program the tracks to play in any desired order. DVD Menu in a Desired Language You can display DVD menus in a desired language, if available on a DVD.
NOTES ON DISCS PLAYABLE DISCS This DVD player is compatible with the following discs. Disc Types Recording (Logos) Types AUDIO VIDEO AUDIO SIMPLE GRAPHICS AUDIO-CD AUDIO CD-R / CD-RW / DVD R / DVD RW AUDIO IMAGE MAX. Disc Size Playing Characteristics Time...
NOTES ON DISCS PLAYABLE DISCS This player conforms to the NTSC color system. You cannot play discs recorded in other color systems such as PAL or SECAM. Some discs include region codes as shown below. The number inside the symbol refers to a region of the world, and a disc encoded in a specific region format can only be played back on DVD players with the same region code.
Page 8
NOTES ON DISCS DISC TYPES Data on a MP3 is divided into sections called “albums”, and then into subsections called “tracks”, each of which is given an album or track number. When you make MP3 data, you refer to the manual accompanying the disc. Example Track 1 Track 1...
INTRODUCTION Your DVD / Compact Disc+Graphics Karaoke System will provide you with fun and entertainment. You will be the “star” while singing with your favorite recordings as well as listening to your voice with the music through the system’s speakers. Before you attempt to use your unit, please read this manual thoroughly to familiarize yourself with all the features available and the sections of the manual that describe their operation.
ASSEMBLY STEP 1 Place the main unit on top of the subwoofer and align it to lock the two pieces together. STEP 2 Front View STEP 3 STEP 2 Join the main unit into the subwoofer according to the installation as illustrated. STEP 3 Push the main unit back until you hear a click sound;...
TO DISMANTLE STEP 1 INSTALLATION INSTRUCTION FOR TOWER SPEAKERS STEP 1 Join the speaker into the stand according to the installation illustration. STEP 2 Tighten five screws at the bottom of the speaker. STEP 1 STEP 2 Depress two plastic strips at the back of the unit.
CONTROL LOCATIONS FRONT VIEW 1. Camera Lens 13. Karaoke Function Button 2. Monitor 14. Stop Button 3. Previous (PRE) Button 15. Karaoke Function “+” Button 4. Program Button 16. DVD Door 5. Audio/ Vocal Button 17. Guitar Jack 6. Standby LED 18.
Page 13
CONTROL LOCATIONS REAR VIEW Brightness Control Contrast Control 40. Vertical Hold Control 41. Audio Input Jack (L) 42. Audio Output Jack (L) 43. Video Input Jack 44. DVD Output Jack 45. S.Video Jack 46. Video Output Jack 47. Audio Output Jack (R) 48.
CONNECT SPEAKERS TO THE MAIN UNIT Connect the speakers to the main unit according to the illustration below. AFTER CONNECTION Power the Singing Machine “ON”. Adjust both the Master Volume and the Mic Volume on your Singing Machine to a comfortable level.
BEFORE CONNECTIONS ARE MADE Always turn off the Singing Machine, TV and other components before connecting or disconnecting any cables. Please refer to the instructions listed on this manual. If another component is being connected to this unit, please refer to the corresponding owner's manual if assistance is needed.
To connect another audio source (such as a Tuner or an AV Receiver) so you can sing along with its music, simply connect the AUDIO OUT jacks (Red & White RCA jacks) to the Singing Machine’s AUDIO IN R & L jacks and choose the DVD/AUX mode by pressing FUNCTION button.
Page 20
To display a video signal from another AV component, set the Function Select to AUX mode and Monitor Select to DVD/AUX mode. To display your image on the Singing Machine’s monitor, set the Monitor Select to CAMERA mode. VIDEO OUT SELECT To display DVD/CDG image on the TV, set Function Select to DVD and set Video Out Select to DVD/AUX mode.
SMM-107B WIRELESS MICROPHONE OPERATION 1) Open the battery compartment. 2) Place a 9V battery in the compartment as indicated by the polarity symbols (+ and -) marked inside the compartment of the wireless microphone. 3) Close the battery compartment. 4) The switch on the wireless microphone has three settings: 1.
INITIAL SETUP Use the setup button to control the setting of this unit. The setup menu is divided into four main categories: General Setup, Audio Setup, Video Setup and Preference Setup. GENERAL SETUP TV Display The aspect ratio of the TV can be changed by selecting one of the following options.
INITIAL SETUP AUDIO SETUP SPDIF Setup SPDIF Output SPDIF/RAW Choose this setting, if your DVD player is connected to a power amplifer with a coaxial cable or an optical cable. When playing a disc recorded with DTS and MPEG audio formats, the corresponding digital signals will be output from the Coaxial Output jack.
BEFORE PLAYING Please check the “Playable Discs” to confirm the disc being used is playable. Confirm the Singing Machine is connected to the component/s properly and the power of the Singing Machine and the other component/s are on. BASIC PLAYBACK TO PLAY A DISC 1.
BASIC OPERATION OTHER FUNCTIONS REPEAT CHAPTER/TITLE/TRACK This function will allow the user to repeat a particular chapter/title/track. The following sequence will display on your TV when pressing this button repeatedly. Chapter Title For DVD disc: CHAPTER TITLE OFF (It will not display on screen.) Track For CDG and CD discs: TRAeeCK...
"AVC" on the lower left corner of the screen Pressing the Karaoke Function +/- button on the front of the Singing Machine or on the remote control will adjust the AVC volume, which ranges from 0 to 10. Pressing the Karaoke Function button again will change the display to "Key Tone"...
BASIC OPERATION OTHER FUNCTIONS SLOW MOTION The user can press the SLOW button repeatedly to adjust the speed of the slow motion as they desired. The following sequence will be shown on screen. For DVD discs: ½ 1/16 aa aa aa ½...
BASIC OPERATION OTHER FUNCTIONS PROGRAM The user can control the playback order as desired by using this function. This unit is equipped with 20 programs. After pressing the PROGRAM button on the remote control or on the unit, the TV screen will display as follows: Use the cursor to select the first entry (i.e.
CARE AND MAINTENANCE POWER SWITCH After using the unit, turn off the power by pressing the ON/OFF button. CLEANING THE UNIT To clean the exterior of the unit, simply wipe with a soft clean cloth moistened with plain lukewarm water. CLEANING THE CD LASER LENS For the Best Results: Use a CD-lens cleaning disc according to the cleaning disc manufacturer...
TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSE Power cord is not securely placed in No power when the unit is on. the AC outlet Power cord is not connected to No power when plugged in. machine. No sound. Volume control is set to minimum. Muting button is pressed.
Page 31
TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSE Balance is not adjusted properly. While playing CDG and singing with the microphone, the music AVC is activated to Maximum. or vocal cuts out. Playing music only track. Video cable is not connected properly to the TV. Source selector on the TV is not set to VIDEO.
SPECIFICATIONS AUDIO SECTION: TOWER SPEAKER OUTPUT POWER (MAX.) TOWER SPEAKER OUTPUT IMPEDANCE SUBWOOFER OUTPUT POWER (MAX.) SUBWOOFER OUTPUT IMPEDANCE DVD PLAYER SECTION: FREQUENCY RESPONSE SIGNAL - TO - NOISE RATIO WOW AND FLUTTER D - A CONVERSION NUMBER OF PROGRAMS DIGITAL OUTPUT MONITOR SECTION MICROPHONE...
THE SINGING MACHINE KARAOKE GLOSSARY OF TERMS In addition to all of the terminology associated with consumer electronics products, a few additional terms are used almost exclusively in karaoke. These terms are meant to familiarize you with the world of Karaoke. The features...
Page 34
ADVERTENCIAS ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIOS O DE CHOQUES ELÉCTRICOS, NO EXPONGA ESTE EQUIPO A LA LLUVIA O HUMEDAD. CUIDADO RIESGO DE CHOQUE ELÉCTRICO NO ABRA CUIDADO: PARA EVITAR CHOQUES ELÉCTRICOS, NO REMUEVA LA TAPA O LA TRASERA. NINGUNA PIEZA QUE PUEDA SER ARREGLADA EN EL INTERIOR.
Page 35
INSTRUCCIONES IMPORTANTES DE SEGURIDAD Lea las Instrucciones - Todas las instrucciones de seguridad y de operación deben ser leídas antes que el producto sea utilizado. Guarde las Instrucciones - Las instrucciones de seguridad y de operación deben ser guardadas, para consulta futura. Advertencias - Todas las advertencias para uso del producto y de las instrucciones de operación deben ser obedecidas.
Page 36
ÍNDICE DE MATERIAS CARACTERÍSTICAS NOTAS SOBRE LOS DISCOS INTRODUCCIÓN MONTAJE PARA DESMONTAR INSTRUCCIONES DE INSTALACIÓN PARA LOS ALTOPARLANTES DE LA TORRE LOCALIZACIÓN DE CONTROLES VISIÓN FRONTAL VISIÓN POSTERIOR SUBWOOFER CONTROLES REMOTO LCD & MICRÓFONO INALÁMBRICO CONEXIONES CONECTE LA UNIDAD PRINCIPAL Y EL SUBWOOFER CONEXIÓN DE UN SISTEMA VÍDEO CONEXIÓN DE UN SISTEMA AUDIO FUNCIONAMIENTO DEL MICRÓFONO INALÁMBRICO SMM-107B...
CARACTERÍSTICAS Reproducción Pausa / Rápido / Lento / Paso Diferentes modos de reproducción son disponibles, incluyendo imagen fija, reproducción acelerada adelante / inversa, cambio lento y cuadro a cuadro Reproducción programada para DVD y CD de audio Usted puede programar las pistas para tocar en el orden deseado. Menú...
NOTAS SOBRE LOS DISCOS DISCOS TOCABLES El tocador DVD es compatible con los discos siguientes. Tipos del Disco Tipos de nsignias Grabación AUDIO VIDEO AUDIO GRÁFICOS SIMPLES AUDIO-CD AUDIO CD-R / CD-RW / DVD R / DVD RW AUDIO IMAGEN Máx.
NOTAS SOBRE LOS DISCOS DISCOS TOCABLES Este tocador es conforme a las normas de color NTSC. Usted no puede tocar discos grabados en otro sistema de color como PAL o SECAM. Algunos discos incluyen códigos de región como mostrado abajo. El número en el símbolo representa la región del mundo, y un disco codificado para el formato de una región especifica puede ser reproducido solamente en tocadores DVD con el mismo código de región.
Page 40
NOTAS SOBRE LOS DISCOS TIPOS DEL DISCO Los datas de MP3 son divididos en secciones llamadas “álbumes” y en subdivisiones llamadas “pistas”, cada una tiene un número de álbum o de pista.Para datos de MP3, consulte el manual que acompaña el disco. Ejemplo Pista 1 Pista 1...
INTRODUCCIÓN Sistema de Karaokê Com CD + Imagem / DVD le proporcionará diversión y entretenimiento. Usted será la “estrella” cantando con sus grabaciones favoritas así como escuchando a su voz con la música a través de los altoparlantes del sistema. Después de algunas instrucciones sencillas, UD puede tornarse un experto.
MONTAJE PASO 1 Coloque la unidad principal encima del subwoofer y alinee para trabar las dos piezas. PASO 2 Visión Frontal PASO 3 PASO 2 Acople la unidad principal en el subwoofer de acuerdo con el diagrama de instalación. PASO 3 Empuje la unidad principal para atrás, hasta oír un sonido de clic para activar la traba como en la ilustración.
PARA DESMONTAR PASO 1 INSTRUCCIONES DE INSTALACIÓN PARA LOS ALTOPARLANTES DE LA TORRE PASO 1 Instale el portavoz en el soporte según la ilustración de la instalación. PASO 2 Apriete cinco tornillo taladrando al fondo del portavoz. PASO 1 PASO 2 Presione los dos filetes plásticos en la parte trasera de la unidad.
LOCALIZACIÓN DE CONTROLES VISIÓN FRONTAL Lentes de la CÁMARA 13. El Botón de la función 2. Monitor Botón Anterior (PRE) 14. Botón STOP Botón Programa 15. El Botón “+” de la función 5. Botón de Audio/Vocal LED de Standby 16. Compartimiento del DVD Botón de Standby Función Seleccionar...
LOCALIZACIÓN DE CONTROLES VISIÓN POSTERIOR Control de Brillo Control de Contraste. 40. Control VERTICAL HOLD Toma de Entrada Audio (D) Toma de Salida Audio (D) Toma de Entrada Video 44. Toma de Salida DVD Video 45. Toma de S.Video Toma de Salida Video Toma de Salida Audio (E) Toma de Entrada Audio (E) 49.
SUBWOOFER VISIÓN FRONTA 57. Botón Power (enciende/ apaga) 58. Subwoofer VISIÓN POSTERIOR Toma de Subwoofer 60. Control de Volumen del Subwoofer Cable de energía CA. Para entrada principal de Fuerza...
CONTROLES REMOTO CONTROLES REMOTO FUNCIÓN Botón Botón de Standby Botones de número (0-9,+10) Botón Botón REPEAT Botón RANDOM Botón de Audio/ Estéreo Botón ZOOM Botón de ÁNGULO El Botón de la función Karaoke Botón de DBB Ecualizador CUIDADO Peligro de la explosión si la batería se substituye incorrectamente. Substituya solamente por el mismo o el tipo equivalente.
LCD & MICRÓFONO INALÁMBRICO Ícono del MONITOR Ícono del PROGRAM Ícono del ZOOM Ícono del CAPÍTULO Ícono del STEREO Ícono del REPEAT Ícono del Izquierda Derecha 10 11 12 Ícono del ECHO Ícono del Ícono del PLAY/PAUSE 18. LCD Ícono del Ícono del Ícono del Ícono de la PISTA...
CONEXIONES CONECTE LA UNIDAD PRINCIPAL Y EL SUBWOOFER Conecte el cable de fuerza del subwoofer marcado como "TO MAIN" en la entrada de la unidad principal marcada como "FROM SUBWOOFER" en la parte trasera del equipamiento. Conecte el cable del subwoofer entre la unidad principal y el subwoofer, en los locales marcados como "SUBWOOFER".
CONEXIONES CONECTANDO A LA ENERGÍA DE LA RED UD puede alimentar el sistema del tomacorriente normal de CA usando el cable de energía suministrado. CUIDADO: El cable de energía CA tiene un conectador polarizado que se encaja en la toma, de una forma única. Sí el conectador no encaja correctamente, delo vuelta e intente de nuevo.
CONEXIONES CONEXIÓN DE UN SISTEMA VÍDEO FORMAS COMUNES DE CONFIGURAR SU TV O VCR UD debe especificar la fuente que UD desea ver, cuando esté conectando el video de una Singing Machina a una TV o VCR. Cada fabricante de la TV y del VCR logra la disposición poco diferentemente. VCR sea diferente, la idea general es la misma.
Page 52
CONEXIONES CONEXIÓN DE UN SISTEMA AUDIO CONECTANDO UN COMPONENTE DE AUDIO EN LA SALIDA DE AUDIO Para conectar un componente de audio (tal como un amplificador de potencia o sistema PA) para escuchar la música de la Singing Machina y las voces, a través del, conecte este componente de audio en las tomas AUDIO OUT o tomas SALIDA COAXIAL.
FUNCIONAMIENTO DEL MICRÓFONO INALÁMBRICO SMM-107B 1) Abra la tapa del compartimiento de las pilas. 2) Ponga una batería de 9V en el compartimiento como indicado, respectando la polaridad (+ o -) indicada en el compartimiento el micrófono inalámbrico 3) Recoloque la tapa. 4) Cierre la tapa del compartimiento de las pilas.
CONFIGURACIÓN INICIAL Utilice el botón para controlar las configuraciones de la unidad. El menú de configuración es dividido en cuatro categorías principales: onfiguración General Configuración Audio, Configuración Video y Preferencias CONFIGURACIÓN GENERAL PANTALLA DE TV El aspecto de la TV puede ser modificado con la selección de las opciones siguientes NORMAL/PS Si la TV y el DVD no pueden desplegar vista de pantalla...
CONFIGURACIÓN INICIAL CONFIGURACIÓN AUDIO Configuración de Spdif Salida SPDIF SPDIF/RAW (valor predeterminado) Escoja esta configuración si su equipo de DVD está conectado a un amplificador de fuerza con un cable coaxial o cable óptico. Al tocar un disco grabado con formatos de audio DTS y MPEG, las señales digitales correspondientes serán la salida de la toma de salida Coaxial.
OPERACIÓN DE BASE ANTES DE TOCAR Verifique “Discos Tocables” para tener certeza que su disco es tocable. Verifique si su Singing Machine esta conectada adecuadamente a los componentes y que la Singing Machine y los otros componentes están conectados. REPRODUCCIÓN BÁSICA PARA TOCAR UN DISCO 1.
OPERACIÓN DE BASE OTRAS FUNCIONES REPETIR CAPÍTULO / TÍTULO / PISTA Esta función posibilita al usuario la repetición de un capítulo / título / pistaparticular. La secuencia siguiente es desplegada en su TV cuando apriete este botón repetidamente. Título Para disco DVD: Capítulo CHAPTER TITLE...
OPERACIÓN DE BASE OTRAS FUNCIONES EFECTO DBB Encienda el efecto de DBB presionando el botón DBB en el control remoto. EFECTO EQ Presione el botón EQ en el control remoto para seleccionar un efecto diferente. Usted puede escoger entre 5 efectos diferentes – Classic (clásico), Jazz, Pop, FLAT y Rock.) AVC/TONO/ECO Presionar el botón de función de karaoké...
OPERACIÓN DE BASE OTRAS FUNCIONES CAMBIO LENTO El usuario puede apretar repetidamente el botón SLOW para ajustar la velocidad de slow motion como desea. La siguiente secuencia será mostrada en la pantalla. Para disco DVD: ½ 1/16 aa aa aa ½...
OPERACIÓN DE BASE OTRAS FUNCIONES PROGRAMA El usuario puede controlar la orden de reproducción como desea con esta función. Este aparato tiene 20 programas. Después de apretar b otón PROGRAMA en el telemando o en el aparato, la pantalla de TV despliega lo siguiente: Utilice el cursor para seleccionar la primera entrada (i.e.
CUIDADOS Y MANTENIMIENTO INTERRUPTOR DE FUERZA Después de utilizar el unidad, desconecte la energía eléctrica, presionando el botón Encender/Apagar. LIMPIANDO LA UNIDAD Para limpiar la parte externa de la unidad, refriegue con un paño limpio y suave, humedecido con agua tibia, pura.
GUÍA DE DIAGNÓSTICO Y ARREGLO DE FALLAS PROBLEMA CAUSA PROBABLE Conectador CA no está conectado Sin tensión cuando activado. en la toma. El cordón de suministro de energía Sin tensión cuando conectado. no es conectado a su Singing Machine. Control de Volumen ajustado al Sin sonido.
Page 63
GUÍA DE DIAGNÓSTICO Y ARREGLO DE FALLAS PROBLEMA CAUSA PROBABLE El balance no está regulado correctamente. Cuando un CDG es tocado y q u e U s t e d c a n ta e n e l AVC está al máximo. micrófono, la música de fondo o las voces son cortadas.
DETALLES TÉCNICOS SECCIÓN DE AUDIO: POTENCIA DE SALIDA DEL ALTOPARLANTES (MÁXIMA) IMPEDANCIA DE SALIDA DEL ALTOPARLANTES POTENCIA DE SALIDA DE SUBWOOFER (MÁXIMA) IMPEDANCIA DE SALIDA DEL SUBWOOFER SECCIÓN DEL TOCADOR DVD: FRECUENCIA DE RESPUESTA RELACIÓN SEÑAL/RUIDO RUIDO Y SISEO CONVERSIÓN D - A NÚMERO DE LOS PROGRAMAS SALIDA DIGITAL SECCIÓN DEL MONITOR...
GLOSARIO DE TÉRMINOS DE KARAOKÉ DE LA SINGING MACHINA Además de toda la terminología asociada a los productos electrónicos de consumo, algunos ítems adicionales son usados casi exclusivamente en karaoke. Estos términos tienen el objetivo de familiarizarle con el mundo del karaoke.
Page 66
AVERTISSEMENTS AVERTISSEMENT: POUR REDUIRE LE RISQUE D'INCENDIE OU DE CHOC NE PAS EXPOSER CE PRODUITA LA PLUIE OU HUMIDITE. AVERTISSEMENT RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR AVERTISSEMENT: POUR EVITER DES RISQUES DE CHOC ELECTRIQUE, NE RETIREZ PAS LE COUVERCLE NI LE PANNEAU ARRIERE.
Page 67
IMPORTANTES INSTRUCTIONS DE SECURITE Lisez les Instructions - Lisez toutes les instructions de sécurité et de fonctionnement avant d'utiliser ce produit. Conservez les Instructions - Conservez les instructions de sécurité et fonctionnement pour future référence. Mises en Garde - Respectez tous les avertissements sur le produit et le mode d'emploi du produit.
Page 68
TABLE DES MATIERES CARACTÉRISTIQUES NOTES SUR LES DISQUES INTRODUCTION MONTAGE POUR DEMANTELER INSTRUCTIONS POUR L’INSTALLATION DES HAUT-PARLEURS TOURS LOCALISATION DES CONTRÔLES VUE DE FACE VUE DE ARRIÈRE SUBWOOFER TÉLÉCOMMANDE AFFICHAGE LCD & MICRO SANS FIL CONNECTIONS CONNECTEZ L’APPAREIL PRINCIPAL À SUBWOOFER CONNEXION A UN APPAREIL VIDEO CONNEXION A UN APPAREIL AUDIO FONCTIONNEMENT DU MICRO SANS FIL SMM-107B...
Page 69
CARACTÉRISTIQUES Lecture Fixe/ Rapide/ Lent/ image par image Divers modes de lecture sont disponibles comprenant image fixe, avance/ retour rapide, ralenti et image par image. Programmation de Lecture de DVD et CD Audio Vous pouvez programmer les pistes qui doivent être jouées dans l'ordre désiré. Menu DVD dans une Langue au Choix Vous pouvez afficher les menus DVD dans la langue de votre choix si elle est disponible sur le DVD.
NOTES SUR LES DISQUES DISQUES QUI PEUVENT ETRE LUS Ce lecteur de DVD est compatible avec les disques suivants: Types Types de Disques d'Enregistrem (Logos) AUDIO VIDEO AUDIO GRAPHIQUES SIMPLES AUDIO-CD AUDIO CD-R / CD-RW / DVD R / DVD RW AUDIO IMAGE Temps...
Page 71
NOTES SUR LES DISQUES DISQUES QUI PEUVENT ETRE LUS Ce lecteur est conforme au système de couleur NTSC. Vous ne pourrez pas jouer de disques enregistrés sur un autre système tel que PAL ou SECAM. Certains disques comprennent des codes régionaux donnés ci-dessous. Le nombre à...
Page 72
NOTES SUR LES DISQUES TYPES DE DISQUES Les données sur un disque MP3 sont divisées en sections appelées « albums », et en sous-sections appelées « pistes », un numéro est attribué à chaque album ou piste. Si vous utilisez des données MP3, reportez-vous au manuel qui accompagne le disque.
Page 73
INTRODUCTION Votre Système De Karaoke De DVD/CD+Graphics of frira des années d'amusement et de divertissement. Vous serez la “star” quand vous chanterez en vous accompagnant sur vos enregistrements préférés ainsi que lorsque vous entendrez votre voix dans les haut-parleurs. Cet Appareil de Karaokê est fait de design compact et comprend beaucoup de fonctions, il est cependant facile à utiliser.
Page 74
MONTAGE ETAPE 1 Placez l’appareil principal sur le subwoofer et alignez-le pour FIXER LES DEUX PARTIES ENSEMBLE. ETAPE 2 Vue De Face ETAPE 3 ETAPE Joignez l’appareil principal au subwoofer comme illustré. ETAPE Tirez l’appareil principal vers l’arrière jusqu’à ce que vous entendiez un déclic, cela ferme le verrouillage comme illustré.
POUR DEMANTELER ETAPE 1 INSTRUCTIONS POUR L’INSTALLATION DES HAUT-PARLEURS TOURS ETAPE Installez ensemble le haut-parleur dans le support conformément à l'illustration. ETAPE Serrez cinq vis au bas du haut-parleur. ETAPE ETAPE 2 Depress two plastic strips at the back of the unit.
LOCALISATION DES CONTRÔLES VUE DE FACE 1. Lentes de la CÁMARA 2. Moniteur 14. Bouton Bouton Précédent (PRE) Bouton de fonction Karaoké “+” Bouton PROGRAMME Bouton Audio/ Vocale LED de STAND-BY Bouton STAND-BY Selection De Fonction Bouton DBB Bouton de Volume Micro 22.
LOCALIZACIÓN DE CONTROLES VUE DE ARRIÈRE Contrôle de Luminosité Contrôle du Contraste Contrôles de BALAYAGE VERTICAL 41. Prises Jack E ntree Audio (G auche 42. Prises Jack Sortie Audio (Gauche) Prises Jack Entree Video 44. Prises Jack Sortie DVD 45. Prises Jack Video-S Prises Jack Sortie Video 47.
Page 78
SUBWOOFER VUE DE FACE 57. Bouton Allumer/ Éteindre 58. Subwoofer VUE DE ARRIÈRE 59. Prises Jack Subwoofer 60. Contrôle de Volume du Subwoofer Fil d'Alimentation AC 62. Vers le courant...
CONNEXION CONNECTEZ L’APPAREIL PRINCIPAL À SUBWOOFER Branchez le fil d’alimentation du subwoofer marqué "TO MAIN" au jack de l’appareil principal marqué "FROM SUBWOOFER" à l’arrière. Connectez le câble du subwoofer à l’appareil principal t au subwoofer; les deux sont marqués «SUBWOOFER »...
CONNEXION BRANCHEMENT DE L'ALIMENTATION Vous pouvez brancher le système à une prise AC normale en utilisant le fil d'alimentation fourni. AVERTISSEMENT: Le fil d'alimentation AC fourni possède une prise polarisée qui n'entre dans la prise murale que d'une façon. Si la prise ne rentre pas débranchez et essayez à nouveau. Ne pas forcer. CONNEXION DE VOTRE ECOUTEUR Il y a une prise d'écouteurs pour utiliser un écouteur à...
CONNEXION CONNEXION A UN APPAREIL VIDEO MOYENS COURANTS POUR CONFIGURER VOTRE TV OU MAGNETOSCOPE Il vous faut spécifier la source que vous souhaitez voir quand vous connectez le vidéo à partir de la Singing Machine soit à un appareil TV ou à un Magnétoscope. Chaque fabricant de TV et Magnétoscope, configure d'une manière différente.
Page 84
CONNEXION CONNEXION A UN APPAREIL AUDIO CONNEXION D'UN COMPOSANT AUDIO EN SORTIE Pour connecter un composant audio (comme un amplificateur ou système d'amplification PA) de façon à pouvoir écouter la musique et les voix de la Singing Machine, connectez le composant audio soit aux prises jack AUDIO OUT ou prise jack COAXIAL OUT.
FONCTIONNEMENT DU MICRO SANS FIL SMM-107B 1) Soulevez le couvercle du compartiment des piles sur le devant de la poignée. 2) Placez une pile de 9 V dans le compartiment comme indiqué en respectant la polarité (+ et -) marquée à l’intérieur du compartiment du micro sans fil 3) Replacez le couvercle.
CONFIGURATION INITIALE Utilisez le bouton de configuration pour régler cet appareil. Le menu de configuration est divisé en quatre catégories principales : Configuration Générale, Configuration Audio, Configuration Video Préférences. CONFIGURATION GENERALE Afficher TV Le rapport largeur / hauteur de votre TV peut être changé...
CONFIGURATION INITIALE CONFIGURATION AUDIO Configuration de Spdif Sortie Spdif SPDIF/RAW (par défaut) Choisissez cette configuration si le lecteur DVD est branché à un amplificateur de puissance avec câble coaxial ou câble optique. Quand vous jouez un disque enregistré en formats audio DTS ou MPEG, les signaux numériques correspondants seront émis par le jack de Sortie Coaxial.
OPERATIONS DE BASE AVANT DE METTRE UN DISQUE Veuillez vérifier « Disques qui peuvent être lus » pour vérifier que le disque peut bien être joué. Vérifiez que votre Singing Machine est connectée correctement aux composants et que votre Singing Machine et les autres composants sont branchés sur l'électricité.
OPERATIONS DE BASE AUTRES FONCTIONS REPETITION DE CHAPITRE / TITRE / PISTE Cette fonction permet à l'utilisateur de répéter des chapitres / titres / pistes particuliers. La séquence suivante sera affichée sur votre TV en appuyant sur ce bouton à plusieurs reprises. Pour DVD: Titre Chapitre...
OPERATIONS DE BASE AUTRES FONCTIONS EFFET DBB Allumez l’effet DBB en appuyant sur le bouton DBB de la télécommande. EFFET EQ Appuyez sur le bouton EQ de la télécommande pour choisir un effet différent. On peut choisir 5 effets différents : Classique, JAZZ Pop, FLAT et Rock. AVC/ TOUCHE/ECHO Appuyez sur le bouton de fonction karaoké...
OPERATIONS DE BASE AUTRES FONCTIONS RALENTI L'utilisateur peut appuyer sur le bouton SLOW à plusieurs reprises pour régler la vitesse de ralenti comme on le désire. La séquence suivante sera affichée sur l'écran. Pour les DVD: ½ 1/16 ½ 1/16 Lecture Normale REMARQUE - Cette fonction ne marche qu'avec les...
OPERATIONS DE BASE AUTRES FONCTIONS PROGRAMMATION L'utilisateur peut contrôler l'ordre de lecture souhaité grâce à cette fonction. L'appareil est équipé de 20 programmations. Après avoir appuyé sur le bouton PROGRAM de la télécommande ou de l'appareil, l'écran TV affichera ce qui suit: Utilisez le curseur pour sélectionner la première entrée (c.à.d.
SOINS ET ENTRETIEN ALIMENTATION Après avoir utilisé appareil, éteignez en appuyant sur le bouton POWER. NETTOYAGE DE L'APPAREIL Pour nettoyer l'extérieur de l'appareil, l'essuyer simplement avec un chiffon doux, propre et humecté d'eau tiède. NETTOYAGE DE LA LENTILLE LASER DU CD Pour de meilleurs résultats: Utilisez un disque de nettoyage de la lentille CD conformément aux instructions du fabricant de disque de nettoyage.
GUIDE DE LOCALISATION DE PROBLÈMES PROBLÈME CAUSE POSSIBLE Ne s'allume pas quand il est en Pas de connexion de la prise position ALLUME. d'alimentation à la prise AC. Ne s'allume pas quand il est Le fil d’alimentation n’est pas branché. branché...
Page 95
GUIDE DE LOCALISATION DE PROBLÈMES PROBLÈME CAUSE POSSIBLE Le contrôle de balance n'est pas réglé correctement. Quand un CDG est joué et que vous chantez au micro, la AVC est au maximum. musique de fond ou les voix sont coupées. Joue seulement la piste de musique.
DÉTAILS TECHNIQUES SECTION AUDIO: ALIMENTATION DE SORTIE DU HAUT- PARLEUR (MAXIMUM) IMPÉDANCE DE SORTIE DU HAUT-PARLEUR ALIMENTATION DE SORTIE DU SUBWOOFER (MAXIMUM) IMPÉDANCE DE SORTIE DU SUBWOOFER SECTION DU LECTEUR DE DVD: RÉPONSE DE FRÉQUENCE RAPPORT SIGNAL - BRUIT BRUIT ET CHUINTEMENT D - A CONVERSION NOMBRE DE PROGRAMMES SORTIE NUMERIQUE...
GLOSSAIRE DES TERMES DU KARAOKE SINGING MACHINE En plus de la terminologie associée avec les appareils électroniques de consommation, des termes supplémentaires sont utilisés presque exclusivement pour le karaoké. Ces termes servent à vous familiariser avec l'univers du Karaoké. Les caractéristiques énumérées ci-dessous, ne s'appliquent au modèle particulier du Singing Machine que vous avez.
Page 100
The Singing Machine Company, Inc. 1001-0607-ENG-SPA-FRE02 6601 Lyons Road, Bldg. A7, Coconut Creek, FL33073-9902, USA. PRINTED IN CHINA IMPRESO EN CHINA TEL: (954) 596-1000 FAX: (954) 596-2000 IMPRIMÉ EN CHINE VISIT OUR WEBSITE www.singingmachine.com VISITE NUESTRO SITIO INTERNETwww.singingmachine.com VISITE NOTRE SITE INTERNET www.singingmachine.com...
