- Page 1 TPA6030A4 Audio Power Amplifier Evaluation Module User’s Guide November 2002 Mixed-Signal Products SLOU113A...
- Page 2 Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
- Page 3 EVM IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including product safety measures typically found in the end product incorporating the goods.
- Page 4 EVM schematic located in the EVM User’s Guide. When placing measurement probes near these devices during operation, please be aware that these devices may be very warm to the touch. Copyright 2002, Texas Instruments Incorporated Mailing Address: Texas Instruments Post Office Box 655303...
-
Page 5: Read This First
How to Use This Manual This document contains the following chapters: Chapter 1—Introduction Chapter 2—Quick Start Chapter 3—Reference Information About Cautions and Warnings This book may contain cautions and warnings. This is an example of a caution statement. A caution statement describes a situation that could potentially damage your software or equipment. - Page 6 SLOU011) provides detailed information on the evaluation platform and its use with TI audio evaluation modules. TPA6030A4 3-W Stereo Audio Power Amplifier With Advanced DC Volume Control (literature number SLOS395). This is the data sheet for the TPA6030A4 audio amplifier integrated circuit.
-
Page 7: Table Of Contents
............... TPA6030A4EVM Layout and Schematic TPA6030A4 Audio Power Amplifier Evaluation Module Parts List Volume Control . - Page 8 Running Title—Attribute Reference Tables 2–1 Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA6030A4 2–2 Typical TPA6030A4EVM Jumper Settings 2–3 Platform Jumper and Switch Settings for the TPA6030A4 2–4 Typical TPA6030A4EVM Jumper Settings for BTL Stand-Alone 2–5 Typical TPA6030A4EVM Jumper Settings for SE Stand-Alone 3–1...
- Page 9 This chapter provides an overview of the Texas Instruments (TI) TPA6030A4 audio amplifier evaluation module (SLOP365). It includes a list of EVM features, a brief illustrated description of the module, and a list of EVM specifications. Topic Feature Highlights ..........
-
Page 10: Feature Highlights
Feature Highlights 1.1 Feature Highlights The TI TPA6030A4 audio amplifier evaluation module and the TI Plug-N-Play audio amplifier evaluation platform include the following features: TPA6030A4 3-W stereo audio power amplifier evaluation module Fully differential operation and internal depop circuitry to minimize... -
Page 11: Introduction
The platform has room for a single TPA6030A4 evaluation module and is a convenient vehicle for demonstrating TI’s audio power amplifier and related evaluation modules. The EVM simply plugs into the platform, which... -
Page 12: Special Notes Regarding The Data Sheet
Special Notes Regarding the Data Sheet 1.4 Special Notes Regarding the Data Sheet The TPA6036A4EVM may have markings not consistent with the data sheet. Some EVMs have an incorrect supply voltage marked on them. The correct supply range is 7 V to 15 V, not 5 V to 15 V. The EVM and this user’s guide refer to the two input pins as HP and LINE, and refer to the control pin as HP/LINE. -
Page 13: Quick Start
SE/BTL pin to automatically switch to SE output mode when a headphone is inserted into the headphone jack. The SE/BTL pin on the TPA6030A4 is designed to switch high when the voltage applied to the pin meets or exceeds 0.8 V , requiring a minimum of 5.6 V when the power... -
Page 14: Typical Ti Plug-N-Play Platform Jumper And Switch Settings For The Tpa6030A4
Table 2–1. Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA6030A4 P-N-P Platform Notes: 1) X = Don’t care 2) ON = Shunt installed 3) OFF = Open 4) Set S2 to ON when signal conditioning board is installed in U1; set S2 to OFF when no signal conditioning board is installed. -
Page 15: Precautions
2.1 Precautions Power Supply Input Polarity and Maximum Voltage Always ensure that the polarity and voltage of the external power connected to V input connector J6 are correct. Overvoltage or reverse-polarity power applied to these terminals can open onboard soldered-in fuses and cause other damage to the platform, installed evaluation modules, and/or the power source. -
Page 16: Quick Start List For Platform
1) Ensure that all external power sources are set to OFF and that the platform power switch S1 is set to OFF. 2) Install a TPA6030A4 module in platform socket U2, taking care to align the module pins correctly. 3) Use switch S2 to select or bypass the signal conditioning EVM (U1). - Page 17 SE and BTL volumes; counterclockwise increases the difference. 15) Turning potentiometer R3 (SEMAX) clockwise increases the maximum SE volume; counterclockwise decreases the maximum SE volume. For more information on volume control operation, see the TPA6030A4 data sheet. Quick Start List for Platform , and the evaluation...
-
Page 18: Quick Start List For Stand-Alone
2.3 Quick Start List for Stand-Alone Follow these steps to use the TPA6030A4EVM stand-alone or when connecting it to existing circuits or equipment. Connections to the TPA6030A4 module header pins can be made via individual sockets, wire-wrapping, or soldering to the pins, either on the top or the bottom of the module circuit board. - Page 19 10) SHUTDOWN: A low voltage applied to this pin shuts down the amplifier IC on the module; a high voltage or float on this pin allows normal operation. Refer to the TPA6030A4 data sheet for trip level information. Power-Up 11) Verify correct voltage and input polarity and set the external power supply to ON.
-
Page 20: Typical Tpa6030A4Evm Jumper Settings For Btl Stand-Alone
Audio Input Audio Input Table 2–5. Typical TPA6030A4EVM Jumper Settings for SE Stand-Alone Note: ON = Shunt installed OFF = Open Power Supply TPA6030A4 Power Supply TPA6030A4 Right External Shut Down Control (active low) Left 33 F – 1000 F 33 F –... -
Page 21: Reference
Topic TPA6030A4EVM Layout and Schematic TPA6030A4 Audio Power Amplifier Evaluation Module Parts List ........... . . -
Page 22: Tpa6030A4Evm Layout And Schematic
TPA6030A4EVM Layout and Schematic 3.1 TPA6030A4EVM Layout and Schematic Figure 3–1. TPA6030A4 EVM Top Layer Figure 3–2. TPA6030A4EVM Bottom Layer Reference... - Page 23 TPA6030A4EVM Layout and Schematic Figure 3–3. TPA6030A4EVM Schematic Reference...
-
Page 24: Tpa6030A4 Audio Power Amplifier Evaluation Module Parts List
TPA6030A4 Audio Power Amplifier Evaluation Module Parts List 3.2 TPA6030A4 Audio Power Amplifier Evaluation Module Parts List Table 3–1. TPA6030A4EVM Parts List Reference Description C9, C11, C12, Capacitor, 1 F, 80%/–20%, nonpolarized, 16 V C1, C2, C3, Capacitor, 0.47 F, C4, C5, C6, 80%/–20%, nonpolarized,... -
Page 25: Volume Control
3.3 Volume Control Table 3–2. Volume Control = 12 V, No Load, SEDIFF = 0 V, SEMAX = 5VREF) Voltage On VOLUME Pin as a Percenatge of 5VREF 0–10 10–12.6 12.6–15.2 15.2–18 18–20.6 20.6–23.4 23.4–26 26–28.6 28.6–31.4 31.4–34 34–36.6 36.6–39.4 39.4–42 42–44.6 44.6–47.2...
