BRACKET
MOUNT
Antennas
Radio
Satellite
Mount
Works with Magnetic Mount Satellite Radio Antennas
Shown below with the TERK XMicro & SIR-Mini
XMicro
SIR-Mini
Installation instructions printed on the inside of this card::
MIRROR
TRUCK
Radio
Satellite
Magnetic
with
Works
SRB-MM
For more information, visit www.terk.com,
For technical support, call 1.800.942.TERK (8375)
Made in China
One year limited warranty
The SIRIUS name is a trademark of
SIRIUS Satellite Radio
The XM name is a trademark of
XM Satellite Radio
TERK and TERK Technologies are trademarks of
TERK Technologies Corp. Commack, NY
©2004 TERK Technologies Corp.
143P005
Mounting the Bracket::
Select the top bar of either the driver's side or
1
passenger side mirror mount (Fig.1). Place the
bracket on the front side of the bar (Fig.2).
Insert the two metal tabs of the small bracket
2
into the two slits near the top of the L-bracket
(Fig.2).
Lower the small bracket over the mirror bar until
3
the bolts in the L-bracket come through the
slots of the small bracket (Fig.2).
Installing the Antenna::
Take your SIR-Mini (for SIRIUS Satellite Radio)
1
or XMicro (for XM Satellite Radio) and place the
antenna on the top of the bracket between the metal
tab and the cable pass-through hole (Fig.5).
Route the cable from the antenna through the top
2
of the bracket using the cable pass-through hole.
Determine the best route for the cable to reach the
satellite radio receiver.
Note: The cable has a very small diameter and should
be routed with care. Three feet of cable protector has
been included. Please install the cable protector around
the cable when going through areas that may cause
damage to the cable such as a door jamb or window. (Fig.4)
Once the cable has been routed to the satellite radio
3
receiver, plug the antenna connector into it.
Please refer to your satellite radio receiver owner's
manual to activate your satellite radio service and
complete your receiver
installation.
While holding the brackets together, install the lock
4
washers and the wing nuts (Fig.3). Before completely
tightening the wing nuts make sure that the ground
plane of the bracket where the antenna will be located
is parallel to the ground. Tighten both wing nuts so that
the bracket is secure.
Fig.1
Fig.2
L-Bracket
Small Bracket
Fig.3
Fig.4
Cable Protector
Fig.5
XMicro
SIR-Mini
