Summary of Contents for Telit Wireless Solutions GM 882
Page 1
INTRODUCTION Thank you and congratulations for having bought a Telit mobile phone. The Gm882 is a GSM dual band, that works fully automatically on the double frequency band (GSM 900-1800 MHz, on condition that the network operator offers this service) and guarantees an excellent quality of conversation and a wider range of the coverage of the radio signal;...
Page 2
USEFUL NUMBERS & CODES Would you like to have more information on Telit products, or on your Gm882? Have you got any suggestions for improvement? Visit our site www.telit.net, or send us an e-mail to info@telit.net. There are some safety numbers and codes for the use of your phone that you should remember.
GSM standard indeed states that for the telephone must use the minimum power necessary for being connected to the nearest repeater. The maximum level of the SAR reached in the most unfavourable conditions and during the emission of the maximum power available with Gm882 is 0.735 W/kg. INSERTING THE SIM CARD •...
Rechargeable Ni-MH batteries (Nickel Metalhydrate, or Nickel-Metalhydride) power this phone. Note: only use original batteries and battery-chargers. Ni-MH batteries are subject to the “memo-effect”, that is the progressive loss of power efficiency if they are not recharged correctly. In order to obtain the best results, remember to recharge the battery only after it is completely flat.
Page 5
THE Gm882: PRESENTATION AND BASIC FUNCTIONS To switch on the Gm882, after you have inserted a valid SIM card and correctly connected the battery, press the key Press the same key for one second, to switch off the phone. After the phone has been switched on, (and the PIN code, if required, has been...
FUNCTION OF THE KEYS function: to switch the phone ON/OFF, turn the “Mute” function ON/OFF during conversation. Soft keys: to perform the functions indicated by the icons on the display. to make a call after the number has been dialled; to confirm a choice, to quickly view the call register in stand-by mode, by pressing the joystick like a key you enter the traditional menu;...
SYMBOLS SHOWN ON THE DISPLAY the signal strength of the cellular network (maximum 5 bars); if the name of the GSM network is not displayed, but the bars are shown, you can only make emergency calls shows that a memo for an appointment, or the alarm clock have been enabled a headset or a viva voce device (optional) are connected shows that there are EMS messages that have not been read;...
Page 8
During a call some icons may appear on the display: indicates call is in progress indicates you have put a call on hold indicates there is a new incoming call while a conversation is in progress. In this case, by pressing answer the new incoming call, or, by pressing reject the new incoming call.
Page 9
If the vibra-call function is ON, the Gm882 informs you, vibrating, that there is an incoming call (see page 38). When someone calls you, 2 icons are viewed on the lower line of the display that show the functions of the keys (soft key) situated below.
Page 10
Emergency calls Any time – even without a SIM card, but on condition that the phone is in an area served by the GSM network – you can make a (free) emergency call. Key in the number 112 in stand-by mode and press Without the SIM card, press and confirm with the key ATTENTION : DO NOT USE THIS SERVICE TO EXCESS...
Page 11
MENU The GM882 has two menus through which you can access the various functions and controls which characterise its functioning. The traditional menu, which includes all the functions and controls, and a quick menu, which with few “clicks”, allows you to use the functions you will probably use most often.
• Direct access to the text editor for editing a new message SMS • Access to the audio profiles, which allow you to set all the sound alerts that the Gm882 can emit – from the SMS tone to the ringing tones for incoming calls, to the flat battery warning tone.
Page 13
Writing letters and numbers in the traditional way When writing EMS/SMS messages and e-mails you can use the T9 technology, whereas in other cases, numbers and letters (for example in the phone book) have to be keyed in in the “ traditional” way. To obtain the desired character, press the corresponding key several times consecutively until the character you are searching for is viewed on the display;...
1 to 9 in the phone book, by simply pressing for a second, in stand-by mode, the key that corresponds to the desired entry. The Gm882 allows you to insert various data for each name; two sequences of characters for the name (e.g. name and surname); home, work and mobile phone numbers;...
Page 15
When you use the internal phone book, you can store further information for each name. For example, you can store the home number, work number, mobile number and e-mail address of one friend. They will be stored in separate files. By moving the joystick left or right you can go from one to another and to call the number you need, simply press Adding a phone number to the internal phone book...
Page 16
8 SIM phonebook: Barred numbers. Internal phonebook: Options menu 9 SIM phonebook: Service numbers 10SIM phonebook: Options menu If you are using the internal phone book, the Options menu is displayed as follows: 1 Memory in use: this allows you to choose between the internal phone book and the SIM card phone book.
CALL REGISTER Basic information (the number of the person you are talking to, if available, the time the conversation started, the call type) of the last calls are stored in your phone. Among the incoming calls there are also the unanswered calls. Information refers to calls received while the phone is switched on and connected to the network;...
With the Gm882 you can send and receive traditional SMS text messages that are enriched with two functions – T9 and EMS – which make the editing of the text easier and quicker and allow you to insert pictures, animations and sounds in your messages.
Page 19
Type (menu 2-1-4-4-3) This network service allows you to convert EMS messages into different formats, such as for example: ISDN and PSTN services, Pager, E-mail, Fax, etc. Change the pre-set value “0_Text” only after having contacted your network operator to make sure these formats can be sent. Extended alphabet (menu 2-1-4-4-4) This function is useful for sending special characters (eg.
Page 20
Concatenated messages The phone Gm882 supports concatenated messages. This means that you can edit a text with more than the traditional 160 characters. Before you send the message, it will be automatically split into two or more messages (up to 5) that will be sent to the same addressee.
Page 21
If the word written by the phone is not the one required, press change it with all the available matches, that is, with all the other words you could have written, using the same keys. For example, with the keys 3-4-4-4-8 you can write “digit”, “fight” or “eight”. If the word you were looking for is not among the matches, you can add the words you often use and that T9 does not “know”...
• Check and modify the SMS Parameters (see “SMS parameters” on page 18) Reading a message When your Gm882 receives a message it emits a short tone or vibration (you can set this in the relative menu – ) and the symbol display.
Page 23
Also in the text messages, the numbers stored in the phone book are automatically replaced by the corresponding name so you can read the name of the person that sent you the message and call them without having to search for their number.
GAMES The menu Games (menu 6) gives access to 5 games. Game rules There are 5 games available: Menu 6-1-1 Cards The betting is $50, and your starting capital is $1000. If, with the first five cards, you have no winning combinations, you can change them. The win of each hand, shown in the top right-hand corner, is automatically added to your capital (viewed at the top on the left).
Page 25
APPLICATIONS The Gm882 provides a series of software applications that are often useful. Date and time: setting the clock (Time Setup), setting the current date (Date Setup), change the Date format (month/day/year – day/month/year – year/ month/day); enable and disable the Internet time, and set its parameters: Daylight Summer Time and the World Timezone.
Page 26
(including pauses). SyncML (menu 5-7) With your Gm882 you can use WAP to connect up to a server where you can store your personal phone book and the data inserted in your agenda. This way you have much more space in your memory for storing data, and the possibility for updating (“Synchronise”) the data of the server in the phone and vice versa.
Page 27
With the GPRS system you pay for the service based on the quantity of data transmitted and not on the duration of the GPRS connection. The Gm882 GPRS telephone allows you to view the quantity of data transmitted and received during the GPRS connections and therefore to know the cost of the connections themselves in other contexts that you can set from the menu.
Page 28
Internet connection with the WAP browser of your Gm882... • You need a SIM card that is enabled for data calls and you must subscribe to the service of the network operator or the service provider. • Search for a place where the signal reception is at its best and stay there; this will definitely improve the quality of your connection.
Page 29
Internet Configuration (menu 8-4) Before you make the first WAP connection, you must set some parameters in the phone – most of them, if they are missing, are given by the service provider. The phone could already be set up for the Internet access; in this case the data needed for the Internet access are already set in the menus: press several times the key to exit the menu and go back to the display in stand-by.
Page 30
Set-up parameters for WAP connection... 1 Connection Name: This is the name that has been assigned to each of the three available profiles and is displayed in the upper menu level, when the phone asks you to select the profile whose parameters have to be viewed/ changed.
Page 32
6 - Incoming mail The incoming mailbox is shown and new messages are signalled. 7 - Reload This reloads the current WAP page. 8 – Settings 8-1 Homepage If this function has been enabled by the Proxy, it shows the complete address of the homepage and gives you the possibility of changing it (settings of this function contained in the Proxy take priority over those contained in the user’s profile).
Page 33
(Schlumberger and RSA). Note: The Gm882 supports the function Download fun. From some sites it is possible to download and store, in your phone, screensavers of compatible format and melodies (standard iMelody) which can then be used as ringing...
Page 34
WAP browser so that it is no longer necessary to insert them manually. Reading a WAP push message: when the Gm882 receives a WAP push, the symbol @ is shown on the display; enter the menu 2-3 and choose the...
Page 35
Zone Messages (menu 2-5): the broadcast messages are free messages which are sent by some network operators and viewed on the phone display in stand-by mode. The most common shows the name of the area you are in. The submenus available are: Reception: you can choose if you want to view the messages that your phone receives from the network operator (enabling of the service and message content varies from operator to operator).
Page 36
You can set, in order, the Contrast (4-1-1) of the display, the Brightness (4-1-2) and the Bright time (4-1-3) of the backlight. The Gm882 is equipped with a Screen saver (4-1-4), that you can choose from those available, which shows an image on the display if no keys have...
Page 37
Wallpaper (4-1-5): use this function to Select (4-1-5-1) the image you want to have on the display in stand-by mode instead of the logo of the network operator (whose name will however appear at the top). With Enable (4-1-5-2) you choose which to have on your display between the image or the operator’s logo.
Page 38
Keyclick vol. (profile X - menu 3): the Gm882 can beep every time you press a key; you can set the volume of this beep for each audio profile. Move the joystick left or right to set the volume desired and press back to the menu.
Page 39
Warning tones (profile X – menu 4): these are tones the Gm882 emits when you receive an SMS message, a Class ero SMS message,when the Battery is Low, and when you switch the Power on or off. In each case there is a menu entry which allows you to set the volume, the tone and the type of alert (ring only, vibrate only, ring and vibrate etc.).Network allows you to enable or...
