Mortch T17-2 50CC Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Mortch International Ltd
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T17-2 50CC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mortch T17-2 50CC

Summary of Contents for Mortch T17-2 50CC

  • Page 1 Mortch International Ltd...
  • Page 2 Mortch International Ltd INTRODUCTION Congratulations on your purchase of T17-2. This model is a fascinating vehicle, which can give you an unsurpassed feeling of power and freedom. It is good for sporting and touring. It is convenient in use, and has elegant appearance design, international fashionable color.
  • Page 3 Mortch International Ltd DESCRIPTION 1. Front Brake lever 2. Front Brake Reservoir Tank 3. Pedal 4.Battery 5.Fuel Tank 6.Helmet Hook 7.Rear Grab...
  • Page 4 Mortch International Ltd 1. Left Handlebar Switch 2. Right Handlebar Switch 3. Main Switch 4. Rear Storage Compartment 5. Rear Shock Absorber 6. Engine 7. Center Stand 8. Side Stand...
  • Page 5 Mortch International Ltd POINTS OF ATTENTION RIDER AND PASSENGER This model is designed for use by only one rider and one passenger. Do not load it over the limits on the specification table. ROAD CONDITION This model is designed for riding on the flat road.

  • Page 6: Table Of Contents

    Mortch International Ltd CONTENTS ACCELERATION………………………………………. …..……..26 SAFETY RIDING……………………………………………………...7 CONTROL FUNCTIONS……………………………………………...8 BRAKING…………………………………………………….…….26 MAIN SWITCH……………………………………………………..8 STARTING OFF…………………………………………………..27 INDICATORLIGHTS…………………………………………………..9 ENGINE BREAK-IN…………………………………………..…...27 SPEEDOMETER……………………………………………………...10 PARKING…………………………………………………….…..28 FUEL GAUGE……………………………………………………..10 PERIODIC MAINTENANCE AND……………………….…..29 HANDLEBAR SWITCHES…………………………………………...11 MINOR REPAIR FRONT BRAKE LEVER…………………………………………..13 PERIODIC MAINTENANCE LUBRICATION……………...…...30 REAR BRAKE LEVER……………………………………………….13 GEAR OIL REPLACEMENT…………………………….…….….31 FUEL TANK CAP…………………………………………………..14...
  • Page 7 Mortch International Ltd SAETY RIDING Regular care and maintenance are essential for preserving your scooter’s value and operating condition. Moreover, what is true for the scooter is also true for the rider good performance depends on being in good shape. Riding under the influence...

  • Page 8: Control Functions

    Mortch International Ltd OFF: CONTROL FUNCTIONS All electrical circuits are switched off. MAIN SWITCH Turn the switch to OFF to stop the engine. The key can be removed in this position. LOCK: The steering is locked when the main switch is LOCK in the ‘LOCK’...

  • Page 9: Indicatorlights

    Mortch International Ltd ！ ！ ！WARNING _____________________ Turn indicator lights ‘ ’ Never turn the key to ‘OFF’ or ‘LOCK’ when the scooter The corresponding indicator flashes when the is moving. The electrical circuits will be switched off switch is moved to the left or right High Beam which may result in loss of control or an accident.

  • Page 10: Speedometer

    Mortch International Ltd SPEEDOMETER FUEL GAUGE 1. Fool gauge 1.Speedometer 2. Trip odometer 3.Reset button The speedometer shows riding speed. This speedometer This model is equipped with an electric fuel is equipped with an odometer and trip odometer. gauge so the rider can monitor the fuel level Reset button help you to reset the clock on the in the fuel tank.

  • Page 11: Handlebar Switches

    Mortch International Ltd HANDLEBAR SWITCHES Turn signal switch To signal a right-hand turn. Push the switch to the ‘ ’.To signal a left-hand turn, push the switch to the ‘ ’.Once the switch is released it will return to the center position.
  • Page 12 Mortch International Ltd Start Switch 1.Turn the main switch to “on” 5. Start switch ‘ ’ 4. Lights switch 2.Apply either brake and push the start switch or kick the start pedal to start the engine. “LIGHTS” Switch CAUTION:__________________________ ”turns on the Turning the light switch to“...

  • Page 13: Front Brake Lever

    Mortch International Ltd FRONT BRAKE LEVER REAR BRAKE LEVER The rear brake lever is located on the left handlebar. Pull it toward the handlebar to apply the rear brake. 1.Rear brake lever 2. Front brake lever The front brake lever is located on the right handlebar.

  • Page 14: Fuel Tank Cap

    Mortch International Ltd FUEL TANK CAP 1 Fuel tank cap 2.Match marks The fuel tank cap is located under the seat. To open !!!WARNING____________________ the fuel tank cap, insert the key into the lock and turn Be sure the cap is properly installed and the key clockwise.
  • Page 15 Mortch International Ltd !!!WARNING __________ Rear storage compartment Do not exceed the loading limits; A helmet can be stored in the compartment under the Rear Compartment: 4kg seat .To open rear storage compartment when it’s ___________________________ locked, insert the key and turn it clockwise.

  • Page 16: Battery Cover Removal

    Mortch International Ltd BETTERY COVER REMOVAL Screw(1x2) 2. Battery cover Pull up the right pedal mat as shown. Then remove the screws on the battery cover.

  • Page 17: Pre-Operation Checks

    Mortch International Ltd PRE-OPERATION CHECKS Before using this scooter, check the following points: NO ITEM ROUTINE PAGE Front Brake Check operation, free play, fluid level and fluid leakage. Top up with DOT4(or 18,19 DOT3) brake fluid if necessary Rear Brake Check operation, condition and free play.

  • Page 18: Brakes

    Mortch International Ltd BRAKES a. Free play 10~20mm b. Free play2~5mm !!!WARNING_______________________ A soft, spongy feeling in the brake lever Brake levers indicates a failure in the brake system. Check for correct free play in the brake levers and Do not operate the scooter until the failure in correct if necessary.
  • Page 19 Mortch International Ltd Inspecting window Brake Fluid leakage (Front) Apply the brake for a few minutes. Check to see if any brake fluid leaks out from the pipe joints or the master cylinder. CAUTION :____________________________ Brake fluid may deteriorate painted surfaces or plastic parts.

  • Page 20: Throttle Grip

    Mortch International Ltd THROTTLE GRIP Free play 3~5mm Turn the throttle grip to see if it operates properly, and check the free play. Make sure the grip returns by spring force when released. Ask a dealer make any necessary adjustments.

  • Page 21: Tires

    Mortch International Ltd TIRES !!!WARNING_________________________ Tire inflation pressure should be checked and adjusted when the temperature of the tire equals the ambient air temperature. To ensure maximum performance, long service and Tire inflation pressure must be adjusted safe operation, note the following:...
  • Page 22 Mortch International Ltd Normal Tire Pressure: cause tire damage, an accident, or even injury. Front Wheel: 200kpa ____________________________________________ Rear Wheel: 220kpa !!!WARNING______________________________ Proper loading of your scooter is important for several Characteristics of your scooter, such as handing braking, 1. Tread depth 2.

  • Page 23: Fittinsandfasteners

    Mortch International Ltd FITTINGS AND FASTENERS LIGTHS, SIGNALS AND SWITHES Always check the tightness of chassis fittings and Check all the lights, meter lights and indicator fasteners before a ride. lights to make sure they are in working condition. Take the scooter to a dealer to correct tightening torque.

  • Page 24: Fuel

    Mortch International Ltd FUEL CAUTION________________________ Always wipe off spilled fuel immediately with a dry and clean soft cloth. Fuel may deteriorate 1.Filler tube 2.Fuel level painted surfaces or plastic parts. Makes sure there is sufficient fuel in the tank. _______________________________________...

  • Page 25: Operation And Important

    Mortch International Ltd OPERATION AND IMPORTANT RIDING POINTS !!!WARNING _______________________ STARTING A COLD ENGINE 1. Before riding this scooter, become thoroughly familiar 1. Turn the main switch to “on ” and the engine with all operating controls and heir functions stop switch to “...

  • Page 26: Acceleration

    Mortch International Ltd BARKING ACCELERATION 1. Close the throttle grip. The speed can be adjusted by opening and closing the 2. Apply both front and rear brake throttle grip. Turning it toward you increases the speed, simultaneously with light pressure and turn it in the opposite direction decreases the speed.

  • Page 27: Starting Off

    Mortch International Ltd STARTING OFF ENGINE BRAKE-IN After warming up the engine : There is never amore important period in the 1. Apply the rear brake lever with your left hand and life of your scooter than the period between hold the rear grab with your right hand.

  • Page 28: Parking

    Mortch International Ltd Keep the riding speed below 60km/h within 1500km. PARKING See the following for details: When parking the scooter, stop the engine and 1. 0~300km: remove the ignition key. Keep the speed below 30 km per hour. 2. 300~500km: !!!WARNING Keep the speed below 40 km per hour.

  • Page 29: Periodic Maintenance And

    Mortch International Ltd PERIODIC MAINTENANCE AND MINOR REPAIR Periodic inspection, adjustment and lubrication will keep !!!WARNING________________________ your scooter in the safety and most efficient condition If you are not familiar with scooter service, possible. Safety is an obligation of the scooter owner.

  • Page 30: Periodic Maintenance Lubrication

    Mortch International Ltd PERIODIC MAINTENANCE/ LUBRICATION A: Adjust C: Clean R: Replace T: Tighten I: check, Clean, Lubrication .Adjust or Replace if Necessary RODAO HAUL(KM) Daily ITEM check 300 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 1100...

  • Page 31: Gear Oil Replacement

    Mortch International Ltd GEAR OIL REPLACEMENT !!!WARNING__________________________ Do not left foreign material enter the gear Replace the gear oil alter initial riding for 300km, case. Be sure oil does not get on the tire or wheel. then replace again after every half year or 3000km later.

  • Page 32: Cleaning Ofair Cleaner

    Mortch International Ltd CLEANING OF ALR CLEANER Recommended oil: Same as engine oil. The air cleaner should be cleaned at the specified drain plug intervals. It should be cleaned more frequently if 8.Install the ail cleaner and the air cleaner cover.

  • Page 33: Spark Plug Inspection

    Mortch International Ltd SPARK PLUG INSPECTION Specified spark plug: The spark plug is an important engine component and is C7HSA(NGK), A7RTC(CHN) easy to inspect. The condition of the spark plug can Before installing the spark plug, measure indicate the condition of the engine. The ideal color on...

  • Page 34: Brake Lever Free Play Adjustment

    Mortch International Ltd BRAKE LEVER FREE PLAT ADJUSTMENT Loosen the locknut and turn the adjusting bolt in 1 locknut 2. Adjusting bolt direction A to increase free play while in direction The front brake lever free play should be adjusted B to decrease free play.

  • Page 35: Inspecting The Brake Fluid Level

    Mortch International Ltd Use only the designated quality brake fluid. Otherwise, INSPECTING THE BRAKE FLUID LEVEL the rubber seals may deteriorate, causing leakage and Inspecting window poor brake performance. Recommended Brake fluid: DOT4 If DOT4 not available, DOT3 may be used.

  • Page 36: Brake Fluid Replacement

    Mortch International Ltd BRAKE FLUID FEPLACEMENT CABLE INSPECTION AND LUBRICATION 1. Complete fluid replacement should be done !!!WARNING only by trained personnel. Damage to the outer housing of cables may allow 2. Have a dealer replace the following internal components during periodic maintenance or rusting and cause interference with cable movement.

  • Page 37: Brake Lever Lubrication

    Mortch International Ltd BRAKE LEVER LUBRICATION CENTER AND SIDE STAND LUBRICATION Lubricate the pivoting parts of both brake levers. Lubricate the pivoting and mating joints. Recommended lubricant: Check to see that the center and side stand move SAE 15W-40 SF up and down smoothly.

  • Page 38: Front Fork Inspection

    Mortch International Ltd FRONT FORK INSPECTION !!!WARNING CAUTION: Securely support the scooter so there is no If any damage or unsmooth movement is Danger or falling over found with the front fork. Consult a dealer. __________________________________ ________________________________ 1. Visual Check: Check for scratches or damage on the inner tube and excessive oil leakage from the front fork.

  • Page 39: Steering Inspection

    Mortch International Ltd STEEPING INSPECTION WHEEL BEARINGS Periodically inspect the condition of the steering. If there is play in the front or rear wheel hub or Worn out or loose steering bearings may be if the wheel does not turn smoothly, have a dangerous.

  • Page 40: Fuse Replacement

    Mortch International Ltd FUSE REPLACEMENT CLEANING & STORAGE A. CLEANING If the fuse is blown, turn off the main switch Frequent, thorough cleaning of your scooter will not only and the switch of the circuit id question. Remove enhance its appearance but will also improve its general the screws on battery case cover, the fuse of specified performance and extend the useful life of many components.
  • Page 41 Mortch International Ltd CAUTION :____________________________ 6. Windscreen cleaning Excessive hose pressure may cause water CAUTION :___________________________________ seepage and deterioration of wheel bearings, Avoid using any alkaline or strong acid cleaner, gasoline, front fork, brakes, transmission seals and brake fluid, or any other solvent.
  • Page 42 Mortch International Ltd 8. Automotive-type wax may be applied to all pained B. STORAGE and chrome-plated surfaces. Avoid combination of Long term storage (60 days or more ) of your scooter will cleaner and wax. Many contain abrasives which may require some preventive procedures to guard against mar the paint or protective finish.
  • Page 43 Mortch International Ltd 3. Lubricate all control cables. 4. Block up the frame to raise both wheels off the ground. 5. Tie a plastic bag over the exhaust pipe outlet to prevent moisture from entering. 6. if storing in a humid or salt-air atmosphere, coat all exposed metal surfaces with a light film of oil.
  • Page 44 Mortch International Ltd TECHNICAL DATA Type: T17 50CC 2T subject Technical details Subject Technical details 49.3 4.8/(6500+325) Displacement Maximum Torque(kw/(r/min)) 7.5:1 Compression Maximum Speed(km/h) 45(70) air cooled Cooling Fuel Capacity 6.0L single/2 stroke/horizontal 90# ( GB 17930-1999) Engine Type Fuel Type Capacity...
  • Page 45 Mortch International Ltd TECHNICAL DATA Type: JHT1750CC2T subject Technical details Subject Technical details 4E8T or BP7HS 130/60-13(130/70-12) Spark Model Front Tire 0.6--0.7 130/60-13(130/70-12) Spark Gap(mm) Rear Tire 1860/680/1220 Transmission Overall Transmission 1280 Ratio(Crankshaft to Wheelbase clutch) Gear Reduction Ratio 3.69 (48/13)
