- Page 1 OMEGA Communications Interface Cabinet Antenna Installation Manual 0049-0706-004...
- Page 3 The products and programs described in this User’s Guide are licensed products of Telenetics Corporation. This User’s Guide contains proprietary information protected by copyright, and this User’s Guide and all accompanying hardware and documentation are copyrighted. Telenetics Corporation does not warrant that the hardware will work properly in all...
-
Page 5: Safety Precautions
This Guide describes how to install the elevated-feed and Yagi antennas for use with the Telenetics OMEGA Communications Interface Cabinet. ! For information about elevated-feed antenna, see Chapter 1. ! For information about the Yagi antenna, see Chapter 2. Safety Precautions Please observe the following precautions when installing the antenna: ! The antennas are electrical conductors. -
Page 6: Grounding Considerations
Technical Assistance If you have any problem with this antenna, you can call Telenetics between 8:00 am and 5:00 pm Pacific Time at (949) 455-4000 Monday through Friday. We recommend that you have your antenna handy, so you can answer any questions the technicians may ask. -
Page 7: Chapter 1 Elevated-Feed Antenna
Two “L” brackets and six screws for wall-mounting the antenna Two fasteners for pole-mounting the antenna ! This manual If any of these items are missing or damaged, please contact Telenetics immediately. OMEGA Antenna Installation Manual Elevated-Feed Antenna Chapter 1... -
Page 8: Choosing A Location
Choosing a Location For best performance, mount the antenna as high as possible, in a clear location above or away from buildings, feed lines, utility wires, and other antennas. Your expertise and particular circumstances will determine the final mounting method. Assembling the Antenna Use the following procedure to assemble the elevated-feed antenna: 1. -
Page 9: Chapter 2 Yagi Antenna
Two lock washers Two nuts ! This manual If any of these items are missing or damaged, please contact Telenetics immediately. Choosing a Location The Yagi antenna can only be mounted so the antenna is oriented horizontally with the elements oriented vertically. For best performance, mount the antenna as high as possible, in a clear location above or away from buildings, feed lines, utility wires, and other antennas. -
Page 10: Installing The Antenna
Installing the Antenna Use the following procedure to assemble the Yagi antenna: 1. Mount the mast onto a wall using the supplied bracket and screws. 2. Mount the brass clamp, as shown in Figure 2. Figure 2. Mounting the Brass Clamp 3. - Page 11 Figure 4 shows a completed installation. Figure 4. Wall-Mounted Yagi Antenna OMEGA Antenna Installation Manual...
