Four-cycle engine horizontal crankshaft air-cooled
Hide thumbs
Table of Contents

Advertisement

Quick Links

TecumsehPower
Operator's Manual
Four-Cycle Engine • Horizontal Crankshaft • Air-Cooled

Table of Contents

IMPORTANT NOTICE! Safety Definitions.........................................ii
I. General Safety Precautions ............................................................. 1
II. How to Get Service .......................................................................... 3
III. Oil and Fuel Specifications............................................................... 3
IV. Before Starting Your Engine............................................................. 4
V. Starting Your Engine ........................................................................ 6
VI. Stopping Your Engine and Short-Term Storage ............................. 12
VII. Maintenance .................................................................................. 12
VIII. Transporting Your Engine............................................................... 16
IX. Storing Your Engine ....................................................................... 16
X. Preventing Forest, Brush and Grass Fires..................................... 18
XI. Maintenance Intervals .................................................................... 18
Emission Control System Warranty ............................................... 21
XII. Warranty Information...................................................................... 22
H30-40
181-789-14
(English) 1/01/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H30-40 and is the answer not in the manual?

Questions and answers

Related Manuals for Tecumseh H30-40

Summary of Contents for Tecumseh H30-40

  • Page 1: Table Of Contents

    TecumsehPower H30-40 Operator’s Manual Four-Cycle Engine • Horizontal Crankshaft • Air-Cooled Table of Contents IMPORTANT NOTICE! Safety Definitions...ii I. General Safety Precautions ... 1 II. How to Get Service ... 3 III. Oil and Fuel Specifications... 3 IV. Before Starting Your Engine... 4 V.
