Page 3
Picture 4 Picture 5 Picture 6 4. Unscrew the two screws on the PCB and the one on power adapter. (See pictures 7 and 8). 5. Remove the OEM PCB and place into the ESD bag. (See pictures 9 and 10). 6.
Page 4
For M/A COM BML 161 78/20 charger housing - Plug the LED connector (attached to the charger top housing) to the HCH-P7101-Retro PCB J3 location b. For M/A COM CH-104560-026 charger housing - plug the LED connector to HCH-P7101-Retro PCB J5 location.
Page 5
Apply GTS front label (LED label) over the old label (See picture 20). c. Apply GTS bottom label over the old label on the charger. (See picture 21). d. Apply GTS back label and over label onto the old label on the charger.
