PX4, PX6, PX8 Lens Plate(s)
Featuring the #SS2 Quick Release Adapter Port
Machined Aluminum Lens Plate
• T6061 Aircraft Aluminum
• 4.5 inch with Large Balancing Slot
• SS2 Quick Release Strap Adapter Port
• Adjustable Lens Foot Anti-Rotation Screws
Thank you for purchasing the ProMediaGear Machined Aluminum Lens Balancing
Plate featuring our SS2 Quick Release Adapter Port. The Lens Plates are CNC
manufactured out of T6061 Aircraft Grade Aluminum for strength and durability.
Made in the USA.
Material
Length
Width
Height
16555 108th Ave, Orland Park, IL 60467 USA
PX4
T6061
4.50" in. / 11.43 cm
1.50" in. / 3.81 cm
.48" in. / 1.22 cm
PX6
T6061
6" in. / 15.24 cm
1.50" in. / 3.81 cm
.48" in. / 1.22 cm
Included Items:
(2) 1/4-20 Mounting Screws
(1) Allen Key Set
PX8
T6061
8" in. / 15.24 cm
1.50" in. / 3.81 cm
.48" in. / 1.22 cm
