System Component
Operating Instructions
SC-EH790
Model No.
SC-EH590
The illustration shows SC-EH790 for the United Kingdom and Eastern Europe.
EB EP GN
Note
"EB" on the outer packaging indicates the
United Kingdom.
Before connecting, operating or adjusting
this product, please read these instructions
completely. Please keep this manual for fu-
ture reference.
RQT6866-B

Advertisement

Table of Contents
loading

Related Manuals for Technics SC-EH590

Summary of Contents for Technics SC-EH590

  • Page 1 System Component Operating Instructions SC-EH790 Model No. SC-EH590 The illustration shows SC-EH790 for the United Kingdom and Eastern Europe. EB EP GN Note “EB” on the outer packaging indicates the United Kingdom. Before connecting, operating or adjusting this product, please read these instructions completely.
  • Page 2 ∏ AC mains lead ........1 of system SC-EH790. : indicates a function which can be enjoyed with SC-EH790 only. : indicates a function which can be enjoyed with SC-EH590 only. System SC-EH790...

  • Page 3: How To Replace Fuse

    Surround speakers Place either side of the listening position, or slightly to the rear, about 1 meter higher than ear level with the Technics logo facing toward the listening position. The effect varies with the type of music and the music source.

  • Page 4: Speaker Leads

    Simple set-up and play The illustrations show SC-EH790 for the United Kingdom and Eastern Europe. STEP Speaker leads Do not connect the AC mains lead until all other connections are complete. Center speaker Surround speaker Surround and center speakers (right) Right Front speaker Speaker side...
  • Page 5 When the unit is in CD mode but a disc isn’t in the play position Press [;] or [!] to resume play. (SC-EH790) or in the player (SC-EH590). Note The disc in the play position is ready to play immediately when you [EH790] press [!].
  • Page 6 < OPEN < OPEN µ COUNTER DECK 1/2 ∫ DOLBY NR REV MODE TAPE EDIT PAUSE RESET DISPLAY T U V W XY Z EH790 SUPER 3D AI EQ MULTI JOG DISPLAY MODE SUPER SUPER CENTER VIRTUAL REAR MULTI REAR SEAT ÎPRO LOGIC SURROUND...
  • Page 7 sDEMO This is a 24-hour clock. The example shows how to set the clock for 16:25 (4:25 p.m.). DEMO The time is set and the original display is restored. Displaying the clock Press [CLOCK/TIMER]. The clock is shown for about 5 seconds. Reset the clock regularly to maintain accuracy.
  • Page 8 To select track 21, press [ 10/-/--]>[2]>[1] To select a 3-digit number e.g. To select track 123, press [ 10/-/--]>[ 10/-/--]>[1]>[2]>[3] Alternatively, press [ [PROGRAM]. Repeat steps 2 through 3 (SC-EH790) or step 3 (SC-EH590) to program additional tracks in the required order. PROGRAM DISC PRGM Press [ ].
  • Page 9 Preparation: Press [CD] on the remote control or [INPUT SELECTOR] on Í SLEEP PROGRAM CANCEL DISC S10/-/-- Starts normal play from a selected track on a selected disc to the last track PRO LOGIC SUPER SRND TEST Î of the final disc (➡ page 8). 3D AI Starts normal play from a selected track to the last track.
  • Page 10 There are two methods of presetting stations. Automatic presetting: The stations the tuner can receive are preset. 2, 4 Manual presetting: There are 39 channels available for presetting. Do the following once each for FM and AM. Preparation: Tune to the frequency presetting is to begin at (➡ page 17). TUNING MODE Hold down [SET].
  • Page 11 SUPER SOUND EQ FLAT To cancel EH590 Press [SUPER SOUND EQ] so the indicator turns orange (SC-EH790) or turns off (SC-EH590). DIGITAL S.WOOFER Turn [MULTI JOG] to select a setting. Each time you turn: HEAVY: Adds punch to rock. CLEAR: Clarifies higher sounds.
  • Page 12 Create your own sound quality effects. EH790 SC-EH590 has three manual equalizers. FLAT EH590 EH790 To cancel MULTI JOG Note The changes you make are stored and automatically recalled the next time you select the manual equalizer. EH590 EH790 EH590...
  • Page 13 See page 25 for speaker level adjustments. Preparation: Connect a DVD player with a built in Dolby Digital or DTS On the remote control Press [VCR/AUX/6CH INPUT] to select “6CH INPUT”. INPUT SELECTOR To cancel Press [INPUT SELECTOR] to select another source. Note SUPER SURROUND You cannot record or enjoy karaoke (For Australia and N.Z.) when you are...
  • Page 14 These effects can be used with the surround systems described on page 24. VIRTUAL REAR Refer to the chart on page 23 for details on which effects can be used. SURROUND These effects are available when the corresponding indicators are alight. Press [CENTER FOCUS].
  • Page 15 See page 39 for tape selection. Note You cannot record when [6CH DISCRETE INPUT] is selected. COUNTER RESET DISPLAY DECK 1/2 Press [COUNTER DISPLAY]. The counter is displayed for about 5 seconds. Press [COUNTER RESET] to reset the counter. To display or reset the tape counter for deck 1, first press [DECK 1/2]. COUNTER DISPLAY COUNTER...
  • Page 16 Preparation: Do the preparatory steps (➡ page 28). To stop recording Press [ ]. To temporarily stop recording Press [ ∫ The deck goes into recording standby mode. To resume recording press [ ] or [ ] with the flashing indicator. ¥...
  • Page 17 This timer records the radio at the set time. The example shows settings for recording preset channel 1 from 18:30 to 19:30. Preparation: Turn the unit on, set the time (➡ page 12), preset radio FPLAY/FREC CLOCK/ TIMER FREC Recording starts 30 seconds before the set time with the volume muted during the set time.
  • Page 18 The sound processor shows the level of each sound range with the three types of display described below. Press [DISPLAY MODE]. The spectrum display will change as follows. DISPLAY MODE (On the sound processor) DISPLAY MODE Remote control only Press [MUTING]. Volume is reduced to minimum.
  • Page 19 ^--------------------------------------} Twist the shield braid to expose the core wire. 15mm On the remote control Press [VCR/AUX/6CH INPUT] (SC-EH790) or [AUX] (SC-EH590). Operate the unit. Shield braid Core wire See the unit’s manual for details on operation and connection. AM loop antenna...
  • Page 20 Troubleshooting guide Before requesting service, make the below checks. If you are in doubt about some of the check points, or if the remedies indicated in the chart do not solve the problem, consult your dealer for instructions. Reference pages are shown as black circled numbers Common Problems No sound.

  • Page 21: Specifications

    Technical specifications SOUND PROCESSOR ∫ FM tuner section Frequency range 87.50–108.00 MHz ∫ EQ/SFP section (0.05 MHz steps) MANUAL GEQ Sensitivity 1.8 ¨V (IHF usable) 5-Band EQ S/N 26 dB Center frequency 70/300/1 k/3.15 k/10 k Hz S/N MONO 70 dB (75 dB, IHF) Level control n2.0, 4.0, 6.0 dB Antenna terminal(s)
