Enwork Equilibrium Installation Instruction

Conference table
Hide thumbs Also See for Equilibrium:

Advertisement

Quick Links

Download this manual
Equilibrium
Conference Table
Installation Instruction
Revision B 11/07/16

Advertisement

loading
Need help?

Need help?

Do you have a question about the Equilibrium and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enwork Equilibrium

Summary of Contents for Enwork Equilibrium

  • Page 1 Equilibrium Conference Table Installation Instruction Revision B 11/07/16...
  • Page 3 Do not, under any circumstance, install on a concrete floor less than four inches thick. Equilibrium assembled can weigh up to 1,700 pounds supported in a three and a half square foot area. It is the responsibility of the dealer to verify that the location for Equilibrium is suitable and is properly installed.

  • Page 4: Tools And Supplies Required

    INSTALLATION INSTRUCTION 1) Tools and Supplies Required Tape Measure Drill / Hammer Drill ½” Diameter 5/8” Socket Masonry Drill Bit 3/4” Socket Phillips Drive Level Adjustable Wrench Socket Wrench Vacuum Utility Knife Roll of Tape Marker Hammer or Mallet...
  • Page 5 INSTALLATION INSTRUCTION 2) Parts and Fasteners Included Aluminum Shim (Pack) ½” x 3 ¾” Concrete Stud ½” – 13 Hex Nut ¾” – 10 x 1 ¼” Hex Bolt 3/8” – 16 Flange Hex Nut 3/8” – 16 x 1 1/2” Flange Hex Bolt 3/8”-16 x 2”...
  • Page 6 INSTALLATION INSTRUCTION 2) Parts and Fasteners Included Center Tie Plate Triangle Base Inverted V Base EQM-1229-1 EQT296 / EQT298 EQV296 / EQV298 EQV426 / EQV428 EQT426 / EQT428 EQM-1229-2 Left Side Top Support Mid Tie Plate Right Side Top Support EQM-2122-xx-L EQM-1228-1 EQM-2122-xx-R...
  • Page 7 INSTALLATION INSTRUCTION 2) Parts and Fasteners Included Right Hand Inner Leg Cover Left Hand Inner Leg Cover Base End Cover EQM-1264-(1,2,3,4) EQM-2126-(1,2,3,4)-RH EQM-2126-(1,2,3,4)-LH EQTxxxE bases All EQV style bases and EQTxxxI bases all EQV style bases and EQTxxxI bases Trough Cover (OPTIONAL) Trough Cover End Cap EQM-1248-xx...

  • Page 8: Installing The Base

    INSTALLATION INSTRUCTION Installing the Base 3) Assembly:...
  • Page 9 INSTALLATION INSTRUCTION Installing the Base continued 3) Assembly: 3.1.1) Place base in final location for installation 3.1.2) Using a utility knife, cut away carpet in the four leg locations. 3.1.3) Once all four leg location carpet cuts are complete, move base and remove cut carpeting. Note: Base must sit directly on concrete floor.
  • Page 10 INSTALLATION INSTRUCTION Installing the Base continued 3) Assembly: 3.4.1) Remove the base. 3.4.2) Drill marked hole locations to 2 ¾” deep. 3.4.3) Vacuum out the drilled holes to remove dust that may prevent anchor from seating properly. Fig. 3.4 3.5.1) Replace the base over final location. 3.5.2) Check that base is level.
  • Page 11 INSTALLATION INSTRUCTION Installing Top Supports 3) Assembly: Fig 4...
  • Page 12 INSTALLATION INSTRUCTION Installing Top Supports continued 3) Assembly: Fig. 4.2 Fig. 4.1 4.2.1) Place top support on base top plate. 4.1.1) Left side top support shown. 4.2.2) Slide top support towards the side wall of base so that the pivot hole on the top support slide onto the pivot bolt on base.
  • Page 13 INSTALLATION INSTRUCTION Installing Top Supports continued 3) Assembly: Fig. 4.6 Fig. 4.5 4.5.1) Loosely install 3/8”-16 x 2” flange hex bolts 4.6.1) Loosely install 3/8”-16 flange nut onto end tie with flat washers, both sides and 3/8”-16 plate bolt. flange hex nut through both top supports and Note: Do not tighten any hardware yet.
  • Page 14 INSTALLATION INSTRUCTION Installing Top Supports continued 3) Assembly: Fig. 4.10 Fig. 4.9 4.9.1) Push shims under the top support arm as far as 4.10.1) Level top support arms front to back at the as they will go for full support. at the end of the arm as shown in Fig.
  • Page 15 INSTALLATION INSTRUCTION Installing Top Supports continued 3) Assembly: 10” Fig. 4.14 Fig. 4.13 4.14.1) Looking down the edge of the table, ensure 4.13.1) Measurement between arms should be 10”. that top supports are straight. Note: Ensure arms are straight, non aligned arms will cause issue with trough installation.
  • Page 16 INSTALLATION INSTRUCTION Installing surface and power 3) Assembly: Fig. 5.2 Fig. 5.1 5.1.1) Center surface on base. For multi piece tops, 5.2.1) If surface has power and data cutouts attach tight joint fasteners. check that they are unimpeded by top tie plates.
  • Page 17 INSTALLATION INSTRUCTION Installing leg covers 3) Assembly: 6.1) Fig. 6.1 is base with inner leg cover option. Fig. 6.1 Base leg slot Cover hook 6.2.1) Inside leg covers are installed by placing the hook on the back of leg cover into the slot at the base of the leg.
  • Page 18 INSTALLATION INSTRUCTION Optional Oasis Mini Extension Kit 3) Assembly: Optional Oasis Extension Bars 3/8”-16 x 2 ¼” Flange Bolt Fig 7.1 Fig 7.1) If an Oasis Mini power unit is installed over the base (EQV296 / EQV426 / EQT296 / EQT426 models only).
  • Page 19 12900 Christopher Drive Lowell, MI 49331 800.815.7251 www.enwork.com Specifications subject to change without notice.
