Tech4o Northstar CW1 Manual

Congratulations on the purchase of
the Tech 4 o NORTHSTAR CW1 or
CW2 compass watch.
Please read these instructions and
save for future reference.
For best performance, we
recommend that you:
• Avoid exposing the watch to
extreme conditions for extended
periods
• Avoid rough use or severe
impacts
• Do not open the watch case
unless certified to repair
electronic instruments
• Clean with a soft damp cloth
• Keep watch away from
magnetic fields such as mobile phones, speakers and motors
• Store in a dry place
NORTHSTAR FEATURES
Current Time Mode
Time System:
• Hour - minute - second. AM [A] PM [P]
• 12 hour or 24 hour format
• Animated 1 second bar graph
Calendar System :
• Month - date - day of week. Auto correction for leap year and day of week
Compass Mode
• 16 compass directions- 4 cardinal and 12 ordinal points
• Magnetic North pointer • Compass lock
• Backward bearing • Declination setting and calibration
Daily Alarm Mode
• Daily alarm • Hourly beep
Chronograph Mode
• Measurement unit - 1/100 second
• Measuring capacity - 99 hours. 59 minutes & 59.99 seconds
Timer Mode
• Measurement unit - 1 second
• Measuring capacity - 99 hours, 59 minutes & 59 seconds
Pace Mode
• Pace beat - 40 to 180 beats per minute
Dual time Mode
Time System
• Hour - minute - second. AM [A] PM [P]
• Animated 1 second bar graph
FUNCTIONS MAP
[MODE]
Pace
Dual Time
[MODE]
[MODE]
[MODE]
Countdown Timer
[MODE]
[MODE]
Chronograph Daily Alarm
NORTHSTAR CW1 & CW2
Navigation
Arrow
LIGHT
MODE
Display
Current Time (date)
[ST/STP]
[LAP/RESET]
Current Time
[seconds]
Compass
CURRENT TIME MODE
Press [ ST/STP ] button to toggle between
Seconds Display and Date Display
Time Display
• 1st row displays: day of week
• 2nd row displays: hour - minute
• 3rd row displays: second
• Animated (1 second) - displays in the
ST/STP
perimeter bar graph
Date Display
• Day of week, hour, minute - display in the 1st and
2nd rows
• Numerical day, month - display in the 3rd row
• Animated (1 second) - displays in the perimeter bar
graph
NOTE: Press and Hold [ ST/STP ] to toggle the date
format between month - day and day - month
LAP/RESET
To Set the Currant Time Mode
• In the currant time mode, Press and Hold [MODE]
for 2 seconds until the "seconds" digits flash
• Press [ST/STP] or [LAP/RESET] to reset the
seconds to zero; OR Press [MODE] to navigate to
any setting you wish to change.
See navigation chart at right
• When the setting you wish to
change flashes, Press [ST/STP]
to raise the value or
[LAP/RESET] to lower the value.
Note: If you Press and Hold the
button, the rate of change is faster
• When 12 or 24 flashes, Press
[ST/STP] or [LAP/RESET] to
toggle between the 12 /24 hour
format. Press [MODE] to confirm
NOTE: If NO INPUT for 1 minute
during setup, the display will
default to the Current Time Mode
DAILY ALARM MODE
When the daily alarm is ON, the watch will beep for 20 seconds at the assigned time.
When the hourly beep is ON, the watch will beep twice every hour on the hour
Daily Alarm Display
Daily alarm setting ( hour - minute ) -
displays in the 2nd row
To Set the Daily Alarm Mode
• In the Daily Alarm Mode, Press and
Hold [ MODE ] for 2 seconds until
the "seconds" digits flash
• Press [ST/STP] or [LAP/RESET] to
reset the seconds to zero; OR Press
[MODE] to navigate to any setting
you wish to change. See navigation
chart at right
• When the setting you wish to
change flashes, Press [ST/STP] to
raise the value or [LAP/RESET] to
lower the value.
Note: If you Press and Hold the button,
the rate of change is faster
To turn Daily Alarm ON/OFF
• Press [ ST/STP ] while in the Daily
Alarm Mode
• When the icon
Daily Alarm is ON
To turn Hourly Beep ON/OFF
• Press [ LAP/RESET ] while in the Daily Alarm Mode
• When the icon
day of week
current hour,
minute
current
second
[ST/STP]
Increase
hold [ST/STP]
Increase
faster
[LAP/RESET]
Decrease
hold [LAP/RESET]
Decrease
faster
Alarm Time
( hour, minute)
Alarm Beep
[ST/STP]
Increase
hold [ST/STP]
Increase
faster
[LAP/RESET]
Decrease
hold [LAP/RESET]
appears, the
Decrease
faster
appears, the hourly beep is ON
animated
bar graph
time display
[ST/STP]
day,
month
date display
Current Time Mode
hold
[MODE]
[MODE]
[MODE]
second minute
[MODE]
year
hour
[MODE]
date
month
[MODE]
12/24
Daily Alarm Mode
Hourly Beep
Daily Alarm Mode
hold
[MODE] [MODE]
minute
[MODE]
hour
